Quick Details
-
Power:
-
18.5KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LTMG
-
Maximum Digging Height:
-
3700mm
-
Maximum Digging Depth:
-
2400mm
-
Machine Weight:
-
2350 kg
-
Max Digging Radius:
-
1610mm
-
Rated Speed:
-
2.8km/h
-
Marketing Type:
-
Hot products 2023
-
Type:
-
Mini Crawler Excavator
-
Keywords:
-
Crawler Excavator
-
Product name:
-
Mini Excavator 2 Ton
-
Track Length:
-
1670mm
-
Engine:
-
LAIDONG/KUBOTA
-
Bucket width:
-
435mm
-
Platform ground clearance:
-
150mm
-
Overall dimension:
-
3555x1300x2290mm
-
Optional:
-
Grappler, Fork, Auger, Hammer etc
-
Mini Swing Radius:
-
1610mm
Quick Details
-
Operating Weight:
-
2ton, 1.5TON, 1.8ton
-
Bucket capacity:
-
0.07CBM
-
Engine Brand:
-
LAIDONG/KUBOTA
-
Power:
-
18.5KW
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LTMG
-
Maximum Digging Height:
-
3700mm
-
Maximum Digging Depth:
-
2400mm
-
Machine Weight:
-
2350 kg
-
Max Digging Radius:
-
1610mm
-
Rated Speed:
-
2.8km/h
-
Marketing Type:
-
Hot products 2023
-
Type:
-
Mini Crawler Excavator
-
Keywords:
-
Crawler Excavator
-
Product name:
-
Mini Excavator 2 Ton
-
Track Length:
-
1670mm
-
Engine:
-
LAIDONG/KUBOTA
-
Bucket width:
-
435mm
-
Platform ground clearance:
-
150mm
-
Overall dimension:
-
3555x1300x2290mm
-
Optional:
-
Grappler, Fork, Auger, Hammer etc
-
Mini Swing Radius:
-
1610mm
It is used to restore the ground, break the concrete, and for cable casting, water pipe laying, planting, cleaning of river/ditch and construction project. It has several functions: excavation, breaking, ditch cleaning, drilling, bulldozing and ect.
Advantages
◆Imported accessories to enhance the overall performance of the machine.
◆Signle-forging forming cylinder, not easy to break, built-in NOK seal.
◆Use thicker high-quality steel, apply plastic molding process, prevent rust and anti-corrosion.
◆Engineering rubber track, fearless of harsh terrain;
◆The 360-degree body rotates freely, and the smart body facilitates outdoor work.
◆Signle-forging forming cylinder, not easy to break, built-in NOK seal.
◆Use thicker high-quality steel, apply plastic molding process, prevent rust and anti-corrosion.
◆Engineering rubber track, fearless of harsh terrain;
◆The 360-degree body rotates freely, and the smart body facilitates outdoor work.
|
Performance Parameters
|
Unit
|
LTE15
|
LTE18
|
LTE20
|
||||
|
Operating Weight
|
Kg
|
1400
|
1750
|
1950
|
||||
|
Engine Model
|
|
Kubota D722
|
Laidong 3TE25
|
|
||||
|
Rated Power
|
Kw
|
10.4KW/2500rpm
|
18.4
|
18.4
|
||||
|
Bucket Capacity
|
m³
|
0.025
|
0.06
|
0.06
|
||||
|
Bucket Width
|
mm
|
385
|
435
|
435
|
||||
|
Max Digging Force
|
Kn
|
9
|
11.5
|
11.5
|
||||
|
System Working Pressure
|
Mpa
|
20
|
18
|
18
|
||||
|
Swing Speed
|
rpm
|
12-13
|
10-12
|
10-12
|
||||
|
Traveling Speed
|
km/h
|
2.1~3.2
|
2.8
|
2.8
|
||||
|
Gradeability
|
°
|
58
|
35
|
35
|
||||
|
Ground Pressure
|
Kpa
|
23
|
38
|
38
|
||||
|
Operating Range
|
|
|
|
|
||||
|
Max. Digging Distance
|
mm
|
3529
|
3860
|
3860
|
||||
|
Max. Digging Depth
|
mm
|
2017
|
2050
|
2050
|
||||
|
Max. Digging Height
|
mm
|
2955
|
3370
|
3370
|
||||
|
Max. Dumping Height
|
mm
|
2077
|
2390
|
2390
|
||||
|
Min. Swing Radius
|
mm
|
|
1720
|
1720
|
||||
|
Overall Dimensions
|
|
|
|
|
||||
|
Overall Length
|
mm
|
3329
|
3800
|
3800
|
||||
|
Overall Width
|
mm
|
990
|
1050
|
1050
|
||||
|
Overall Height
|
mm
|
2267
|
2280
|
2280
|
||||
|
Min. Ground Clearance
|
mm
|
153
|
210
|
210
|
||||
|
Track Ground Length
|
mm
|
1190
|
1050
|
1050
|
||||
|
Track Width
|
mm
|
200
|
230
|
230
|
||||
