Quick Details
-
Brand Name:
-
LXSHOW
-
Power:
-
100W
-
Dimension(L*W*H):
-
760mmX780X790mm
-
Product name:
-
Laser cleaning machine
-
Laser power:
-
50W 70W 100W 200W
-
Laser wavelength:
-
1064nm
-
Pulse frequency:
-
20-100KHz
-
Cooling method:
-
Air cooling
-
Scan width:
-
10-60mm
-
Optional:
-
Hand/automatic
-
Working temperature:
-
5-40℃
Quick Details
-
Applicable Industries:
-
metal processing company
-
Weight (KG):
-
20
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
LXSHOW
-
Power:
-
100W
-
Dimension(L*W*H):
-
760mmX780X790mm
-
Product name:
-
Laser cleaning machine
-
Laser power:
-
50W 70W 100W 200W
-
Laser wavelength:
-
1064nm
-
Pulse frequency:
-
20-100KHz
-
Cooling method:
-
Air cooling
-
Scan width:
-
10-60mm
-
Optional:
-
Hand/automatic
-
Working temperature:
-
5-40℃
| 10-80Mm Scan Width Cleaning Machine Laser Rust Removal Portable With Fiber Laser Device |
Laser cleaning technology
1) Powerful, short pulses, fast moving laser pulses act on the surface of the target, producing tiny plasma ruptures, shock waves, thermal stress, etc., causing surface materials to sublimate and evaporate.
2) The focused laser beam is capable of accurately evaporating surface objects or dirt.
3) Laser cleaning is suitable for metal surfaces. The treated and optimized laser beam does not alter metal properties or damage those laser treated surfaces. The precisely tuned laser beam acts only on the coating, residual residue or oxide, and does not harm the underlying parent metal surface.
4) By adjusting other parameters, the laser beam is able to achieve the desired cleaning effect accurately and easily.
|
Technical Parameters |
||||||
|
Equipment model |
LXF -7C-0050 |
LXF -7C-0070 |
LXF -7C-0100 |
LXF -7C-0200 |
||
|
Laser working medium |
Yb-doped fiber |
|||||
|
Laser power |
50W |
70W |
100W |
200W |
||
|
Laser wavelength |
1064nm |
|||||
|
Pulse frequency |
20-100KHz |
20-100KHz |
20-200KHz |
20-50KHz |
||
|
C ooling method |
Air cooling |
Air cooling |
Air cooling |
Air cooling |
||
|
Dimension |
760mmX780X790mm |
1100x950x700m |
||||
|
Total Weight |
56kg |
60kg |
65kg |
130kg( Including Water tank ) |
||
|
Total power |
350W |
500W |
600W |
1000W |
||
|
Scan width |
10-60mm |
|||||
|
Optional |
Hand/automatic |
|||||
|
Working temperature |
5-40℃ |
|||||
