Quick Details
-
Application:
-
Supermarket, Warehouse, Bank, etc
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
OEM
-
Model Number:
-
AC600KG Rolling Door Engine
-
Usage:
-
Control Rolling Door up and down
-
Color:
-
Black, Gray, Yellow, Blue, etc
-
Feature:
-
Easy Installation
-
Open Style:
-
Electric/Manual
-
Motor advantage:
-
Low Noise
-
Running Speed:
-
Constant speed
-
Certificate:
-
CCC, CE, ISO9001:2015
-
Remote Control:
-
Learning Code or Dial Code
-
Bracket:
-
Can be customized
-
Material:
-
100% Pure Copper Wire
Quick Details
-
Warranty:
-
1 Year
-
After-sale Service:
-
Online technical support
-
Project Solution Capability:
-
Others
-
Application:
-
Supermarket, Warehouse, Bank, etc
-
Place of Origin:
-
Fujian, China
-
Brand Name:
-
OEM
-
Model Number:
-
AC600KG Rolling Door Engine
-
Usage:
-
Control Rolling Door up and down
-
Color:
-
Black, Gray, Yellow, Blue, etc
-
Feature:
-
Easy Installation
-
Open Style:
-
Electric/Manual
-
Motor advantage:
-
Low Noise
-
Running Speed:
-
Constant speed
-
Certificate:
-
CCC, CE, ISO9001:2015
-
Remote Control:
-
Learning Code or Dial Code
-
Bracket:
-
Can be customized
-
Material:
-
100% Pure Copper Wire
Product Description
Application Area:
Our motors are applied to shopping centers, warehouse, garages, theaters, hotels, banks, factories and other buildings' rolling shutter doors' opening and closing, with electric and manual function.
Feature
1) Shell: Aluminium alloy , solid and light but
durable
and
easy to install
.
2)
Low noise
: low energy consumption, small vibration.
3) Limit System:
Correct control
, easy operation , and big control range.
4)
Anti-dropping device
: Preventing accidental injury and ensure safety.
5)
Transmitters
:
It outfits with remote control.
Technical Parameter
|
Model No. |
Max lifting weight(kg) |
Max lifting height(m) |
Rated Input Power(W) |
Output Torque(N.m) |
Big reel sprocket Rotation(r/min) |
Chain No. |
|
220V /230V 50HZ /6 0HZ |
||||||
|
AC300KG-1P |
300 |
6.5 |
450 |
168 |
6.2 |
10A |
|
AC500KG-1P |
500 |
6.5 |
450 |
343 |
6.2 |
10A |
|
AC600KG-1P |
600 |
6.5 |
680 |
412 |
6.2 |
10A |
|
AC800KG-1P |
800 |
7 |
700 |
607 |
4.2 |
10A |
|
AC1000KG-1P |
1000 |
7 |
700 |
1102 |
3.5 |
12A |
|
380 V /415V 50HZ /6 0HZ |
||||||
|
AC 10 00KG- 3 P |
1000 |
8 |
400 |
1102 |
6.5 |
1 2 A |
|
AC 13 00KG- 3 P |
1300 |
8 |
600 |
1372 |
6.5 |
1 2 A |
|
AC 15 00KG- 3 P |
1500 |
8 |
600 |
1610 |
5.7 |
1 2 A |
|
AC 20 00KG- 3 P |
2000 |
8 |
800 |
2200 |
5.7 |
1 2 A |
More information about our products, please click in our website at: fjja.en.alibaba.com.
Packing & Delivery
Packing
:
One set in two cartons, plastic bag inside, carton outside.
( The outside cartons can be customized acco
r
ding to customers' requirements, like printing logo or words on it or according to your own design to print it.)
Loading Capacity : A 20 GP container can hold about 520-550 PCS AC motor , if DC motors, 480-520PCS is available.
Delivery time : We will delivery the goods in 10-45 days after we receiving your deposit, which according to your exact quantity and requirements~
