KD C6266C pool cue lathe machine taiwan lathe machine lathe headstock

KD C6266C pool cue lathe machine taiwan lathe machine lathe headstock

FOB Reference Price: Get Latest Price

≥1 Sets

US $12506

≥3 Sets

US $12006

≥5 Sets

US $11256

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Range of Spindle Speed(r.p.m):: 36 - 1600 r.p.m

Width of bed (mm):: 405

Max. Turned Length (mm):: 830 mm

Spindle Motor Power(kW):: 7.5

Place of Origin:: Zhejiang, China

Brand Name:: KD

Model Number:: DC2640-C

Voltage:: Made to order

Dimension(L*W*H):: 2500x1100x1450mm

Weight (KG):: 3000 KG

CNC or Not:: Normal

Automatic Grade:: Manual

Width of bed:: 405mm

Max. Swing Diameter:: 660mm metal lathe

Weight:: 3000kg

Power(W):: 7.5 kw metal lathe

Quick Details

Max. Length of Workpiece (mm):: 1000 mm

Machining Capacity:: Medium Duty

Spindle Bore(mm):: 105

Range of Spindle Speed(r.p.m):: 36 - 1600 r.p.m

Width of bed (mm):: 405

Max. Turned Length (mm):: 830 mm

Spindle Motor Power(kW):: 7.5

Place of Origin:: Zhejiang, China

Brand Name:: KD

Model Number:: DC2640-C

Voltage:: Made to order

Dimension(L*W*H):: 2500x1100x1450mm

Weight (KG):: 3000 KG

CNC or Not:: Normal

Automatic Grade:: Manual

Width of bed:: 405mm

Max. Swing Diameter:: 660mm metal lathe

Weight:: 3000kg

Power(W):: 7.5 kw metal lathe

FEATURES AT A GLANCE

Product Features

1. Precision ground and hardened bed ways.

2. The spindle is supported with precision roller bearings. The spindle system is high in rigidity and accuracy.

4.An automatic stopping device is used to realized automatic stop for the machining of a work piece of a certain length.

4. Easy operating speed change levers.

5. Removable gap is provided for larger diameter work.

PRODUCT SPECIFICATIONS

MODELS	C6256C	C6266C	C6277C
CAPACITY
Max. swing over bed	Ф560mm	Ф660mm	Ф770mm
Max. swing over carriage	Ф360mm	Ф420mm	Ф575mm
Max. swing over gap	Ф770mm	Ф870mm	Ф1050mm
Bed width	405mm
Effective length of gap	230mm
Distance between centers	1000/1500/2000/3000mm
Max turning length	830/1330/1830/2830mm
SPINDLE
Spindle nose	D8
Spindle bore	Ф105mm
Taper bore of spindle	Ф113mm 1:20
Steps of spindle speed	12
Range of spindle speed	36~1600rpm
FEED
Range of longitudinal feeds	0.063~2.52 (0.023″~0.937″)mm
Range of cross feeds	0.027~1.07(0.010″~0.404″)mm
RAPID TRAVEL
Longitudinal	4500mm/min
Cross	1900mm/min
THREAD RANGE/ NUMBER
Metric pitch threads	1~14mm/ 22
Whit-worth threads	28~2TPI/ 26
Module threads	0.5~7MP/ 18
D.P. Threads	56~4DP/ 24
TAILSTOCK SLEEVE
Taper bore	M.T.NO.5
Max.travel	150(5~29/32″)mm
External diameter	Ф75(2~61/64″)mm
OTHERS
Size of tool shank	25×25mm
Max travel of cross slide	310mm	360mm	430mm
Max.travel of top slide	145mm
Main motor power	7.5kw
Overall dimension (LxWxH)	2500/3000/3500/4500x1100x1350mm	2500/3000/3500/4500x1100x1450mm	2500/3000/3500/4500x1100x1540mm
Net weight	2400/2650/2900/3250g	3000/3200/3400/3900kg	3600/3800/4000/4500kg
