Quick Details
-
Model Number:
-
DS-2DE2A404IW-DE3
-
Image Sensor:
-
1/3" progressive scan CMOS
-
Min. Illumination:
-
Color: 0.005 Lux
-
Adjustment Range:
-
2.8 to 12mm, 4x optical zoom
-
Wide Dynamic Range:
-
120 dB
Quick Details
-
Special Features:
-
Waterproof / Weatherproof
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
HIK
-
Model Number:
-
DS-2DE2A404IW-DE3
-
Image Sensor:
-
1/3" progressive scan CMOS
-
Min. Illumination:
-
Color: 0.005 Lux
-
Adjustment Range:
-
2.8 to 12mm, 4x optical zoom
-
Wide Dynamic Range:
-
120 dB
- 1/3" progressive scan CMOS
- Up to 2560 × 1440@25fps resolution
- Min. illumination:
Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR
- 4× optical zoom, 16× digital zoom
- 120 dB WDR, 3D DNR, HLC, EIS, Regional Exposure, Regional Focus
- 12 VDC & PoE
- Up to 20 m IR distance
- IK10, IP66
- Support H.265+/H.265 video compression
| Image Sensor: | 1/3" progressive scan CMOS | |
| Effective Pixels: | 2560(H)×1440(V) | |
| Signal System: | PAL/NTSC | |
| Minimum Illumination: |
Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON) 0 Lux with IR |
|
| White Balance: | Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp | |
| AGC: | Auto/Manual | |
| HLC: | Support | |
| WDR: | 120dB | |
| Shutter Time: |
50Hz: 1/1 s to 1/30,000 s
60Hz: 1/1 s to 1/30,000 s |
|
| Day& Night: | ICR | |
| Digital Zoom: | 16× | |
| Privacy Mask: | 24 programmable privacy masks | |
| Auto Focus: | Auto / Semi-automatic / Manual |
| Lens | ||
|---|---|---|
| Focal Length: | 2.8 to 12mm, 4× optical zoom | |
| Zoom Speed: | Approx. 2s (optical lens, wide-tele) | |
| Field of View: |
Horizontal field of view: 100° to 33° (Wide-Tele)
Vertical field of view: 53° to 18° (Wide-Tele) Diagonal field of view: 119° to 37.5° (Wide-Tele) |
|
| Minimum Working Distance: | 10 to 1500mm (wide-tele) | |
| Aperture Range: | F1.6 to F2.7 | |
| Pan & Tilt | ||
|---|---|---|
| Pan Range: | 0° to 330° | |
| Pan Speed: |
Configurable, from 0.1°/s to 100°/s,
Preset speed: 100°/s |
|
| Tilt Range: | Tilt: 0°~90° | |
| Tilt Speed: |
Configurable, from 0.1°/s to 100°/s
Preset Speed: 100°/s |
|
| Proportional Zoom: | Rotation speed can be adjusted automatically according to zoom multiples | |
| Number of Preset: | 300 | |
| Power-off Memory: | Support | |
| Infrared | ||
|---|---|---|
| IR Distance: | 20m | |
| IR irradiation angle: | Adjustable by zoom | |
| Input & Output | ||
|---|---|---|
| Audio Input: | 1-ch audio input | |
| Audio Output: | 1-ch audio output | |
