Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YiFeng
-
Model Number:
-
YF-12GF-N20
-
Torque:
-
Customised
-
Product Name:
-
Dc Planetary Gear Motor
-
Application:
-
Home Applicance
-
Keywords:
-
low noise small volume Gear Motor
-
Diameter:
-
22mm
-
Power:
-
0.1-5W
-
Motor type:
-
PMDC Brushed Motor
-
Rated Voltage:
-
1.5v 3v 6v 7.4v 12v24vdc
Quick Details
-
Speed(RPM):
-
1-4000rpm
-
Continuous Current(A):
-
Customised
-
Efficiency:
-
IE 1
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YiFeng
-
Model Number:
-
YF-12GF-N20
-
Torque:
-
Customised
-
Product Name:
-
Dc Planetary Gear Motor
-
Application:
-
Home Applicance
-
Keywords:
-
low noise small volume Gear Motor
-
Diameter:
-
22mm
-
Power:
-
0.1-5W
-
Motor type:
-
PMDC Brushed Motor
-
Rated Voltage:
-
1.5v 3v 6v 7.4v 12v24vdc
|
Product type:
|
dc planetary gear motor/dc spur gear motor/dc worm gear motor/ dc square gear motor/BLDC gear motor/
view more...
|
|
|
|
|||
|
Dimension:
|
8mm,10mm,12mm,16mm,20mm, 22mm, 24mm, 25mm, 27mm, 28mm,32mm,36mm,37mm,42mm,48mm,50mm,60mm
|
|
|
|
|||
|
Gear ratio:
|
4.2 ~ 3736
|
|
|
|
|||
|
Power:
|
0.1 W ~ 150 W
|
|
|
|
|||
|
Torque:
|
0.05 kg.cm ~150kg.cm
|
|
|
|
|||
|
Current:
|
0.1A ~ 30A
|
|
|
|
|||
|
Voltage:
|
1.5v, 3v，3.7v，5v，6v, 7.4v，12v, 24v, 36v
|
|
|
|
|||
|
Shaft size：
|
2mm, 3mm, 4mm, 5mm, 6mm, 7mm, 8mm, 10mm
|
|
|
|
|||
|
gearbox material:
|
steel, brass, plastic, powder metallurgy , zinc alloy
|
|
|
|
|||
|
Bearing Type：
|
Ball Bearing, Oil bearing
|
|
|
|
|||
|
Shape of Motor Shaft
|
circular shaft, D shaft, Slotted shaft, Knurled shaft, Square shaft, hexagon shaft, threaded shaft, Shaft with hole
|
|
|
|
|||
|
comments:
|
Specific performance parameters and shaft size can be customized according to customer requirements
|
|
|
|
|||
Details Images
|
Packing & Delivery
|
|
|
|
|
||||
|
the single net weight:
|
85.5 g
|
|
|
|
||||
|
packing qty per carton:
|
156 pcs
|
|
|
|
||||
|
carton size & G.W.:
|
36×25×18.5, 14kg
|
|
|
|
||||
|
package type:
|
Pearl cotton Inside, strong export carton box outside, with pallet, or as the customer's requirements
|
|
|
|
||||
|
lead time:
|
1000 pcs ,15-20 days / 10000 pcs, 25-30 days
|
|
|
|
||||
|
comments:
|
The weight and package size are for reference. The actual package shall prevail
|
|
|
|
||||
