Quick Details
-
Place of Origin:
-
China
-
Brand Name:
-
OEM
-
Model Number:
-
TC-V45
-
Network:
-
4G/3G/2G
-
Battery:
-
600mAh
-
Application:
-
Android/IOS App, Web Platform
-
Feature:
-
GPS Tracking, 4G, Waterproof IP67, Screen, Camera
-
Weight:
-
41g
-
Accuracy:
-
5-15m
-
Frequency 1:
-
FDD Band 1/2/3/5/7/8, TDD Band 38/39/40/41, WCDMA Band 1/2/5/8
-
Frequency 2:
-
FDD Band 1/2/3/4/5/7/8/12/20/28A, WCDMA Band 1/2/5/8
Quick Details
-
Resolution:
-
1920*1080
-
Function:
-
Bluetooth-Enabled
-
Warranty:
-
1 Years
-
Place of Origin:
-
China
-
Brand Name:
-
OEM
-
Model Number:
-
TC-V45
-
Network:
-
4G/3G/2G
-
Battery:
-
600mAh
-
Application:
-
Android/IOS App, Web Platform
-
Feature:
-
GPS Tracking, 4G, Waterproof IP67, Screen, Camera
-
Weight:
-
41g
-
Accuracy:
-
5-15m
-
Frequency 1:
-
FDD Band 1/2/3/5/7/8, TDD Band 38/39/40/41, WCDMA Band 1/2/5/8
-
Frequency 2:
-
FDD Band 1/2/3/4/5/7/8/12/20/28A, WCDMA Band 1/2/5/8
Product Description
4G Mini GSM GPRS Tracking System Hand Held Panic Alarms
4G SOS Panic Button GPS Tracker
Features:
1, Support 4G/3G/2G Network : Stronger signal, wider network cover, faster network speed.
2, Two Way Call : You can not only use this device to track and protect your pets,but also call him back remotely via calling eature.
3, Real Time GPS Tracking : Locate your loved ones anywhere at any time, protect them around the clock.
4, SOS button for emergency alarm and call
5, Camera for photograph
6, 1.3' LCD HD screen
7, GPS+WIFI+LBS Multiple Positioning Modes : the device can automatically recognize the positioning network and switch the
positioning mode automatically, indoors using LBS/WiFi positioning mode while outdoors GPS positioning mode. Accurate real time
tracking & device position data uploading automatically
8, History Locations Tracking(Footprint Record) : Past locations of the GPS device in the latest 3 months will be stored for future
checking, so you can track all the places the GPS holder has been to, easier to find the lost.
9, Electronic Fence Alarm(Geo-fence ) : you can set a safe area( centering around the device) to keep them(such as your kids,
elders, disabled) inside the area; when the GPS holder leaves the safe area, the device will automatically raise an alarm in your
phone application.
10, Low Battery Alarm : when the GPS track is running out of battery power, a low battery alarm will be sent to the application and
monitor number.
11, Listen In : with this feature, you can listen to the device secretly without being heard.
12, Waterproof IP67 : Real water proof device, able to withstand water immersion.
13, Health management : Step counter, sedentary reminder, pill reminder
14, The Mobile Application is compatible with both of Android and IOS system; we offer lifetime application and platform service
for free.
15, Multiple Monitor Platforms : Mobile Application, Web Monitor Platform, WeChat.
16, Long standby time : There are 3 options for data uploading interval : 30 seconds, 10 min, 1 hour. Interval shorter, battery
life longer. With interval of 30 seconds, battery lasting about a 1 day; 10 min, battery lasting about 3 days; 1 hour, battery
lasting about 4-6 days.
17 , You can manage multiple devices at the same time in a manager account via the app and web platform, which is simple and easy.
1, Support 4G/3G/2G Network : Stronger signal, wider network cover, faster network speed.
2, Two Way Call : You can not only use this device to track and protect your pets,but also call him back remotely via calling eature.
3, Real Time GPS Tracking : Locate your loved ones anywhere at any time, protect them around the clock.
4, SOS button for emergency alarm and call
5, Camera for photograph
6, 1.3' LCD HD screen
7, GPS+WIFI+LBS Multiple Positioning Modes : the device can automatically recognize the positioning network and switch the
positioning mode automatically, indoors using LBS/WiFi positioning mode while outdoors GPS positioning mode. Accurate real time
tracking & device position data uploading automatically
8, History Locations Tracking(Footprint Record) : Past locations of the GPS device in the latest 3 months will be stored for future
checking, so you can track all the places the GPS holder has been to, easier to find the lost.
9, Electronic Fence Alarm(Geo-fence ) : you can set a safe area( centering around the device) to keep them(such as your kids,
elders, disabled) inside the area; when the GPS holder leaves the safe area, the device will automatically raise an alarm in your
phone application.
10, Low Battery Alarm : when the GPS track is running out of battery power, a low battery alarm will be sent to the application and
monitor number.
11, Listen In : with this feature, you can listen to the device secretly without being heard.
12, Waterproof IP67 : Real water proof device, able to withstand water immersion.
13, Health management : Step counter, sedentary reminder, pill reminder
14, The Mobile Application is compatible with both of Android and IOS system; we offer lifetime application and platform service
for free.
15, Multiple Monitor Platforms : Mobile Application, Web Monitor Platform, WeChat.
16, Long standby time : There are 3 options for data uploading interval : 30 seconds, 10 min, 1 hour. Interval shorter, battery
life longer. With interval of 30 seconds, battery lasting about a 1 day; 10 min, battery lasting about 3 days; 1 hour, battery
lasting about 4-6 days.
17 , You can manage multiple devices at the same time in a manager account via the app and web platform, which is simple and easy.
Specifications1
1, Structure
|
|
Black, Red |
|
|
|
|
|||||
|
|
One button(power button) |
|
|
|
|
|||||
GPS antenna
|
|
Built-in high sensitivity ceramic antenna
|
|
|
|
|
|||||
GSM antenna
|
|
FPC
|
|
|
|
|
|||||
Battery
|
|
600mAh |
|
|
|
|
|||||
|
|
One slot |
|
|
|
|
2.Hardware
Network
|
|
Version A:
FDD-Band 1/2/3/5/7/8 TDD-Band 38/39/40/41 WCDMA-Band 1/2/5/8,GSM-Band 2/3/5/8 Version B: FDD-Band 1/2/3/4/5/7/8/12/20/28A WCDMA-Band 1/2/5/8, GSM-Band 2/3/5/8 |
|
|
|
|
|||||
GPRS
|
|
Class12 |
|
|
|
|
|||||
GPS singals
|
|
L1,1575.42MHz C/A code |
|
|
|
|
|||||
GPS channels
|
|
20 channels |
|
|
|
|
|||||
GPS Positioning accuracy
|
|
5~15m
|
|
|
|
|
|||||
Accuracy base station location
|
|
100-1000M
|
|
|
|
|
|||||
Minimum standby current
|
|
<0.5 mA |
|
|
|
|
|||||
Average standby current
|
|
<2.5 mA |
|
|
|
|
|||||
Average working current
|
|
<55mA
|
|
|
|
|
|||||
Temperature
|
|
-20~70℃ |
|
|
|
|
|||||
Humidity
|
|
5% to 95% no condensation |
|
|
|
|
|||||
Certification
|
|
CE, ROHS, FCC and etc
|
|
|
|
|
|||||
GPS antenna
|
|
Built-in high sensitivity FPC antenna
|
|
|
|
|
|||||
GSM antenna
|
|
Built-in four frequency PIFA antenna
|
|
|
|
|
|||||
MIC
|
|
Supported
|
|
|
|
|
|||||
Supported OS
|
|
Android 2.3 and above, iOS 5.0 and above |
|
|
|
|
