Quick Details
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Cameo
-
Dimension(L*W*H):
-
535x465x580
-
Weight:
-
52
-
Rated power/speed:
-
11.5HP/3600rpm
-
Type:
-
Single cylinder/Vertical/Four stroke/Air cooled
-
Combustion system:
-
Direct injection
-
Bore*stroke(mm):
-
92x75
-
Displacement(CC):
-
499
-
Enging speed(rpm):
-
3000/3600
-
Starting system:
-
Recoil/ Electric
-
Fuel/lubrication:
-
0#diesel fuel(summer), 10#diesel fuel(winter)/SAE 10W/30
-
Fuel capacity(L):
-
5.5
-
Lubrication capacity(L):
-
1.65
-
Loading Q'TY(20GP/40HQ):
-
228/415
Quick Details
-
Displacement:
-
499CC
-
Emission Standard:
-
EURO 5
-
Power:
-
11.5HP
-
Place of Origin:
-
Chongqing, China
-
Brand Name:
-
Cameo
-
Dimension(L*W*H):
-
535x465x580
-
Weight:
-
52
-
Rated power/speed:
-
11.5HP/3600rpm
-
Type:
-
Single cylinder/Vertical/Four stroke/Air cooled
-
Combustion system:
-
Direct injection
-
Bore*stroke(mm):
-
92x75
-
Displacement(CC):
-
499
-
Enging speed(rpm):
-
3000/3600
-
Starting system:
-
Recoil/ Electric
-
Fuel/lubrication:
-
0#diesel fuel(summer), 10#diesel fuel(winter)/SAE 10W/30
-
Fuel capacity(L):
-
5.5
-
Lubrication capacity(L):
-
1.65
-
Loading Q'TY(20GP/40HQ):
-
228/415
|
Model
|
CP173F/
CP173FE
|
CP178F/
CP178FE
|
CP186FA/
CP186FAE
|
CP188F/
CP188FE
|
|||
|
Type
|
Single cylinder/ Vertical/ 4 stroke/ air cooled
|
|
|
|
|||
|
Combustion system
|
Direct injection
|
Direct injection
|
Direct injection
|
Direct injection
|
|||
|
Bore*stroke(mm)
|
73*59
|
78*62
|
86*72
|
88*75
|
|||
|
Displacement(cc)
|
247
|
296
|
418
|
452
|
|||
|
Engine speed(rpm)
|
3000/3600
|
3000/3600
|
3000/3600
|
3000/3600
|
|||
|
Rated output(hp)
|
5
|
5.5
|
9
|
10
|
|||
|
Starting system
|
Recoil/ Electric
|
Recoil/ Electric
|
Recoil/ Electric
|
Recoil/ Electric
|
|||
|
Fuel/ lubrication(L)
|
0 #diesel fuel(summer), 10 #diesel fuel(winter)/ SAE 10W/30
|
|
|
|
|||
|
Fuel capacity(L)
|
2.5
|
3.5
|
5.5
|
5.5
|
|||
|
Lubrication capacity(L)
|
0.75
|
1.1
|
1.65
|
1.65
|
|||
|
N.W/G.W(kg)
|
26/28
|
28/30
|
48/50
|
48/50
|
|||
|
Dimensions(mm)
|
445*365*465
|
460*380*520
|
520*450*560
|
520*450*560
|
|||
|
Loading Q'TY(20GP/40HQ)
|
402/827
|
341/473
|
228/415
|
228/415
|
|||
|
Model
|
CP192F/
CP192FE
|
CP195F/
CP195FE
|
CP1100F/
CP1100FE
|
CP1105F/
CP1105FE
|
|||
|
Type
|
Single cylinder/ Vertical/ 4 stroke/ air cooled
|
|
|
|
|||
|
Combustion system
|
Direct injection
|
Direct injection
|
Direct injection
|
Direct injection
|
|||
|
Bore*stroke(mm)
|
92*75
|
95*75
|
100*85
|
105*88
|
|||
|
Displacement(cc)
|
499
|
532
|
668
|
762
|
|||
|
Engine speed(rpm)
|
3000/3600
|
3000/3600
|
3000/3600
|
3000/3600
|
|||
|
Rated output(hp)
|
11.5
|
12
|
14
|
17.5
|
|||
|
Starting system
|
Recoil/ Electric
|
Recoil/ Electric
|
Recoil/ Electric
|
Recoil/ Electric
|
|||
|
Fuel/ lubrication(L)
|
0 #diesel fuel(summer), 10 #diesel fuel(winter)/ SAE 10W/30
|
|
|
|
|||
|
Fuel capacity(L)
|
5.5
|
5.5
|
5.5
|
5.5
|
|||
|
Lubrication capacity(L)
|
1.65
|
1.65
|
2.0
|
2.0
|
|||
|
N.W/G.W(kg)
|
50/52
|
50/52
|
59/61
|
59/61
|
|||
|
Dimensions(mm)
|
535*465*580
|
535*465*580
|
510*510*590
|
510*510*590
|
|||
|
Loading Q'TY(20GP/40HQ)
|
228/415
|
192/400
|
175/365
|
175/365
|
|||
Here is brief introduction of Camel Power as below:
* 20 years' experience in general machine industry.
* the company has its own workshop with an area of more than 50000 square meters and more than 200 employees.
* It has five automatic production lines and advanced online inspection equipment, with an annual production capacity of more than
500,000 units.
* Our products have been exported to nearly 100 countries and regions around the world.
* Main products: generator sets, welding machine, water pump, air compressor and other terminal series
* 20 years' experience in general machine industry.
* the company has its own workshop with an area of more than 50000 square meters and more than 200 employees.
* It has five automatic production lines and advanced online inspection equipment, with an annual production capacity of more than
500,000 units.
* Our products have been exported to nearly 100 countries and regions around the world.
* Main products: generator sets, welding machine, water pump, air compressor and other terminal series
