Quick Details
-
Brand Name:
-
RELAK
-
Model Number:
-
RLK-5
-
Output Voltage (V):
-
220
-
Motor type:
-
Brush type
-
Efficiency:
-
80%
-
Material:
-
iron casting
-
Frequency:
-
50/60hz
-
Turbine Inlet diameter:
-
100mm/150mm
-
Weight:
-
140kg
-
Size:
-
60*70*100cm
-
Power:
-
5kw
Quick Details
-
Warranty:
-
1 Year
-
Marketing Type:
-
Hot Product 2023
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
RELAK
-
Model Number:
-
RLK-5
-
Output Voltage (V):
-
220
-
Motor type:
-
Brush type
-
Efficiency:
-
80%
-
Material:
-
iron casting
-
Frequency:
-
50/60hz
-
Turbine Inlet diameter:
-
100mm/150mm
-
Weight:
-
140kg
-
Size:
-
60*70*100cm
-
Power:
-
5kw
5000W Mini Portable Low Water Head Hydroelectric Generator
Characteristics:
1.Turbine and generator are separated, which is more easy to maintain;
2.Unlike vertical turbine, this turbine is horizontal. The turgo turbine is water lubricated, while the radial turbine has a separate oil lubrication system ensuring a more reliable system. The turbine has 2 bearings, generator has 2 bearing, which is more reliable.
3.The axial force is well balanced by axial force balancing device, therefore it is more reliable.
4.The automatic voltage rectifier is installed within induction generator, the voltage and frequency is more stable than permanent magnetic generator.
Specification:
| Power | Water head | Flow Rate | Install pipe diameter | Install Water Head | Weight |
| 3.0kw | 15-70m | 0.003-0.015 m3/s | 50 mm | 40m | 80 kg |
| 10-60m | 0.005-0.017 m3/s | 65 mm | 30m | ||
| 10-50m | 0.008-0.025 m3/s | 80 mm | 20m | ||
| 5.0kw | 10-50m | 0.008-0.025 m3/s | 80 mm | 40m | 140 kg |
| 10-40m | 0.011-0.033 m3/s | 100 mm | 30m | ||
| 10-40m | 0.014-0.042 m3/s | 150 mm | 20m | ||
| 8.0kw | 10-70m | 0.008-0.025 m3/s | 80 mm | 60m | 150 kg |
| 10-70m | 0.011-0.033 m3/s | 100 mm | 45m | ||
| 10-70m | 0.014-0.045 m3/s | 150 mm | 30m | ||
| 10.0kw | 10-70m | 0.011-0.033 m3/s | 100 mm | 60m | 160 kg |
| 10-70m | 0.011-0.033 m3/s | 150 mm | 40m | ||
| 10-70m | 0.015-0.055 m3/s | 150 mm | 30m | ||
| 15kw | 10-100m | 0.015-0.055 m3/s | 150 mm | 50m | 200 kg |
| 10-100m | 0.025-0.11 m3/s | 200 mm | 30m | ||
| 20kw | 10-100m | 0.025-0.11 m3/s | 150 mm | 50m | 220 kg |
| 10-100m | 0.03-0.15 m3/s | 200 mm | 30m | ||
| 30kw | 10-100m | 0.025-0.11 m3/s | 200 mm | 50m | 240 kg |
| 10-100m | 0.03-0.15 m3/s | 250 mm | 30m |
