Quick Details
-
Brand Name:
-
Bamx
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
BX150GY-3
-
Engine:
-
200CC/250CC Single cylinder,Air-Cooled,Four Stroke
-
Color:
-
Red/Black/Blue/Green/Orange Etc.
-
Wheel:
-
Spoke wheel
-
Brake:
-
Front Disc/Drum brake, Rear Disc/Drum brake
-
Fork:
-
Alloy
-
Transmission System:
-
Chain drive
Quick Details
-
Displacement:
-
100-200CC
-
Max. Speed:
-
> 80km/h
-
Motor:
-
Other
-
Brand Name:
-
Bamx
-
Place of Origin:
-
Chongqing, China
-
Model Number:
-
BX150GY-3
-
Engine:
-
200CC/250CC Single cylinder,Air-Cooled,Four Stroke
-
Color:
-
Red/Black/Blue/Green/Orange Etc.
-
Wheel:
-
Spoke wheel
-
Brake:
-
Front Disc/Drum brake, Rear Disc/Drum brake
-
Fork:
-
Alloy
-
Transmission System:
-
Chain drive
Product Introduction
Specification
|
ENGINE
|
|
|
|
Engine Type:
|
Single-cylinder,Oil-cooled, 4-stroke,PR250 six gears
|
|
|
Displacement (ml):
|
249ml
|
|
|
Bore X Stroke (mm):
|
72×61.4
|
|
|
Compression Ratio:
|
9.25:1
|
|
|
Max. Power (kw/r/min)
|
14/8000
|
|
|
Max. Torque (N.m/r/min):
|
18/6500
|
|
|
Max. Speed (Km/h):
|
≥90
|
|
|
Lubrication:
|
Pressure ,splash
|
|
|
Clutch Type:
|
Multiplate wet clutch
|
|
|
Ignition:
|
CDI
|
|
|
Starting System:
|
Electric
|
|
|
Transmission System:
|
Chain drive
|
|
|
CHASSIS
|
|
|
|
Front shock absorber:
|
hydraulic pressure and spring
|
|
|
Rear shock absorber:
|
hydraulic pressure and spring
|
|
|
Chassis structure:
|
Steel tube and steel plate,rhombic structure
|
|
|
Rear fork:
|
Aluminium
|
|
|
Front Brake:
|
Disc/Drum Brake
|
|
|
Rear Brake:
|
Disc/Drum Brake
|
|
|
Front Tire:
|
110/90-17
|
|
|
Rear Tire:
|
140/70-17
|
|
|
Muffler:
|
Double Pipes Muffler
|
|
|
Steering Head Angle:
|
39/41
|
|
|
Wheel rim
|
Spoke
|
|
|
Battery:
|
12V9Ah
|
|
|
DIMENSIONS
|
|
|
|
L X W X H (mm):
|
1820*490*880
|
|
|
Seat Height (mm):
|
845mm
|
|
|
Wheelbase (mm):
|
1380mm
|
|
|
Min. Ground Clearance (mm):
|
160mm
|
|
|
Max. Permissionable Weight (kg):
|
150
|
|
|
Rider Capacity:
|
2 Persons
|
|
|
Dry. Weigth (kg):
|
135
|
|
|
Fuel Tank Capacity (L):
|
15L
|
|
|
Packing Weight (kg):
|
160
|
|
