- Product Details
- {{item.text}}
Quick Details
-
Model Number:
-
ZJ
-
Voltage:
-
110V/220V/380V/440V/480V/575V
-
Power:
-
0.55-60KW
-
Weight:
-
2500 KG
-
Dimension(L*W*H):
-
TBD
-
Processing Types:
-
Liquid with alcohol
-
Applicable in Industries:
-
Wine Alcohol Industry
-
Prodcuts:
-
Vodka ,Wiskey,Rum,Spirit,Gin
-
Material:
-
SS304/SS316L/Red Copper
-
Feeding:
-
Potato, Corn, Barley and Rye as Raw + Water
-
Heating Method:
-
Steam/Hot Oil/Hot Water/Electrical/Briquettes
-
Cooling Method:
-
Chiller/Tap Water /Cooling Tower Water
-
Output:
-
Alcohol
-
Related Words:
-
Vodka Distilling Kit/Vodka Still/Vodka Making Kit
-
Control:
-
PLC Automatic/Manual Control
Quick Details
-
Marketing Type:
-
New Product 2022
-
Place of Origin:
-
Wenzhou,China
-
Brand Name:
-
JOSTON
-
Model Number:
-
ZJ
-
Voltage:
-
110V/220V/380V/440V/480V/575V
-
Power:
-
0.55-60KW
-
Weight:
-
2500 KG
-
Dimension(L*W*H):
-
TBD
-
Processing Types:
-
Liquid with alcohol
-
Applicable in Industries:
-
Wine Alcohol Industry
-
Prodcuts:
-
Vodka ,Wiskey,Rum,Spirit,Gin
-
Material:
-
SS304/SS316L/Red Copper
-
Feeding:
-
Potato, Corn, Barley and Rye as Raw + Water
-
Heating Method:
-
Steam/Hot Oil/Hot Water/Electrical/Briquettes
-
Cooling Method:
-
Chiller/Tap Water /Cooling Tower Water
-
Output:
-
Alcohol
-
Related Words:
-
Vodka Distilling Kit/Vodka Still/Vodka Making Kit
-
Control:
-
PLC Automatic/Manual Control
Video Description
A still is an apparatus for separating substances by distillation. In ancient China, it was generally used in alchemy, making
soju, steaming toilet water and so on. Different uses have different forms and origins.
Red copper has good resistance to acid in wine, in the heating process, copper and butyric acid, caproic acid, caprylic acid,
caproic acid, mallow acid, acid and other forms of insoluble copper salt, so as to remove the acid with bad flavor, can improve the quality of brandy. A distiller made of glass or stainless steel simply cannot achieve the same effect. In addition, copper has good thermal conductivity and is the catalyst for some esterification reactions. T2 red copper is used in all the contact parts of liquor and brandy condensate in the distillation equipment for skin residue produced by our company to ensure the full contact between wine and red copper. T2 red copper up to 99.60% copper content, to ensure the superior performance of the material, the use of its production of distillation equipment distilled brandy mellow taste, full of fragrance, is a high indicator of good brandy. The thermal conductivity of stainless steel is worse than that of copper
soju, steaming toilet water and so on. Different uses have different forms and origins.
Red copper has good resistance to acid in wine, in the heating process, copper and butyric acid, caproic acid, caprylic acid,
caproic acid, mallow acid, acid and other forms of insoluble copper salt, so as to remove the acid with bad flavor, can improve the quality of brandy. A distiller made of glass or stainless steel simply cannot achieve the same effect. In addition, copper has good thermal conductivity and is the catalyst for some esterification reactions. T2 red copper is used in all the contact parts of liquor and brandy condensate in the distillation equipment for skin residue produced by our company to ensure the full contact between wine and red copper. T2 red copper up to 99.60% copper content, to ensure the superior performance of the material, the use of its production of distillation equipment distilled brandy mellow taste, full of fragrance, is a high indicator of good brandy. The thermal conductivity of stainless steel is worse than that of copper
Technical Data Related
Function for the component of the equipment:
Item
|
Material
|
Function
|
Type
|
still pot
|
SS304 ,SS316Land red copper
|
Material/mash distilling
|
Tank/pot
|
Helmet
|
SS304 ,SS316L and Full red copper
|
Improve high quality
|
Ellipse/round type
|
Gin basket
|
glass / red copper
|
Flavour spirits, making Gin
|
Basket, glass
|
Distilling column 16 plate
|
SS304 ,SS316L and Full red copper
|
Distilling alcohol
|
Column
|
Dephlegmator
|
SS304 and SS316L
|
Partial condenser
|
Column
|
Condenser
|
SS304
|
Condensing to alcohol
|
Column
|
Technology data specification
|
|
|
||
Type
|
Volumn
|
Compenent
|
||
Vodka Distiller
|
50-5000L
|
Still pot,helmet,Column,Dephlegmator,Condenser,Pipe system
|
Type
|
Volumn
|
Compenent
|
Whisky Distiller
|
50-5000L
|
Still pot,Swan neck,Condenser,Cip,Pipe system
|
Vodka Distiller
|
50-5000L
|
Still pot,Onion head,Column,Dephlegmater,Condenser,Pipe system
|
Brandy Distiller
|
50-5000L
|
Still pot,Onion head,Column,Dephlegmater,Condenser,Pipe system
|
Rum Distiller
|
50-5000L
|
Still pot,Column,Condenser,Cip,Pipe system
|
Gin Distiller
|
50-5000L
|
Still pot,Column,Gin basket,Condenser,Cip,Pipe system
|
Multi-Function Distiller
|
50-5000L
|
Still pot,Column,Onion head,Dephlegmater,Gin basket,Condenser,Cip,Pipe system,Collecting tank
|
Products Description
Recommend Products
About Us
Service
We have established some overseas agent office to make the after-sales serivce already ,so it can will be service client in fast response .also in our headquarter service team ,there is a expert team which can support client in 7*24 hours .
1. Customer inquiry and consultation (URS documents)
2. Confirmation of treatment plan (DQ documents &PID Drawing)
3.Quotation offer with the technology document (Quotation PI )
4.Engineering and Manufacturing (Production &Quality inspection )
5. Product inspection (FAT documents)
6. Delivery arrangement and loading work (full set Shipment documents)
FAQ
1.What about your factory?
Our factory is located in Wenzhou city ,Zhejiang Province and have more than 15 years experience on machinery making.
2.How will your company control the equipment quality ?
We have a qualified expert team ,we will inspect every production proceed .also Machines will be tested in our plant before shipment .
3.How long the warranty will be?
We provide 1 year warranty for the machine running ,but we will afford whole -life service for the machine .
4.Which kind payment do your company do now ?
We accept Western Union, T/T ,D/P,D/C and irrevocable L/C payable etc.
5.Can we become your distributor in our country?
Yes, we very welcome you! More details will be discussed if you are interested in being our agent.
6.Why we choose "JOSTON "?
1. We enhance the reliability of product's quality and working life .
2. We decrease the consumption cost of the product in the running.
3. We improve research personnel's ability to deliver a creative design;
4. We use leading technologies in our product development and innovation, and thereby increase the competitive advantage of products.
7.Do you supply installation equipment in oversea?
Yes, if need, we can send our engineer to your plant to help you do installation and commission.
8.How can we know the order production status ?
We will arrange the person to take photo or video during manufacturing in every week to make you to know the production status.When goods are finished,we will take detailed photos or video for your checking ,after approve ,then we will arrange shipment .also you can arrange FAT in our plant when the goods is ready here
9.what is kind service do you offer before making order ?
1.according to your company URS ,we will make the design drawing accordingly.
2.after your company approved drawing ,we will make quotation.
3. final we make agreement on payment terms ,delivery time ,package ,shipment etc.
10.how about your company after-sale service ?
1. We provide long-term after-sale service.
2. we can do installation and commission for the equipment in your plant if necessary .
3. Meanwhile, you can call or e-mail us to consult on any relevant question since we have a special line for after-sale service. Alternatively, you can communicate on-line with us to solve any problem.
