Quick Details
-
Panel Size:
-
500x125mm /1.64x0.41ft
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
TGC1.9/TGC2.8/TGC3.9/TGC5.2/TGC7.8/TGC10.4
-
Pixel Pitch:
-
1.9/2.8/3.9/5.2/7.8/10.4mm, 1.9/2.8/3.9/5.2/7.8/10.4mm
-
Product name:
-
Transparente LED Display
-
Transparency:
-
Up to 80%
-
Cabinet Material:
-
CNC Aluminum
-
Refresh Rate (HZ):
-
1,920
-
Module Dimension:
-
500x125mm /1.64x0.41ft
-
Cabinet Dimension:
-
1000x500mm / 3.28x1.64ft
-
Cabinet Weight:
-
5 kg
-
Service Access:
-
Front & Back
-
Viewing Angle (H/V):
-
160/160
-
Input Voltage (AC):
-
100V or 240V
Quick Details
-
Application:
-
Indoor, Semi-outdoor
-
Brand Name:
-
LEDFUL
-
Color:
-
FULL COLOR
-
Panel Size:
-
500x125mm /1.64x0.41ft
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
TGC1.9/TGC2.8/TGC3.9/TGC5.2/TGC7.8/TGC10.4
-
Pixel Pitch:
-
1.9/2.8/3.9/5.2/7.8/10.4mm, 1.9/2.8/3.9/5.2/7.8/10.4mm
-
Product name:
-
Transparente LED Display
-
Transparency:
-
Up to 80%
-
Cabinet Material:
-
CNC Aluminum
-
Refresh Rate (HZ):
-
1,920
-
Module Dimension:
-
500x125mm /1.64x0.41ft
-
Cabinet Dimension:
-
1000x500mm / 3.28x1.64ft
-
Cabinet Weight:
-
5 kg
-
Service Access:
-
Front & Back
-
Viewing Angle (H/V):
-
160/160
-
Input Voltage (AC):
-
100V or 240V
Product Description
Product Paramenters
|
Model
|
TGC1.9
|
TGC2.8
|
TGC3.9
|
TGC3.9
|
TGC5.2
|
||||
|
Pixel Pitch(mm)
|
H1.9-V3.9
|
H2.8-V5.6
|
H3.9-V7.8
|
H3.9-V7.8
|
H5.2-V10.4
|
||||
|
Pixel Matrix Per Sq.m
|
129,024
|
61,952
|
32,768
|
32,768
|
18,432
|
||||
|
Pixel Configuration
|
SMD1515
|
SMD1921
|
SMD1921
|
SMD1921
|
SMD1921
|
||||
|
Brightness (nits)
|
3,000
|
5,500
|
3,500
|
5,500
|
5,500
|
||||
|
Scan
|
1/14
|
1/11
|
1/8
|
1/8
|
1/6
|
||||
|
Cabinet Resolution
|
504x128
|
352x88
|
256x64
|
256x64
|
192x48
|
||||
|
Transparency
|
30%
|
50%
|
70%
|
70%
|
80%
|
||||
|
Power Con. (Max / Avg)
|
800/360w/sq.m
|
800/360w/sq.m
|
400/180w/sq.m
|
800/360w/sq.m
|
800/360w/sq.m
|
||||
|
Module Dimension
|
500x125mm /1.64x0.41ft
|
|
|
|
|
||||
|
Cabinet Dimension
|
1000x500mm / 3.28x1.64ft
|
|
|
|
|
||||
|
Cabinet Material
|
CNC Aluminum
|
|
|
|
|
||||
|
Cabinet Weight
|
5 kg
|
|
|
|
|
||||
|
Service Access
|
Front & Back
|
|
|
|
|
||||
|
Refresh Rate (HZ)
|
1,920
|
|
|
|
|
||||
|
Viewing Angle (H/V)
|
160/160
|
|
|
|
|
||||
|
IP Rate
|
IP24
|
|
|
|
|
||||
|
Operation Temperature
|
-40° 〜45°
|
|
|
|
|
||||
|
Input Voltage (AC)
|
100V or 240V
|
|
|
|
|
||||
|
Model
|
TGC7.8
|
TGC7.8
|
TGC10.4
|
TGC10.4
|
|||
|
Pixel Pitch(mm)
|
H7.8-V7.8
|
H7.8-V7.8
|
H10.4-V10.4
|
H10.4-V10.4
|
|||
|
Pixel Matrix Per Sq.m
|
16,384
|
16,384
|
9,216
|
9,216
|
|||
|
Pixel Configuration
|
SMD1921
|
SMD1921
|
SMD1921
|
SMD1921
|
|||
|
Brightness (nits)
|
3,500
|
5,500
|
3,500
|
5,500
|
|||
|
Scan
|
1/4
|
1/4
|
1/3
|
1/3
|
|||
|
Cabinet Resolution
|
128x64
|
128x64
|
96x48
|
96x48
|
|||
|
Transparency
|
70%
|
70%
|
80%
|
80%
|
|||
|
Power Con. (Max / Avg)
|
400/180w/sq.m
|
800/360w/sq.m
|
400/180w/sq.m
|
800/360w/sq.m
|
|||
|
Module Dimension
|
500x125mm /1.64x0.41ft
|
|
|
|
|||
|
Cabinet Dimension
|
1000x500mm / 3.28x1.64ft
|
|
|
|
|||
|
Cabinet Material
|
CNC Aluminum
|
|
|
|
|||
|
Cabinet Weight
|
5 kg
|
|
|
|
|||
|
Service Access
|
Front & Back
|
|
|
|
|||
|
Refresh Rate (HZ)
|
1,920
|
|
|
|
|||
|
Viewing Angle (H/V)
|
160/160
|
|
|
|
|||
|
IP Rate
|
IP24
|
|
|
|
|||
|
Operation Temperature
|
-40° 〜45°
|
|
|
|
|||
|
Input Voltage (AC)
|
100V or 240V
|
|
|
|
|||
