Quick Details
-
Brand Name:
-
Holykell
-
Model Number:
-
Level Sensor Series
-
Material:
-
stainless steel, 316L stainless steel
-
Mode:
-
submersible level sensor
-
Max level range:
-
500M
-
Output:
-
4-20mA/0-5V/0-10V/RS485/SDI-12
-
Accuracy:
-
0.5%F.S
-
Working temp:
-
-40℃~+80℃
-
Power supply:
-
12-30VDC/7-30VDC/12VDC/5VDC
-
Electronic connection:
-
Directly cable IP68
-
Overload pressure:
-
150%F.S
-
Burst pressure:
-
500%F.S
-
Cable:
-
PE/ PU/ FEP
Quick Details
-
Grade:
-
IP68 waterproof
-
Warranty:
-
18 months
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
Holykell
-
Model Number:
-
Level Sensor Series
-
Material:
-
stainless steel, 316L stainless steel
-
Mode:
-
submersible level sensor
-
Max level range:
-
500M
-
Output:
-
4-20mA/0-5V/0-10V/RS485/SDI-12
-
Accuracy:
-
0.5%F.S
-
Working temp:
-
-40℃~+80℃
-
Power supply:
-
12-30VDC/7-30VDC/12VDC/5VDC
-
Electronic connection:
-
Directly cable IP68
-
Overload pressure:
-
150%F.S
-
Burst pressure:
-
500%F.S
-
Cable:
-
PE/ PU/ FEP
Our Advantages
Product Details
Holykell level sensors offer a comprehensive solution for monitoring and managing liquid levels in industrial tanks, reservoirs, wells, and other containment systems. These sensors are engineered to provide accurate measurements, easy integration, and robust performance in challenging conditions.
Holykell level sensors provide a reliable, accurate, and durable solution for all your liquid level measurement needs, ensuring optimal performance and safety in diverse industrial applications.
Applications:
*Water Treatment Plants: Monitoring water levels in tanks and reservoirs.
*Oil and Gas Industry: Measuring levels of crude oil, refined products, and other fluids.
*Chemical Processing: Managing chemical inventories and processing liquids.
*Food and Beverage: Monitoring levels of ingredients and finished products.
*Pharmaceuticals: Ensuring accurate levels in production processes
.
HPT621 wireless truck fuel tank level monitoring
UE3003 wireless ultrasonic level monitoring
water/fuel tank level monitoring
radar level sensor
Product Parameters
|
Level range
|
0-0.5m…..500m H2O/ 0-0.05 Bar…..50 Bar
|
|
|
|
|
|
|
||||||
|
Overload
|
150% F.S.
|
|
|
|
|
|
|
||||||
|
Burst Pressure
|
500% F.S.
|
|
|
|
|
|
|
||||||
|
Accuracy
|
≤ ±0.5%F.S(Typical); ≤ ±0.25%F.S (by customized) @25 degree C
|
|
|
|
|
|
|
||||||
|
Long-term Stability
|
≤ ±0.1%F.S. of span/year
|
|
|
|
|
|
|
||||||
|
Working Temp.
|
-40℃~80℃(non-corrosive medium)
|
|
|
|
|
|
|
||||||
|
Storage Temp.
|
-40℃~80℃(Nitrile rubber sealing ring); -20℃~80℃(fluororubber rubber sealing ring)
|
|
|
|
|
|
|
||||||
|
Temperature Compensation
|
0℃~80℃
|
|
|
|
|
|
|
||||||
|
Medium compatible
|
Compatible with 316L Stainless Steel
|
|
|
|
|
|
|
||||||
|
Electronic Wire
|
2 Wires
|
|
3 wires
|
|
|
|
4 Wires
|
||||||
|
Output
|
4-20mA
|
4-20mA+Hart
|
0-5V
|
0-10V
|
0.5-4.5V
|
Dual 4-20mA
|
RS485
|
||||||
|
Power Supply
|
7-30Vdc
|
12-30Vdc
|
8-30Vdc
|
13-30Vdc
|
5Vdc
|
12-30Vdc
|
3.5-36Vdc
|
||||||
|
Electronic connection
|
Fixed cable with vented tube and water proof IP68
|
|
|
|
|
|
|
||||||
|
Response time
|
≤10 ms
|
|
|
|
|
|
|
||||||
|
Pressure Type
|
Gauge pressure; Sealed gauge and absolute optional.
|
|
|
|
|
|
|
||||||
|
Cable optional
|
PE Cable（Water Proof）; PU Cable（Oil/Fuel Proof）; FEP Cable（Anti-Corrosive）
|
|
|
|
|
|
|
||||||
Why Choose Holykell
Focus on sensor for harsh environment
Welcome to Holykell - Where Innovation Meets Precision!
As a premier high-tech enterprise , we specialize in crafting industrial measuring instruments including pressure sensors, level sensors, flow meters, and temperature sensors. All will elevate your operations to new heights.
Why choose Holykell? Our track record speaks for itself:
♦The only Alibaba 5-star supplier in the industry
♦5000m2 clean workshop
♦5 advanced production lines
♦120,000+ production capacity
♦On-time delivery ＞99.8%
♦Manufacturing return rate ＜0.05%
♦11 staff R&D team
Experience the expertise of our formidable R&D team and take advantage of our OEM/ODM service . We boast an impressive 20+ patents and hold 18+ quality certifications (CE, ATEX, FCC, ROHS , etc.), and are approved by SGS, TUV, ISO9001, ISO45001, ISO14001, etc.
With export experience to 175+ countries and 30,000+ one-stop solutions under our belt, trust Holykell to be your reliable partner in progress. Join us on this exhilarating journey of innovation, where your success is our ultimate mission. Let Holykell empower your success today!
Price Policy
The displayed price is for reference only
, the actual price will change according to your project needs.
HOLYKELL reserves the right of final interpretation.
Please send us your requirements to get the best quotation!
HOLYKELL reserves the right of final interpretation.
Please send us your requirements to get the best quotation!
FAQ
Q:What kind of products do you offer ?
A:We supply pressure sensor, level sensor, flow meter and digital controllers. Main market is European countries, American, the Middle East and Asia. Certificates are international ones.
Q:Could I get samples?
A:Yes,we have materials in stock to help you to get the samples as soon as we can.
Q:How about the quality of the magnets?
A:We have the certification of ISO, Europe standard ATEX, TUV-CE and ROSH,we could send the certification test of our company to you.
Q:Could you provide me the shortest lead time?
A:We have materials in our stock,if you really need,you can tell us and we will try our best to satisfy you.
Q:Could I visit your factory?
A:Of course,if you need we will help you to visit our factory.
Q: How can I get the quotation or send my inquiry to?
A: Send your inquiry to us by the inquiry from on the right-side or the bottom of this page.
Q. How to order?
A. In order to send you correct solution and best offer, please provide the following information when send inquiry, thanks !
1. What is the process medium? Water, oil or others.
2. Measure range: 0-5m or..?
3. Output signal:4-20mA, RS485 or..?
4. Require quantity?
