Quick Details
-
Brand Name:
-
ACREL
-
Model Number:
-
ADF400L-2S
-
Accuracy Class:
-
0.5s
-
Output Voltage:
-
3*220/380V or 3*57.7/100V
-
Operating Temperature:
-
-20℃~+60℃
-
Dimensions:
-
119.3*72*79.5
-
Electricity measurement:
-
U ,I, P, Q, S, PF, F
-
Display:
-
LCD Digital Display
-
Power Supply:
-
3x220/380V
-
Reference frequency:
-
50Hz
-
Input Current:
-
3x1(6)A,3*10(80)A
-
Input voltage:
-
3*220/380V or 3*57.7/100V
-
Communication:
-
RS485 Modbus RTU
-
Measuring circuit number:
-
10
-
Consumption:
-
≤10W
-
Application:
-
Prepaid System/Property maintennance
Quick Details
-
Phase:
-
Three Phase
-
Measuring Energy Range:
-
0-99999.9kwh
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
ACREL
-
Model Number:
-
ADF400L-2S
-
Accuracy Class:
-
0.5s
-
Output Voltage:
-
3*220/380V or 3*57.7/100V
-
Operating Temperature:
-
-20℃~+60℃
-
Dimensions:
-
119.3*72*79.5
-
Electricity measurement:
-
U ,I, P, Q, S, PF, F
-
Display:
-
LCD Digital Display
-
Power Supply:
-
3x220/380V
-
Reference frequency:
-
50Hz
-
Input Current:
-
3x1(6)A,3*10(80)A
-
Input voltage:
-
3*220/380V or 3*57.7/100V
-
Communication:
-
RS485 Modbus RTU
-
Measuring circuit number:
-
10
-
Consumption:
-
≤10W
-
Application:
-
Prepaid System/Property maintennance
Technical parameters
1.Products measurement type
|
Features
|
Function Description
|
|
Display method
|
LCD（Field）
|
|
Energy metering
|
Active energy metering（Forward and reverse），
Reactive power measurement（Forward and reverse） |
|
Electricity measurement
|
Voltage, current (zero sequence current), power factor, frequency, active power, reactive power, apparent power
|
|
Harmonic function
|
Total harmonic content, sub-harmonic content (2～31 times)
|
|
Three-phase unbalance
|
Voltage and current unbalance
|
|
DI/DO |
Main module 2DI2DO
|
|
|
Transformer access to the slave module 2DI4DO (direct access to the slave module without)
|
|
LED Instructions
|
Pulse light indication
|
|
Communication
|
Infrared communication
|
|
|
RS485 interface (main module) supports MODBUS
|
|
Historical power
|
Historical Electricity in Last December
|
Product Description
Dimensions and wirings
Main module size
Slave module (direct access or transformer access module) size
