Quick Details
-
Specification:
-
4.2V 4000F
-
Packaging Type:
-
Standard packing
-
Application:
-
back-up source
-
Package / Case:
-
aluminum enclosure
-
Series:
-
#
-
Features:
-
#
-
Size / Dimension:
-
#
-
Description:
-
Graphene Super Capacitor
-
Manufacturing Date Code:
-
#
-
Capacitance:
-
4000F
-
Operating Voltage Range:
-
4.2V~3.0V
-
Surge Voltage:
-
4.35V
-
Cut-off discharge voltage:
-
3.0V
-
Rated Charge/Discharge Current:
-
600mA
-
Max. Continuous Discharge Current:
-
6000mA
-
Cycle life Expectancy:
-
1000 cycles at 25 degrees Celsius
-
ESR (1KHz)(m2):
-
Less than or equal to 70
-
Cap.Tolerance:
-
-20%~+20%
-
Operating Temp(°C):
-
-20°C~60°C
-
Applications:
-
Smart instrument, car electronics, Internet of Things, etc
Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
YL
-
Model Number:
-
4.2V 4000F
-
Specification:
-
4.2V 4000F
-
Packaging Type:
-
Standard packing
-
Application:
-
back-up source
-
Package / Case:
-
aluminum enclosure
-
Series:
-
#
-
Features:
-
#
-
Size / Dimension:
-
#
-
Description:
-
Graphene Super Capacitor
-
Manufacturing Date Code:
-
#
-
Capacitance:
-
4000F
-
Operating Voltage Range:
-
4.2V~3.0V
-
Surge Voltage:
-
4.35V
-
Cut-off discharge voltage:
-
3.0V
-
Rated Charge/Discharge Current:
-
600mA
-
Max. Continuous Discharge Current:
-
6000mA
-
Cycle life Expectancy:
-
1000 cycles at 25 degrees Celsius
-
ESR (1KHz)(m2):
-
Less than or equal to 70
-
Cap.Tolerance:
-
-20%~+20%
-
Operating Temp(°C):
-
-20°C~60°C
-
Applications:
-
Smart instrument, car electronics, Internet of Things, etc
Products Overview
|
Part Number
|
4.2V 4000F
|
|
Place of Origin
|
China
|
|
Quality
|
Good Quality
|
|
Port
|
HongKong /Shenzhen
|
|
Packaging
|
Foam + Carton
|
|
MOQ
|
500 pieces
|
|
Condition
|
New
|
|
Delivery Time
|
7-14 days
|
|
Shipping
|
Fast air transprot: UPS; DHL; EMS; TNT and Fedex
|
Advantage
The capacitor is made of low-loss metallized polypropylene film, and the self-healing film is a copper peak base film and a graded square resist film applied by evaporation.
The film is wound into a cylindrical shape by fully automated equipment, and the non-inductive winding product is used.
services
Support customization, according to customer requirements, such as color, packaging, printing, outer diameter, material and other special requirements, provide one-stop service for customized production.
R-yangling has established a complete service system standard and has a complete service system process
