Keyed safety switch prevents accidental starting
12-speed settings to accommodate various materials and thicknesses
Cast iron worktable, height adjustable and bevels up to 45 Degree left & right
Scaled steel fence helps align, guide and brace workpieces, stop block for repetitive drilling jobs
- Product Details
- {{item.text}}
Quick Details
-
Drilling Speed:
-
620-2620/740-3140 r/min
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Millart
-
Model Number:
-
ZJQ4116E
-
Voltage:
-
220v/380v
-
Dimension(L*W*H):
-
700*420*270mm
-
Weight (KG):
-
28 KG
-
Marketing Type:
-
Hot Product 2024
-
Model:
-
ZJQ4116E
-
Motor Power:
-
450W
-
Chuck:
-
16mm
-
Spindle Travel:
-
65mm
-
Spindle Taper:
-
MT2
-
Speed Change:
-
5
-
Speed 50/60Hz:
-
620-2620/740-3140 r/min
-
Swing:
-
260mm
-
Working Table size:
-
200x200mm
-
Base size:
-
340x210mm
Quick Details
-
type:
-
Pillar Drilling Machine
-
Max. Drilling Dia. (mm):
-
16
-
Range of Spindle Speed(r.p.m):
-
620 - 2620 r.p.m
-
Drilling Speed:
-
620-2620/740-3140 r/min
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Millart
-
Model Number:
-
ZJQ4116E
-
Voltage:
-
220v/380v
-
Dimension(L*W*H):
-
700*420*270mm
-
Weight (KG):
-
28 KG
-
Marketing Type:
-
Hot Product 2024
-
Model:
-
ZJQ4116E
-
Motor Power:
-
450W
-
Chuck:
-
16mm
-
Spindle Travel:
-
65mm
-
Spindle Taper:
-
MT2
-
Speed Change:
-
5
-
Speed 50/60Hz:
-
620-2620/740-3140 r/min
-
Swing:
-
260mm
-
Working Table size:
-
200x200mm
-
Base size:
-
340x210mm
Product Description
Feature
Product Paramenters
|
Model
|
ZJQ4116E
|
|
Motor Power
|
450W
|
|
Chuck
|
16mm
|
|
Spindle Travel
|
65mm
|
|
Spindle Taper
|
MT2
|
|
Speed Change
|
5
|
|
Speed 50/60Hz
|
620-2620/740-3140 r/min
|
|
Swing
|
260mm
|
|
Working Table size
|
200x200mm
|
|
Base size
|
340x210mm
|
|
Column diameter
|
58mm
|
|
Total Height
|
880mm
|
|
Weight
|
30/28kg
|
|
Packing Dimensions
|
700x420x270mm
|
Standard Accessories
Drill chuck
Tapper sleeve
Wrench
