Quick Details
-
Driving Mode:
-
DC motor output driving
-
Transmission Mode:
-
Gear drive
-
Travelling Speed:
-
16m/min on average
-
Cleaning Mode:
-
Round-trip/full-cycle cleaning
-
Operating Noise:
-
Less than 60dB
-
Operating Temperature:
-
-40℃~70℃
-
Operating Humidity:
-
0%~95%
Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Model Number:
-
SRC-5/4000
-
Voltage:
-
DC 24V
-
Driving Mode:
-
DC motor output driving
-
Transmission Mode:
-
Gear drive
-
Travelling Speed:
-
16m/min on average
-
Cleaning Mode:
-
Round-trip/full-cycle cleaning
-
Operating Noise:
-
Less than 60dB
-
Operating Temperature:
-
-40℃~70℃
-
Operating Humidity:
-
0%~95%
|
S/N
|
Item
|
Parameters
|
Remarks
|
|
1
|
Operation Method
|
Manual
|
By portable remote controller.
|
|
SCADA
|
Wireless remote communication via gateway and
antenna. RF433MHz Modbus TCP/IP Protocol |
||
|
2
|
Auxiliary
Supporting Structures |
Requiring bridges, docking & return
stations. |
Robot wheels run on panel frame.
Module-to-module clearance is suggested within 20mm, so as to avoid installing bridge connection. |
|
3
|
Cleaning Method
|
Dry cleaning by roller brush
|
Bristle material: Nylon PA6, UV-Resistant.
|
|
4
|
Weight
|
Roughly 67Kg
|
Depend on battery size and battery size/capacity
depends on robot travelling distance. |
|
5
|
Dimension
|
L4000±*W445*H455mm
|
Robot is customized,
*L depends on panel length. |
|
6
|
Voltage
|
DC 24V
|
|
|
7
|
Driving
Mode |
DC motor output driving
|
Two 70W wheel-driven motors.
One 100W brush-driven motor. |
|
8
|
Transmission
Mode |
Gear drive
|
No sprockets and chains inside robot.
|
|
9
|
Power
Supply |
200W
L1580*W676*H40mm
11.3kg
|
Self-charging solar panel is placed on docking
station. Short array will be equipped with 100W panel. |
|
10
|
Travelling
Speed |
16m/min on average
|
|
|
11
|
Travelling
Distance |
Suggest within 2400m(Namely row length 1200m)
|
Depend on battery capacity.
|
|
12
|
Cleaning Mode
|
Round-trip/full-cycle cleaning
|
|
|
13
|
Brush
Rotating Speed |
130RPM
|
|
|
14
|
Operating Noise
|
Less than 60dB
|
|
|
15
|
Operating
Temperature |
-40℃~70℃
|
|
|
16
|
Operating
Humidity |
0%~95%
|
Robot is able to run after rain or in the rain. While
in order to ensure better cleaning effect, robot is suggested to be operated when the panel is dry, or panel is wet after raining. |
|
17
|
Wind
Rating |
26m/s, Grade 10(For normal robot operation; if robot
stops its supporting structures, wind rating can be 45~47m/s.) |
*Different country may have different wind rating
standard. |
|
18
|
IP Level
|
IP65
|
|
|
19
|
Cleaning
Angle |
0~35°
|
*If for tracker, robot only runs while tracker is in
stow position. |
|
20
|
Climbing
Angle |
Suggested less than 15°(Short distance like bridge climbing)
|
|
|
21
|
Cleaning
Frequency |
Max. once per day is suggested
|
Depend on site soling condition.
|
|
22
|
Cleaning
Efficiency |
≥99.5%
|
|
|
23
|
Uptime/
Availability |
≥98.5%
|
The rest 1.5% can be rectified immediately by site
O&M team within the day. |
|
24
|
Environmental
Effect |
Environment-Friendly
|
No trash, no toxic and harmful matter output.
|
|
25
|
Standard
Warranty |
2 Years(From robot acceptance test date.)
|
For complete robot system.
Within warranty period, Sol-Bright provides maintenance services along with spares. |
