touch screen TIJ Thermal batch inkjet Expiry date code printing machine with conveyor on Wood Metal paper box Carton bucket

touch screen TIJ Thermal batch inkjet Expiry date code printing machine with conveyor on Wood Metal paper box Carton bucket

FOB Reference Price: Get Latest Price

≥1 Sets

US $600

≥2 Sets

US $400

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: BOTTLING

Voltage:: Customized

Weight:: 10 KG, Based on the model

Product name:: Code printer

Printing content:: date, time, batch number, class and serial number, etc

Ink color:: black, red, white etc.

Printing speed:: Based on the model

Customized:: Can be fixed on the the conveyor

Automatic grade:: Automatic and semi-automatic

Marketing Type:: New Product 2020

Quick Details

Automatic Grade:: Automatic

Application:: Code printing, Bottle, cup, carton, card, food products etc.

Place of Origin:: Jiangsu

Brand Name:: BOTTLING

Voltage:: Customized

Weight:: 10 KG, Based on the model

Product name:: Code printer

Printing content:: date, time, batch number, class and serial number, etc

Ink color:: black, red, white etc.

Printing speed:: Based on the model

Customized:: Can be fixed on the the conveyor

Automatic grade:: Automatic and semi-automatic

Marketing Type:: New Product 2020

Products Description

Online Ink jet code printer

Technical Specification: 1)Inkjet printing precision: 200 DPI 2)Inkjet print fonts: high-definition inkjet print fonts ( print form) 3)Character: national Primary and Second Chinese character(more than 6000 Chinese characters), seven font (Song typeface,Regular script, Hollow, Bold, Clouds, New Song typeface, Bitmap font) to choose from, pinyin input method. 4)Inkjet print graphics: all sorts of trademark design can be printed, graphic transmission is not affected by length-to-width ratio and length. 5) The number of lines: one to fifteen lines of English Numbers or one to eight lines of Chinese characters can be printed, and the size of the word can be adjusted. This system is dual-purpose. 6) Character height: 1 mm ~ 12.7 mm high word font can be printed 7) Inkjet print distance: nozzle to printing objects 5-10 mm 8) Automatic inkjet printing: date, time, batch number, class and serial number, etc 9) Storage information: 100 messages, 100 graphics can be stored 10) Message length: each message can be up to 200 characters 11) Serial number: Number of Bits 1-8 bits variable sequence number 12) Inkjet printing speed: up to 75 m/min, and inkjet printing speed does not change due to the increase of the number of lines(Capacity reach max around 10000 bottles per hour) 13) Ink color: black, red, white 14) Inkjet print direction: nozzle is rotatable, adjusted to forward, backward and straight down.The program is set to adjust upside down and turn around. 15) Material for inkjet printing: the surface of metal, plastic, wood, aluminum foil, cartons and building materials and so on. 16) Application: such as mobile phone screen, Beverages cap , food packaging bags, medicine boxes, plastics-steel doors and windows, aluminum alloy, batteries, plastic pipe, steel plate, circuit boards, chip, woven bags, eggs, brake pad, phone housings, cartons, motors, transformers, inside dishes of water meter, gypsum board, PCB circuit board, outer packing of explosive, etc. 17) Ink used: environmental protected quickly dry printing ink or oil-based ink, no need to use external gas or diluent 18) External interface: USB, synchronizer, photoelectric sensor, data line 19) The machine size: 34.7 x22x 10 cm 20) Power supply parameters: AC 220 v 21) System power consumption: the average power consumption is less than 100 w 22) Application Environment: temperature (0 ℃ to 40 ℃); humidity(40% to 70%) 23) Status display: spray printing, synchronizer and photoelectric have light display when they are normally working

Handheld Inkjet code printer

1: 4.3-inch color touch screen, easy-to-understand editing interface, easy to operate in 10 minutes 2: Using Samsung quad-core high-speed processor, making your editing operations faster and smoother 3: The use of metal casing is good for heat dissipation, and it is equipped with a 2600 mAh long-life battery for longer working life 4: It adopts the integrated design of original print head and ink cartridge, free of maintenance and maintenance, making printing more worry-free and trouble-free 5: One machine with five systems, powerful operation page, to meet the requirements of different customers at home and abroad 6: Added one-key detection function of the whole machine, display of ink cartridge usage, main board data and other functions Can be printed with dot matrix characters, Chinese, English, graphics, QR codes, numbers, dates, serial numbers, etc.Can be printed with cardboard boxes, plastic films, bottle caps, PVC pipes, tin boxes, bottle surfaces, etc.

Shape features	stainless steel casing/black aluminum shell and color touch screen
Dimension	130128200mm
Net weight	1.18kg
Printing direction	adjusted within 360 degree, meet all kinds of production needs
Character type	high-definition printing character, dot matrix font, Simplified, Traditional Chinese and English
Printing pictures	all kinds of logo, pictures can be uploaded through USB disk
Printing accuracy	600DPI
Printing line	1-8 lines (adjustable)
Printing height	1.2mm-12.7mm
Print code	bar code, QR Code
Printing distance	1-10mm Mechanical Adjustment (the best distance between the nozzle and printed object is 2-5mm)
Print serial number	1~9
Automatic print	date, time, batch number shift and serial number, etc
Storage	the system can store more than 1000 mass (external USB make the information transfer in a free way)
Message length	2000characters for each message, no limitation on length
Printing speed	70m/min
Ink type	Quick-dry environmental ink, water-based ink and oily ink
Ink color	black, white, red, blue, yellow, green, invisible
Ink volume	42ml(usually can print 100,000 characters)
External interface	USB, DB9, DB15, Photoelectric interface, can directly insert a USB disk to upload information
Voltage	DC16.8 lithium battery, print continuously more than 10 hours and 20 hours standby
Control panel	touch-screen (can connect wireless mouse, can also edit information through the computer)
Power consumption	the average power consumption is lower than 5W
Working environment	Temperature:0 - 38 degree; Humidity: 10% - 80%
Printing material	board, carton, stone, pipe, cable, metal, plastic product, electronic, the fiber board, light steel keel, aluminum foil, etc.

CO2 laser flying code printer / marking machine

CO2 Laser Printer is designed for production line nonmetal materials marking and some plastic PET bottles and glass bottle marking. For example, drinks expiry date printing, we will install a sensor to give signals back to the laser machine when PET bottles pass by, then start to mark. It can continue to work in a very fast speed. One hour for CO2 Laser Printer can be 10000-20000 bottles. The machine can also marking the objects by meters, we will just fix a length counter. The lifetime can reach 30,000 hours. During the marking process, it won’t cause any consumables, compared to the ink jet printer, it is cost-saving and economical.

Characters: •Use air cooling system, with long time continuous working ability. •The laser power is 15W 30W etc. which can print Chinese, English and patterns clearly, and can meet the requirements of printing all similar products by only one machine. •High efficiency laser, high-speed galvanometer scanning system and control software, with high speed, good light output mode, stable performance and high system configuration. •Fully enclosed optical path system can better protect optical devices from external environment. •The stable and portable lifting mechanism of the main beam can adapt to different positions and shapes of product in different lines. •Using professional optical fiber probe, no gap printing and no missing printing. •Equipped with a smoke extraction device, which can quickly exhaust the smoke and dust generated by code printing and protect the environment of the printing area (optional). •Chinese and English operation interface, Standard keyboard, mouse operation, equipment with standard expansion interface, convenient hardware expansion.

Laser type	Metal tube carbon dioxide laser
Laser power	30W
Laser head	Length: 750mm Width: 160mm Height: 180mm
Whole machine Power	800W
Print line speed	≤150m/min
Number of flight mark lines	10X 10
Minimum line width	0.15mm
Minimum character	0.40mm
Repeating accuracy	±0.01mm
Laser wave length	10.6µm
Divergence angle miliradian	7.5mrad
Fastest printing line speed	7000mm/s
Number of characters printed per second	1200bps
Focal length	120mm
Rows	Any rows
Character height	0.5~100mm
Print information	Line height 0.5-100mm,Max 300mm
Print range	90*300mm
Cooling way	Air cooling
Environment literature	5-45℃
Environment humidity	90% non-condensing
Print content	English letter,Arabic numerals and patterns
Optimal print interval	≥1mm
Power Supply	Ac 110V-220V/50HZ,5A
Humidity	10%-90%
Communication interface	USB,RS232/485,Ethernet
Protection degree	IP54
Detection settings	Photoelectric sensor,PNP/12V
Size and weight:	Laser head 850170195mm 25KG Laser bracket 1500600580mm 22KG Controller 27521030mm 2KG

VEDIO JET Inkjet Code Printer

Designed for low duty applications, the Videojet 1210 continuous inkjet printer is the perfect variable data printing machine to fulfill applications that involve printing codes 8 to 10 hours per day / 5 days a week. The printer is engineered to keep your line up and running longer. Vedio jet 1210 is designed for customers with simple coding needs like date printing and is ideal for the food, beverage, chemical, pharmaceutical and personal care/cosmetics industries.

Characteristics: Speed without compromising quality: Ideal solution for a range of slow to moderate speed applications: Single line maximum speed of 162 m/min (533 ft/min) Two line maximum speed of 59 m/min (194 ft/min) Three line maximum speed of 29 m/min (96 ft/min) Store up to 100 complex messages for easy recall. Store even more messages using a standard USB memory stick Small and portable, the 1210 is easily moved from line to line with minimal connections Engineered to keep your line running: Vedio jet’s advanced core technology includes all ink system filters and common wear parts Intervals of up to 6,000 hours between preventative maintenance Auto cleaning print head for fast start-ups, even after extended shutdowns Optional internal air pump eliminates need for external air, minimizing potential for contaminants to enter the ink stream No mess, no waste fluid delivery: Advanced fluid management reduces makeup consumption to as low as 2.4 ml/hr Smart Cartridge TM fluid delivery system to virtually eliminate spills and help ensure the correct fluids are being used Simple Usability via Vedio jet standard CIJ interface: Bright display with WYSIWYG and function keys for easy operation User levels to separate operation from installation and maintenance Prompted user fields to help reduce errors

Specification	Value
Print heads	1
Inks	Dye Based
Maximum Lines of Print	3
Maximum Line Speed	162.5 m/min (533 ft/min) Capacity reach max around 25000 bottles per hour
Environmental Protection	IP55
Core Life (Maintenance Interval)	Up to 6000 hours
Umbilical Length	6.56ft (2 m)
Message Storage Capability	100
Smart Cartridge™	Included
Plug and Play Print head Modules	–
USB	Included
Communications	RS-232 Serial
Positive Air	Included
Expanded I/O Ports and Control	#
Display (User Interface)	LCD with membrane keyboard
Support language	English(US),English (UK),French,German,Spanish,Portuguese Brazilian,Japanese,Russian,Italian,Dutch,Chinese Simplified,Chinese (Traditional),Arabic,Korean,Thai,Norwegian,Finnish,Swedish,Danish,Greek,Hebrew,Polish,Turkish,Czech,Hungarian,Vietnamese,Bulgarian,Portuguese,

Solid Ink Roll Coding Machine

The use of photoelectric integration technology, advanced solid ink wheel, has the excellent performance of instant printing and instant dry, which is not easy to erase. The machine is advanced in design, precise in manufacturing, stable in operation, longitudinally controlled in position by electronic control, arbitrarily adjustable, photoelectrically controlled printing actions and counts, and the number of printable sheets can be set. Applicable to the surface indentation or color printing production date, product batch number, expiration date, inspection qualification, etc. of paper boxes, labels, tags, certifications, etc., with automatic sorting, automatic counting, random positioning, preset printing times, Indentation is clear, color is optional, printing speed is fast, instantaneous printing instant dry, loss and other advantages.

Performance and Features: Feature applies to the T-type or T-type arrangement of dualmarking round, T-1-11 rows 1-10 lines / characters : R-type 1-8 OK , 1-8 word / line . Word grain specifications are 2mm , 2.5mm , 3mm available. Tags can be printed on paper , cardboard and plastic film , aluminum foil. The machine automatic , high speed , high efficiency , maximum printed 300 per minute.

Model	BL-380F
Voltage	AC 220/50V 110/60HZ
Power	180W
Solid Ink Roller	35*32MM
Printing Speed	≤300Pcs/min
Object Size	L: 50-500mm W: 30-190mm
Max Printing Line	T type(10.5PT):11Lines(Max.10 Types/Line) R Type(10.5PT):8 Lines(Max.8Types/Line)
Printing Size	Within 60 - 250mm
Type Size	21.5mm(8PT) 2.52mm(9PT) 33mm(10.5PT) 42.5mm(18PT)
Net Weight	23kg
Dimension	440345300mm

Manual press ribbon code printer

The manual ribbon date coding machine adopts the high quality materials, the superb copper alloy and stainless steel, with compact and reasonable structure, beautiful appearance, small and exquisite. It introduces the international latest thermal printing ribbon, which can replace the oil ink and can print out the clear words on any soft packing material and paper, trademark and small paper box, without toxin and pollution, convenient words replacing, The machine is widely used in food and pharmaceutical industries.

Speed:	10-80 TIMES/MIN
Voltage:	220V 50/60Hz
Heating pipe:	24-100W
Print row number:	Can print 1-3 rows
Number of print lines:	One row can hold 14 characters
Letter:	2*4mm
Preheat time:	5-10MIN
Working temperature:	0-200℃
Dimension:	240240140mm
Weight:	2.6KG
Requirements for printed matter: the product material is soft, not hard material, and the final printed matter cannot exceed 4mm

All modes of our code printers, Let me know which model you like……

Online inkjet code printer

Handhold code printer

Laser code printer

VEDIO JET Inkjet Code Printer

Solid Ink Roll Coding Machine

Manual press ribbon code printer

company profile

ZhangJiaGang City BOTTLING MACHINERY Co.,Ltd. is located in Zhangjiagang city which is core of beverage machinery producer collection in China. Integrated the industry advantages and its own development in R&D, production, sales, after sales service,
BOTTLING MACHINERY is ready to serve more and more customers with our full range products and best service.BOTTLING MACHINERY is very critical in the choice of raw materials and spare parts. Korea 304 /316 stainless steel plate, ABB, SEW motors, Siemens, Mitsubishi, OMRON electrical control components, FESTO CAMOZZ the control valve, as well as international precision machining center for the fine quality of the machine foundation.

We are the supplier who can design and manufacture for all kinds beverage production plant (pure drinking water, mineral water,carbonated drinks, juice, tea and beer, etc.)

Customer's service:
1. ZhangJiaGang City BOTTLING MACHINERY Co.,Ltd. can provide turn-key project for you, we can design the beverage factory plan according to your idea.
2. BOTTLING MACHINERY company have professional design team, our engineers can draw bottle samples and flow chart of workshop for you .
3. BOTTLING MACHINERY company can give you the best quotation for all kinds of beverage production, as long as you tell us which kind of drink you want to produce, what is your capacity(how many bottles one hour) what is you bottle material, pet or glass bottle or can, etc.

After service:
1. We send our engineers to your factory to help installing, commissioning and training, the engineers start from our factory area.
2. We supply below necessary documents with the goods shipping to you:
a. Machines layout drawing.
b. Electricity diagram.
c. Machine certificate.
d. General manual book/maintenance book.
3. After one year guarantee, the seller provides payable spare parts and technician's VISITING maintenance service.

Packing&Delivery of BOTTLING

1. Our machines are packed by wooden case. 2. The delivery date of this machine is within 10-25 days after payment.

FAQ

Q:Are you a manufacturer or trade company? A:We are a manufacturer in beverage bottling machine field more than 10 years, located at Leyu town, ZhangJiaGang, 2 hours from Shanghai, We will pick you up from Shanghai Pudong Airport to visit our factory. Q:Do you have any certification? A:SGS,ISO,CE etc Q:What about the delivery time? A:Usually 20-30 Working days for most kinds of machines Q:What about the machine’s capacity? A:1000 - 20000 bottles per hour based on 500ml bottle. Q:The after-sale service A:12 months warranty.

We can solve basic questions by telephone, email, whatsapp, wechat and video call. Engineer will go to buyer's factory to install, test machines, and train buyer's staff how to operate, maintain machines. Operating manuals will be sent with machines or by email. We also have overseas service center Q:If our bottle size changes, can we just do some adjustment on machine according to our new bottle? A:Yes. Maybe you just need some spare little parts to change. Q: If I want to purchase the machine, what information do I need to tell you? A:a. What kind beverage you want to produce? b. bottle volume? 250ml, 330ml, 500ml, 750ml, etc.? c. Producing capacity requirement? How many bottles per hour? d.Raw water analysis report . e.Voltage and altitude. Q:What kinds of product you supply? A: Drink water/juice/carbonated drink filling line for bottle or can. 5 gallon/20L bottle water filling line. Water treatment system. Bottle blowing molding machine.

After packing system(label machine, PE film shrink packing machine, carton machine)

Sachet water packing line
