Quick Details
Quick Details
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
UE
-
Model Number:
-
UE-DCG-300/1000
Product Description
Product Parameters
|
Model
|
UE-DCG-300
|
UE-DCG-1000
|
|
Applicable motorcycle type
|
For 2 wheels
|
For 2&3 wheels
|
|
Max. axle load（kg）
|
300
|
750
|
|
Axle Distance（mm）
|
850-1500
|
850-2700
|
|
Wheel base（mm）
|
\
|
250-700
|
|
Range of engine capacity（cc）
|
50cc-650cc
|
50cc-650cc
|
|
Min. height from floor（mm）
|
90
|
70
|
|
Max. testing speed（km/h）
|
120
|
120
|
|
Max. absorption power of eddy current（KW）
|
160
|
160
|
|
Measurable rated torque（NM）
|
1600
|
1600
|
|
Motor Power（kw）
|
3
|
3
|
|
Clamping Method
|
Pneumatic centering
|
Pneumatic centering
|
|
Clamping Range（mm）
|
50-230
|
50-260
|
Features
1.Designed and manufactured using only the highest quality materials and components. 2.The rugged design of the power absorption system also ensures long service life in the most demanding test environments 3.Which can do constant speed test (Customizable test point); constant drive power test (Customizable test point); vehicle speedometer calibration; acceleration time test; coasting time and distance test; starting acceleration test; exceeding acceleration test; climbing performance test, etc. 4.The user can connect the motorcycle ECU to analyze the driving performance, structural design and other relevant data of the motorcycle under the working condition created by the dynamometer 5.Double safety insurance mechanism to ensure the safety of test. With self-protection function, emergency stop and software over limit protection 6.All real-time data during detection can be saved 10 times per second 7.It has a variety of emission test functions 8.Equipped with automatic cooling system, i.e. axial flow fan, which can be controlled automatically, manually or separately
