Quick Details
-
Jacket:
-
XLPE
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Slocable
-
Model Number:
-
CA206B -- EN solar cable
-
Product Name:
-
Slocable
-
Approved of Slocable:
-
CE TUV
-
Insulation Material of Slocable:
-
XLPE
-
Wire of Slocable:
-
Copper (Class5, tinned)
-
Rated Current of Slocable:
-
70A
-
Rated Voltage of Slocable:
-
DC1500V/1000V
-
Smallest Permissible Bending Radius:
-
5*D
-
Temperature Range of Slocable:
-
-40℃ ~ +90℃ (Max 120℃)
-
Flame Test According to:
-
DIN EN 50265-2-1/V0
-
Colours of Slocable:
-
Black
Quick Details
-
Insulation Material:
-
Xlpe
-
Application:
-
solar, pv energy system
-
Conductor Material:
-
Copper
-
Jacket:
-
XLPE
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Slocable
-
Model Number:
-
CA206B -- EN solar cable
-
Product Name:
-
Slocable
-
Approved of Slocable:
-
CE TUV
-
Insulation Material of Slocable:
-
XLPE
-
Wire of Slocable:
-
Copper (Class5, tinned)
-
Rated Current of Slocable:
-
70A
-
Rated Voltage of Slocable:
-
DC1500V/1000V
-
Smallest Permissible Bending Radius:
-
5*D
-
Temperature Range of Slocable:
-
-40℃ ~ +90℃ (Max 120℃)
-
Flame Test According to:
-
DIN EN 50265-2-1/V0
-
Colours of Slocable:
-
Black
Products Description
|
Specifications
|
Cross Section
|
Conductor Diameter
|
External Diameter
|
Max DC Resistance
|
Rated Current
|
|
1x2.5mm²
|
2.5mm²
|
2mm
|
5.1mm±0.2
|
8.21Ω/km
|
30A
|
|
1x4.0mm²
|
4.0mm²
|
2.5mm
|
5.6mm±0.2
|
5.09Ω/km
|
50A
|
|
1x6.0mm²
|
6.0mm²
|
3.2mm
|
6.3mm±0.2
|
3.39Ω/km
|
70A
|
|
1x10.0mm²
|
10.0mm²
|
4mm
|
7.2mm±0.2
|
1.95Ω/km
|
95A
|
|
1x16.0mm²
|
16.0mm²
|
5.5mm
|
8.5mm±0.2
|
1.24Ω/km
|
132A
|
|
1x25.0mm²
|
25.0mm²
|
6.5mm
|
9.5mm±0.2
|
0.795Ω/km
|
176A
|
|
1x35.0mm²
|
35.0mm²
|
7.7mm
|
11.1mm±0.2
|
0.565Ω/km
|
218A
|
|
1x50.0mm²
|
50.0mm²
|
9.5mm
|
13.5mm±0.2
|
0.393Ω/km
|
280A
|
Advantage of PV Cable
·
Dual wall insulation. Electron beam cross-linked.
· Resistance to UV, water, ozone, fluids, salt, general weathering.
· Resistance to UV, water, ozone, fluids, salt, general weathering.
· Halogen free, flame, retardant, low toxicity.
· Flexibility and stripping performance.
· TUV, CE, IEC approved.
· High voltage and high current carrying capacity.
· Resistance to abrasion.
· Flexibility and stripping performance.
· TUV, CE, IEC approved.
· High voltage and high current carrying capacity.
· Resistance to abrasion.
Technical Data
|
Conductor: 99.99% copper, tinned
|
UV resistance: EN60811-501
|
|
Insulation material: XLPE(XLPO)
|
High voltage and High current
|
|
Double walls insulation
|
Temperature range: -40°C ~ +85°C
|
|
Halogen-free material: EN50525-1
|
Color: Black/Red/Blue/Brown/Grey/Yellow
|
|
OEM & ODM can be accepted
|
Smallest permissible bending radius:
5 x D
|
|
Flame test: EN60332-1-2
|
Smoke density: EN61034-2
|
|
Ozone resistance: EN50396
|
Oil resistance: EN60811
|
