Quick Details
-
Brand Name:
-
SOFTEL
-
Use:
-
10GBASE-ZR/ZW
-
Warranty Time:
-
12 Month
-
Operating case temperature:
-
0 to 70°C
-
Transmission Distance:
-
80km
-
Coupled fiber:
-
Single mode fiber
-
Certification:
-
RoHS
-
Power supply:
-
Single 3.3V
-
Power dissipation:
-
< 1.5 W
Quick Details
-
Type:
-
Fiber Optic Transceivers
-
Model Number:
-
10GBase-ZX SFP
-
Place of Origin:
-
Zhejiang,China
-
Brand Name:
-
SOFTEL
-
Use:
-
10GBASE-ZR/ZW
-
Warranty Time:
-
12 Month
-
Operating case temperature:
-
0 to 70°C
-
Transmission Distance:
-
80km
-
Coupled fiber:
-
Single mode fiber
-
Certification:
-
RoHS
-
Power supply:
-
Single 3.3V
-
Power dissipation:
-
< 1.5 W
Products Description
PRODUCT FEATURES
Up to 11.1Gbps Data Links
Up to 80km transmission on SMF
EML transmitter and APD receiver
Metal enclosure, for lower EMI
2-wire interface with integrated Digital Diagnostic monitoring
Hot-pluggable SFP+ footprint
Specifications compliant with SFF 8472
Compliant with SFP+ MSA with LC connector
Single 3.3V power supply
Case operating temperature range:0°C to 70°C
Power dissipation < 1.5 W
APPLICATIONS
10GBASE-ZR/ZW
STANDARD
Compliant to SFF-8431
Compliant to SFF 8472
RoHS Compliant.
PRODUCT DESCRIPTION
SFP+ transceiver FYPP5596-80BD is designed for use in 10-Gigabit Ethernet links up to 80km over single mode fiber. The
module consists of 1550 EML Laser, APD and Preamplifier in a high-integrated optical sub-assembly. Digital diagnostics
functions are available via a 2-wire serial interface, as specified in SFF8472. The module data link up to 80km in 9/125um
single mode fiber.
Up to 11.1Gbps Data Links
Up to 80km transmission on SMF
EML transmitter and APD receiver
Metal enclosure, for lower EMI
2-wire interface with integrated Digital Diagnostic monitoring
Hot-pluggable SFP+ footprint
Specifications compliant with SFF 8472
Compliant with SFP+ MSA with LC connector
Single 3.3V power supply
Case operating temperature range:0°C to 70°C
Power dissipation < 1.5 W
APPLICATIONS
10GBASE-ZR/ZW
STANDARD
Compliant to SFF-8431
Compliant to SFF 8472
RoHS Compliant.
PRODUCT DESCRIPTION
SFP+ transceiver FYPP5596-80BD is designed for use in 10-Gigabit Ethernet links up to 80km over single mode fiber. The
module consists of 1550 EML Laser, APD and Preamplifier in a high-integrated optical sub-assembly. Digital diagnostics
functions are available via a 2-wire serial interface, as specified in SFF8472. The module data link up to 80km in 9/125um
single mode fiber.
|
Absolute Maximum Ratings
|
|
|
|
|
||||
|
Parameter
|
Symbol
|
Min
|
Max
|
Unit
|
||||
|
Storage Temperature
|
TS
|
-40
|
85
|
°C
|
||||
|
Operating Case Temperature
|
Tc
|
0
|
70
|
°C
|
||||
|
Relative Humidity
|
RH
|
5
|
95
|
%
|
||||
|
Power Supply Voltage
|
VCC
|
-0.3
|
4
|
V
|
||||
|
Signal Input Voltage
|
|
VCC-0.3
|
VCC+0.3
|
V
|
||||
FAQ
1. What are the payment terms that you support?
Usually, we accept T/T PayPal, Western Union, and Alibaba Trade Assurance. You can select the termsof payment which is more convenient for you.
2. What about the lead time?
Usually, if there's stock, we ship the goods within 3-5 working days after the deposit is confirmed. lf it isout of stock. the lead time depends.
3.How about the shipping?
When the package is small, we normally choose FedEx, DHL, TNT, and UPS and so on, while the goodshave high weight and volume, we suggest using air or sea shipment.
4. How can I place an order?
(1) Negotiation is agreed upon for the product price and specifications.
(2) The Proforma invoice will be sent for confirmation.
(3)After the agreement on the proforma invoice, the customer makes the deposit
(4) Manufacturing will be started as soon as the payment is confirmed by our bank
(5) Ship out the goods within the agreed delivery deadline.
5.Can you do OEM for us?
Yes. If there is a certain order quantity, we can do OEM including printing, logo, and customized model for you.
6.How about the Warranty?
There are 12 months for the warranty. While the warranty is not responsible for those broken by violence or updated with other brands.
