- Product Details
- {{item.text}}
Quick Details
-
Function:
-
0-15V battery product
-
Model Number:
-
C-01
-
Input voltage and current:
-
100-240V
-
output voltage and current:
-
12V 40A
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Lifepo4 pack charger
-
Application:
-
Motorcycle, Golf cart, Forklift, Electric Vehicle E-bike Scooter,
-
Output Voltage:
-
0-15V, 12V, 12.8V, 14.6V
-
Output Current:
-
40A, 60A, 85A, 100A
-
Keywords 1:
-
Iron Phosphate Battery Charger
-
Keywords 2:
-
Lifepo4 Pack Charger
-
Keywords 3:
-
Iron Phosphate Battery Charger for 12.8V 14.6V 4S RV Bike Car
-
Feature:
-
Super fast charge for most types of batteries
-
Use for:
-
Lifepo4 battery, 18650 battery, lithium battery, lead acid battery
-
Connection line:
-
Clip and Anderson lines available
Quick Details
-
Type:
-
Electric, Power Supply Adapter, Fast Charger
-
Port:
-
DC
-
Material:
-
Aluminum
-
Function:
-
0-15V battery product
-
Model Number:
-
C-01
-
Input voltage and current:
-
100-240V
-
output voltage and current:
-
12V 40A
-
Place of Origin:
-
Guangdong, China
-
Product Name:
-
Lifepo4 pack charger
-
Application:
-
Motorcycle, Golf cart, Forklift, Electric Vehicle E-bike Scooter,
-
Output Voltage:
-
0-15V, 12V, 12.8V, 14.6V
-
Output Current:
-
40A, 60A, 85A, 100A
-
Keywords 1:
-
Iron Phosphate Battery Charger
-
Keywords 2:
-
Lifepo4 Pack Charger
-
Keywords 3:
-
Iron Phosphate Battery Charger for 12.8V 14.6V 4S RV Bike Car
-
Feature:
-
Super fast charge for most types of batteries
-
Use for:
-
Lifepo4 battery, 18650 battery, lithium battery, lead acid battery
-
Connection line:
-
Clip and Anderson lines available
Specification
|
Type:
|
Solar Battery charger, Lifepo4 Pack Charger, Pulse repair battery charger
|
|
Protection:
|
Short Circuit Protection, Over-charging, Overcurrent, Overvoltage
|
|
Function:
|
0-15V battery product
|
|
Input voltage and current:
|
100-240V
|
|
output voltage and current:
|
12V, 12.8V, 14.6V/ 40A, 50A, 60A, 85A, 100A
|
|
Product Name:
|
Solar Battery charger
|
|
Application:
|
Motorcycle, Golf cart, Forklift, Electric Vehicle E-bike Scooter,
|
|
Output Voltage:
|
0-15V, 12V, 12.8V, 14.6V
|
|
Output Current:
|
40A, 60A, 85A, 100A
|
|
Keywords 1:
|
Solar Battery charger
|
|
Keywords 2:
|
Lifepo4 Pack Charger
|
|
Keywords 3:
|
Pulse repair battery charger
|
|
Feature:
|
Super fast charge for most types of batteries
|
|
Use for:
|
Lifepo4 battery, 18650 battery, lithium battery, lead acid battery
|
|
Connection line:
|
Clip and Anderson lines available
|
Use guides
Detail instructions:
Step1: Do not connect the battery to the charger, turn on the power, adjust the voltage knob to adjust the voltage, refer to the voltage display at the top of the display, (4S lifepo4 battery 3.65 v*4=14.6V, 3S lithium battery 4.2v *3=12.6V), adjust to the voltage you need (you can adjust the voltage in combination with a multimeter. The display will have a small error.).
Step2: Adjust the current to the minimum. After connecting the battery, adjust the current from small to large to the current you need. (It is not allowed to adjust the voltage knob again during the charging process, otherwise there will be overcharge or undercharge, which may burn the host) If the voltage is displayed and the current becomes zero, it means that it is fully charged.
Step3: When using it later (the voltage has been set for the first time, no need to set it later) ------- connect the battery first (very important, it can protect the charger) ------- then connect the power supply- ---------Follow this step for later use,
no need to adjust the voltage and current (unless you want to modify it)
Do not adjust the charger voltage while charging. The voltage of the charger itself fluctuates, and it is normal to charge the
battery with constant voltage. When the battery is fully charged, the current on the charger display will show zero or near zero.
Step1: Do not connect the battery to the charger, turn on the power, adjust the voltage knob to adjust the voltage, refer to the voltage display at the top of the display, (4S lifepo4 battery 3.65 v*4=14.6V, 3S lithium battery 4.2v *3=12.6V), adjust to the voltage you need (you can adjust the voltage in combination with a multimeter. The display will have a small error.).
Step2: Adjust the current to the minimum. After connecting the battery, adjust the current from small to large to the current you need. (It is not allowed to adjust the voltage knob again during the charging process, otherwise there will be overcharge or undercharge, which may burn the host) If the voltage is displayed and the current becomes zero, it means that it is fully charged.
Step3: When using it later (the voltage has been set for the first time, no need to set it later) ------- connect the battery first (very important, it can protect the charger) ------- then connect the power supply- ---------Follow this step for later use,
no need to adjust the voltage and current (unless you want to modify it)
Do not adjust the charger voltage while charging. The voltage of the charger itself fluctuates, and it is normal to charge the
battery with constant voltage. When the battery is fully charged, the current on the charger display will show zero or near zero.
If you do not understand, please consult customer service!
To extend the life of the charger. The charger has a voltage of 220V, and the maximum recommended current is 90%, for example, 60A. It is most suitable to adjust it to about 54A. The maximum recommended voltage and current of 110V is 80%, and the maximum recommended voltage and current of 100V is 70%.
To extend the life of the charger. The charger has a voltage of 220V, and the maximum recommended current is 90%, for example, 60A. It is most suitable to adjust it to about 54A. The maximum recommended voltage and current of 110V is 80%, and the maximum recommended voltage and current of 100V is 70%.
Product Description
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
