1. The casting structure is stable, reasonable and beautiful. The cast iron of our company is cast with HD250 grade, which has time aging and annealing aging to ensure that the cast iron body is stable and not deformed and durable.
2. The main parts of the fuselage are the first and second configuration parts imported from the same industry: for example: the guide rails are precision grade guide rails from Taiwan Shangyin or Yintai or ABBA; the screw rods are Japan's NSK, THK or German Rexroth (Rexroth); the system adopts Taiwan's Syntec bus absolute value control system and integrated drive; the servo motor adopts the high inertia of Japan's Panasonic servo motor; the wire adopts Japanese wire and custom wire;
- Product Details
- {{item.text}}
Quick Details
-
Table Travel (Y) (mm):
-
400 mm
-
Spindle Taper:
-
BT30
-
Dimension(L*W*H):
-
1700mm*1800mm*2000mm
-
Weight (T):
-
3 T
-
Table Travel (Z) (mm):
-
300 mm
-
Positioning Accuracy (mm):
-
± 0.005/300mm
-
Repeatability (X/Y/Z) (mm):
-
± 0.005
-
Range of Spindle Speed(r.p.m):
-
1 - 20000 r.p.m
-
Spindle Motor Power(kW):
-
5.5/7.5
-
Max. Table Load(kg):
-
300 kg
-
Feed Speed(mm/min):
-
1 - 4800 mm/min
-
Rapid Feed Speed(m/min):
-
48
-
Tool Magazine Capacity:
-
16
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Rui Yi
-
Voltage:
-
380v
-
Machine Type:
-
Cnc Milling Machine
-
Product name:
-
3-axis Vertical Cnc Machining Center
-
Product type:
-
Metal Cnc Machine Milling
-
Application:
-
Metal Parts Processing
-
Processing:
-
Metal Cutting Cnc Milling Machine
-
Keywords:
-
Metal Milling Cnc Machine
-
Precision:
-
High Precision Machining Center
-
Key word:
-
High Speed Vertical
-
Controlling Mode:
-
Fanuc Mitsubishi Siemens Gsk System
-
Usage:
-
Steel Milling Drilling Tapping Turning
Quick Details
-
Table Size (mm):
-
700*400
-
Number of Axes:
-
3
-
Table Travel (X) (mm):
-
600 mm
-
Table Travel (Y) (mm):
-
400 mm
-
Spindle Taper:
-
BT30
-
Dimension(L*W*H):
-
1700mm*1800mm*2000mm
-
Weight (T):
-
3 T
-
Table Travel (Z) (mm):
-
300 mm
-
Positioning Accuracy (mm):
-
± 0.005/300mm
-
Repeatability (X/Y/Z) (mm):
-
± 0.005
-
Range of Spindle Speed(r.p.m):
-
1 - 20000 r.p.m
-
Spindle Motor Power(kW):
-
5.5/7.5
-
Max. Table Load(kg):
-
300 kg
-
Feed Speed(mm/min):
-
1 - 4800 mm/min
-
Rapid Feed Speed(m/min):
-
48
-
Tool Magazine Capacity:
-
16
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Rui Yi
-
Voltage:
-
380v
-
Machine Type:
-
Cnc Milling Machine
-
Product name:
-
3-axis Vertical Cnc Machining Center
-
Product type:
-
Metal Cnc Machine Milling
-
Application:
-
Metal Parts Processing
-
Processing:
-
Metal Cutting Cnc Milling Machine
-
Keywords:
-
Metal Milling Cnc Machine
-
Precision:
-
High Precision Machining Center
-
Key word:
-
High Speed Vertical
-
Controlling Mode:
-
Fanuc Mitsubishi Siemens Gsk System
-
Usage:
-
Steel Milling Drilling Tapping Turning
Products Description
Applicable industries:
precision machining of ceramic mobile phone watch shells; glasses parts; fiberboard cutting; mobile phone hardware parts processing; bronzing, shoe molds, buttons, injection molding and other mold manufacturing, hardware accessories precision manufacturing, glass edging and cutting, auto parts, electronics Tobacco manufacturing, smart wear processing, PCB circuit board milling and drilling, jewelry, handicrafts, die casting, jewelry manufacturing, seal engraving
|
A
|
Technical parameters of machine tool：
|
|
|
|
|
||||
|
1
|
The machine body and all parts are made of nano castings
|
|
|
|
|
||||
|
2
|
Table size
|
|
|
500×400mm
|
|
||||
|
3
|
T-groove (width x quantity x spacing)
|
|
|
18×3×150mm
|
|
||||
|
4
|
The largest load
|
|
|
300KG
|
|
||||
|
5
|
Maximum feed height
|
|
|
440mm
|
|
||||
|
6
|
Distance from spindle face to work
|
|
|
90-440mm
|
|
||||
|
7
|
Triaxial travel X/Y/Z
|
|
|
500/500/350mm
|
|
||||
|
8
|
The spindle diameter
|
|
|
Ǿ110mm
|
|
||||
|
9
|
Spindle speed
|
|
|
20000RPM
|
|
||||
|
10
|
Spindle motor power
|
|
|
7.5KW
|
|
||||
|
11
|
Spindle tool library capacity
|
|
|
16
|
|
||||
|
12
|
Tool change time
|
|
|
0.5S
|
|
||||
|
13
|
The spindle taper
|
|
|
BT30
|
|
||||
|
14
|
Knife library classes
|
|
|
Clamp Arm Tool Magazine
|
|
||||
|
15
|
Fast moving rate X/Y/Z
|
|
|
48/48/48m/Min
|
|
||||
|
16
|
Processing speed
|
|
|
6－24m/Min
|
|
||||
|
17
|
Positioning accuracy
|
|
|
±0.006/300mm
|
|
||||
|
18
|
Repetitive positioning accuracy
|
|
|
±0.006/300mm
|
|
||||
|
19
|
Machined surface accuracy
|
|
|
≤Ra1.6
|
|
||||
|
20
|
The machining accuracy
|
|
|
±0.01mm
|
|
||||
|
21
|
Optional four-axis five-axis
|
|
|
Yes
|
|
||||
|
22
|
Angle of rotation of axis A
|
|
|
±105 degrees
|
|
||||
|
23
|
Fifth axis C axis rotation Angle
|
|
|
360 degrees
|
|
||||
|
24
|
Five-axis linkage mode
|
|
|
5 axis with the move
|
|
||||
|
25
|
Working voltage
|
|
|
380V/50HZ±10% or 220V/60HZ
|
|
||||
|
26
|
Machine size (l * W * H)
|
|
|
1700×1600×2200mm
|
|
||||
|
27
|
The body weight
|
|
|
3500KG
|
|
||||
|
B
|
Machine tool configuration details brand parameters：
|
|
|
|
|
||||
|
1
|
The system configuration
|
|
|
Taiwan Syntec 22MA/Mitsubishi E80A/LNC
|
|
||||
|
2
|
The spindle
|
|
|
7.5KW Taiwan direct-connected mechanical spindle
|
|
||||
|
3
|
Ball screw
|
|
|
Taiwan HIWIN/PMI
|
|
||||
|
4
|
Linear guide
|
|
|
Taiwan HIWIN/ABBA high precision guide
|
|
||||
|
5
|
Servo unit
|
|
|
Syntec/Mitsubishi Servo motor1500W
|
|
||||
|
6
|
Wire rod bearing
|
|
|
Japan NSK
|
|
||||
|
7
|
Switching power supply
|
|
|
Taiwan Ming weft
|
|
||||
|
8
|
Electric switch
|
|
|
China chint
|
|
||||
|
9
|
converter
|
|
|
Servo spindle frequency conversion drive
|
|
||||
|
10
|
Tool magazine
|
|
|
Taiwan Shengjie
|
|
||||
Shenzhen Yudiao CNC Technology Co., Ltd.
manager
: Hong Fengsheng
Contact number:0086 13421359966 (same number on WeChat or WhatsApp)
Eamil address:Gideon@gdyudiao.com
Address: Room 101, Building 1, No. 13, Dakang Road, Dakang Community, Yuanshan Street, Longgang District, Shenzhen
