Quick Details
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Cardy
-
Material:
-
PVC
-
Feature:
-
Water-proof
-
Size:
-
85.5*54mm/customized
-
Application:
-
Access Control System
-
Craft:
-
Laser Code\UV Ink\Serial Number\Embossing\Thermal Printing
-
Chip:
-
HITAG2
-
Type:
-
Contactless RFID Card
-
Keyword:
-
RFID Cards
-
Printing:
-
CMYK offset Printing/Silkscreen Printing/Digital Printing
Quick Details
-
Special Features:
-
Waterproof / Weatherproof
-
Communication Interface:
-
RFID
-
Frequency:
-
125KHz
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Cardy
-
Material:
-
PVC
-
Feature:
-
Water-proof
-
Size:
-
85.5*54mm/customized
-
Application:
-
Access Control System
-
Craft:
-
Laser Code\UV Ink\Serial Number\Embossing\Thermal Printing
-
Chip:
-
HITAG2
-
Type:
-
Contactless RFID Card
-
Keyword:
-
RFID Cards
-
Printing:
-
CMYK offset Printing/Silkscreen Printing/Digital Printing
Products Description
|
Material
|
PVC/PET/ABS
|
|
|
|
|||
|
Size
|
85.5*54mm or customized
|
|
|
|
|||
|
Thickness
|
0.76mm-0.9mm or customized
|
|
|
|
|||
|
Chip
|
Refer to RFID chips options as below. Please also consult our sales person for more information.
|
|
|
|
|||
|
Frequency and reading distance
|
LF, 125KHz, 0cm≤Reading distance≤10cm
HF, 13.56MHz, 0cm≤Reading distance≤10cm UHF, 860-960MHz, 0cm≤Reading distance≤10m |
|
|
|
|||
|
|
a. Offset Printing/CMYK printing (Heidelberg offset printing machine)
b. Digital printing (HP digital Printing machine)
c. Silk-screen printing d. Glossy/Matt/Frosted surface with overlay |
|
|
|
|||
|
Crafts
|
a. Glitter gold/silver background
b. Loco 300oe/600oe magstripe , Hico 2750oe/4000oe magstripe
c. Thermal printing/UV spot logo /DOD/Inkjet printing serial/Laser engraving d. serial or UID numbers e. Magnetic stripe(300oe, 2750oe), Barcode f. Encoding and Encryption, Chip encoding g. Anti-metal layer , Back adhesive , Epoxy cover |
|
|
|
|||
|
|
Corporations, Hotel, Bank, Supermarket, Club/SPA Membership Management,
advertisement, Health care, School, Campus one-card, Loyalty card, Bus- stored value card, Travel, Public transportation, Access Control & Security, freeway collection toll,Parking and Payment, Time Attendance, Event ticketing,Residential management, |
|
|
|
|||
|
|
Standard size card packing: 200pcs/inner box, 2000pcs or 3000pcs/ctn.
Irregular size(except the standard size): 100pcs/Opp bag and then in carton, or packed per your request. |
|
|
|
|||
|
Certification
|
RoHS/CE/ISO
|
|
|
|
|||
|
Lead time
|
7-10 Working days
|
|
|
|
|||
RFID chips options
We have many kinds of style for choosing, IC card, magnetic stripe card, differrent frequency 125KHz,13.56MHz
and 860-960MHz, and available chips as below are our style for you to choose
and 860-960MHz, and available chips as below are our style for you to choose
|
|
|
|
|
|
|
LF
125KHz
|
ISO14223 |
HITAG® µ
|
128 bits/512 bits/1760 bits
|
|
|
|
|
HITAG® S 256
|
256 bits
|
|
|
|
|
HITAG® S 2048
|
2048 bits
|
|
|
|
|
HITAG® RO64
|
64 bits
|
|
|
|
|
HITAG® 1
|
2048 bits
|
|
|
|
|
HITAG® 2
|
256 bits
|
|
|
HF
13.56MHz
|
|
MIFARE Classic® EV1 Mini
|
320 bytes
|
MIFARE® and MIFARE Classic® are trademarks of NXP B.V.
Cardy is a Registered MIFARE® Partner. |
|
|
|
MIFARE Classic® EV1 1K
|
1K bytes
|
|
|
|
|
MIFARE Classic® EV1 4K
|
4K bytes
|
|
|
|
|
MIFARE Ultralight®
|
64 bytes
|
MIFARE® and MIFARE Ultralight® are registered trademarks of NXP B.V. and are used under license.
Cardy is a Registered MIFARE® Partner.
|
|
|
|
MIFARE Ultralight® C
|
192 byte
|
|
|
|
|
MIFARE Ultralight® EV1
|
48 bytes/128 bytes
|
|
|
|
|
MIFARE Ultralight® Nano
|
56 bytes
|
|
|
|
|
MIFARE Ultralight® AES
|
144 bytes
|
|
|
|
|
MIFARE® DESFire® Light
|
640 bytes
|
MIFARE® and MIFARE® DESFire® are registered trademarks of NXP B.V. and are used under license.
Cardy is a Registered MIFARE® Partner. |
|
|
|
MIFARE® DESFire® EV1 2K
|
2K bytes
|
|
|
|
|
MIFARE® DESFire® EV1 4K
|
4K bytes
|
|
|
|
|
MIFARE® DESFire® EV1 8K
|
8K bytes
|
|
|
|
|
MIFARE® DESFire® EV2 2K
|
2K bytes
|
|
|
|
|
MIFARE® DESFire® EV2 4K
|
4K bytes
|
|
|
|
|
MIFARE® DESFire® EV2 8K
|
8K bytes
|
|
|
|
|
MIFARE® DESFire® EV3 2K
|
2K bytes
|
|
|
|
|
MIFARE® DESFire® EV3 4K
|
4K bytes
|
|
|
|
|
MIFARE® DESFire® EV3 8K
|
8K bytes
|
|
|
|
|
MIFARE Plus® S 2K
|
2K bytes
|
Cardy is a Registered MIFARE® Partner. |
|
|
|
MIFARE Plus® S 4K
|
4K bytes
|
|
|
|
|
MIFARE Plus® SE 1K
|
1K bytes
|
|
|
|
|
MIFARE Plus® X 2K
|
2K bytes
|
|
|
|
|
MIFARE Plus® X 4K
|
4K bytes
|
|
|
|
|
MIFARE Plus® EV1 2K
|
2K bytes
|
|
|
|
|
MIFARE Plus® EV1 4K
|
4K bytes
|
|
|
|
|
MIFARE Plus® EV2 2K
|
2K bytes
|
|
|
|
|
MIFARE Plus® EV2 4K
|
4K bytes
|
|
|
|
NFC Forum T2T/ T4T |
NTAG® 213
|
144 bytes
|
NTAG® is a registered trademark of NXP B.V. and are used under license.
|
|
|
|
NTAG® 215
|
504 bytes
|
|
|
|
|
NTAG® 216
|
888 bytes
|
|
|
|
|
NTAG® 424 DNA
|
416 bytes
|
|
|
|
|
NTAG® 424 DNA TT
|
416 bytes
|
|
|
|
ISO/IEC 15693
ISO/IEC 18000-3
|
ICODE® SLIX-L
|
256 bits
|
|
|
|
|
ICODE® SLIX
|
896 bits
|
|
|
|
|
ICODE® SLIX-S
|
1280 bits
|
|
|
|
|
ICODE® SLIX2
|
2528 bits
|
|
|
|
|
ICODE® SLI
|
1024 bits
|
|
|
|
|
ICODE® SLI-S
|
2048 bits
|
|
|
|
|
ICODE® DNA
|
2016 bits
|
|
|
|
|
ICODE® ILT-M
|
512 bits
|
|
|
860-960MHz |
|
UCODE® 7
|
0 bits
|
|
|
|
|
UCODE® 7m
|
32 bits
|
|
|
|
|
UCODE® 7xm
|
2048 bits
|
|
|
|
|
UCODE® 7xm+
|
2048 bits
|
|
|
|
|
UCODE® 8
|
0 bits
|
|
|
|
|
UCODE® 8m
|
32 bits
|
|
|
|
|
UCODE® 9
|
0 bits
|
|
|
|
|
UCODE® 9xe
|
0 bits
|
|
|
|
|
UCODE® DNA
|
3072 bits
|
|
|
|
|
UCODE® G2iM
|
320/640 bits
|
|
Product Process
Application
Why Choose Us ?
Cardy is a professional manufacturer engaged in the R&D, production and the sale of RFID/NFC cards, tags, keyfobs, wristbands and readers with Self-owned brands (KD, CARDY), devotes itself to be a first-class supporting manufacturer and solution provider in IoT industry.
Advantage
* 20+ YEARS
Self-owned brands (KD, CARDY) have a good reputation in IoT industry since 2004
* LARGE PRODUCTION CAPACITY
100 million pcs products per year
* R&D
Devotes more than 30% of the company's profits to R & D and improve equipments
30 patents and software copyrights
* QUALITY CONTROL
100% inspection for the IPQC and QA
* SHORT PRODUCTION TIME
24 hours uninterrupted production line with three shifts
1 million products can be finished within 2 weeks
* ORIGINAL FACTORY PRICES
8000㎡factory with full automatic production lines
* PREMIUM SERVICES
24 hours online services
Trade assurance
