HotSale straightener feeder & uncoiler metal sheet coil decoiler straightener feeder uncoiler straightener feeder machine
HotSale straightener feeder & uncoiler metal sheet coil decoiler straightener feeder uncoiler straightener feeder machine
HotSale straightener feeder & uncoiler metal sheet coil decoiler straightener feeder uncoiler straightener feeder machine
HotSale straightener feeder & uncoiler metal sheet coil decoiler straightener feeder uncoiler straightener feeder machine
HotSale straightener feeder & uncoiler metal sheet coil decoiler straightener feeder uncoiler straightener feeder machine
HotSale straightener feeder & uncoiler metal sheet coil decoiler straightener feeder uncoiler straightener feeder machine
HotSale straightener feeder & uncoiler metal sheet coil decoiler straightener feeder uncoiler straightener feeder machine
HotSale straightener feeder & uncoiler metal sheet coil decoiler straightener feeder uncoiler straightener feeder machine

HotSale straightener feeder & uncoiler metal sheet coil decoiler straightener feeder uncoiler straightener feeder machine

FOB Reference Price: Get Latest Price
≥1 Pieces
US $28845
≥2 Pieces
US $27000
≥3 Pieces
US $25500
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Voltage:
3P 380V 50HZ, 380V 3P 50HZ(Customizable)
Dimension(L*W*H):
1500*1450*1650mm
Weight (KG):
2100
Max Leveling Width:
800mm
Roller Diameter:
42mm
Max Plate Thickness:
3mm
Leveling Thickness Range:
0.8-3mm
Min Workpiece Size:
10*70mm
Leveling Speed:
0-6m/min
Leveling Accuracy:
0.05-0.2mm
Size:
1500*1450*1650mm
Weight:
2100kg

Quick Details

Place of Origin:
Guangdong, China
Marketing Type:
Hot Product
Brand Name:
Inserter
Voltage:
3P 380V 50HZ, 380V 3P 50HZ(Customizable)
Dimension(L*W*H):
1500*1450*1650mm
Weight (KG):
2100
Max Leveling Width:
800mm
Roller Diameter:
42mm
Max Plate Thickness:
3mm
Leveling Thickness Range:
0.8-3mm
Min Workpiece Size:
10*70mm
Leveling Speed:
0-6m/min
Leveling Accuracy:
0.05-0.2mm
Size:
1500*1450*1650mm
Weight:
2100kg
Product Features
• Suitable for all kind of Steel, Aluminum, copper, stainless steel, mesh sheet, laser cut plate, alloy plate and other metal plate workpiece • Suitable for vehicle metal parts, aviation metal parts, high-speed train parts, chain board, saw blade, stamping parts, sheet metal parts, furniture metal parts and electrical appliances parts fabrication etc. • By balancing internal stress, restoring and improving metal parts flatness, flatness accuracy can reach micron grade, then it can provide qualified work-pieces for next process step of bending, welding etc • Roller leveler machine equip with a large number of leveling rollers arranged in multi-layers and a very small spacing between each other, then based on "Bauschinger effect", sheet metal was repeatedly twisted to make metal fiber gradually consistent, eliminate internal stress, restore and improve the flatness • The stagger arranged support rollers ensure leveling rollers bearing heavy pressure in balance without bending deformation, keeping the whole equipment have enough rigidity. Upper and lower support roller column & upper and lower leveling roller group making up four-high layers structure, ensuring stable, efficient and high-quality leveling performance • Manual adjust leveling roller gap: At the guidance of digital display, operator can crank the two hand wheels to adjust leveler’s straightening performance
Product Parameter
Model
LM-42-400M
LM-42-600M
LM-42-800M
Max Leveling Width
400MM
600MM
800MM
Roller Diameter
42mm
42mm
42mm
Max Plate Thickness
3mm
3mm
3mm
Leveling Thickness Range
0.8-3mm
0.8-3mm
0.8-3mm
Min Workpiece Size
10*70mm
10*70mm
10*70mm
Leveling Accuracy
0.05-0.2mm
0.05-0.2mm
0.05-0.2mm
Leveling Speed
0-6m/min
0-6m/min
0-6m/min
Leveling Roller Quantity
19pcs(Upper 9pcs/Lower 10pcs)
Leveling Roller Gap Adjust Method
Four Points Manual Adjust
Voltage
AC 3Phase 380V 50HZ(Customizable)
FAQ
1. Who are we? A:We are based in Guangdong, China, sell to Southeast Asia(20.00%),Eastern Europe(20.00%), WesternEurope(10.00%), North America(10.00%), Northern Europe(5.00%), Central America(5.00%),SouthAmerica(5.00%),Eastern Asia(5.00%),South Asia(5.00%),Oceania(5.00%),Southern Europe(5.00%),Africa(3.00%),MidEast(2.00%). There are total about 11-50 people in our office. 2. How to choose the right leveler? You tell us the material, thickness, width, etc. of the sheet metal, and we will recommend it for you. 3.Which payment terms you can accept? A: We can accept flexible payment include Bank Transfer, LC, DP, West Union, Paypal, or Combination terms as negotiation. 4.Which shipping way can you provide? A: We can provide shipping by sea, by air, by express and etc according to customer requirements. 5.How to place order? A: When you are ready to order, please contact us for confirm the suitable solution & plan & model. What cannot be ignored is you should provide a copy purchase order to ensure that your order is processed properly. 6.Do you have an inspection procedure for the product? A: Yes, We have a strict inspection of product quality and packing.
