Quick Details
-
Table Size:
-
1.4*0.7 m
-
Weight:
-
4650 kg
-
Platform Height:
-
25 m
-
Horizontal Outreach:
-
14.2 m
-
Up and Over Height:
-
12.7 m
-
Below Ground Reach:
-
5.8 m
Quick Details
-
Warranty:
-
1 Year
-
Place of Origin:
-
Hunan, China
-
Brand Name:
-
EVANGEL
-
Table Size:
-
1.4*0.7 m
-
Weight:
-
4650 kg
-
Platform Height:
-
25 m
-
Horizontal Outreach:
-
14.2 m
-
Up and Over Height:
-
12.7 m
-
Below Ground Reach:
-
5.8 m
Contact Ways:
Yvonne Liu
Sales Director
Whatsapp/Wechat/Mobile: +86-158 2104 0156
E-mail: yvonne@evangelchina.com
Evangel Industrial (Shanghai) Co., Ltd / Evangel International Machinery Ltd.
Add: Suite 2806, Super Ocean Finance Center
No.2067 West Yan'an Road, Shanghai 200336, China.
Specification
|
Work Height
|
27m
|
|
Platform Height
|
25m
|
|
Horizontal Outreach
|
14.2m
|
|
Up and Over Height
|
12.7m
|
|
Below Ground Reach
|
5.8m
|
|
A - Stowed Length (w/ platform）
|
6.15m
|
|
D - Stowed Length (w/o platform)
|
5.7m
|
|
B - Stowed Width
|
0.89m
|
|
C - Stowed Height
|
2.05m
|
|
E - Platform Length
|
1.4m
|
|
F - Platform Width
|
0.7m
|
|
G - Platform Height
|
1.25m
|
|
H - Crawler Size (Length×Width)
|
1.52m×0.25m
|
|
I - Max Length w/ Outrigger Extending (Standard)
|
4.95m
|
|
J - Max Width w/ Outrigger Extending (Standard)
|
4.48m
|
|
K - Max Length w/ Outrigger Extending (Narrow)
|
6.45m
|
|
L - Max Width w/ Outrigger Extending (Narrow)
|
2.88m
|
|
Outrigger Pad Size (Diameter)
|
0.26m
|
|
Approach Angle
|
15°
|
|
Depature Angle
|
24°
|
