PP PE PA PET Customized Pelletizer Recycling Extruder Pellet Making Line Double Stage Waste Plastic Pelletizing Machine
PP PE PA PET Customized Pelletizer Recycling Extruder Pellet Making Line Double Stage Waste Plastic Pelletizing Machine
PP PE PA PET Customized Pelletizer Recycling Extruder Pellet Making Line Double Stage Waste Plastic Pelletizing Machine
PP PE PA PET Customized Pelletizer Recycling Extruder Pellet Making Line Double Stage Waste Plastic Pelletizing Machine
PP PE PA PET Customized Pelletizer Recycling Extruder Pellet Making Line Double Stage Waste Plastic Pelletizing Machine
PP PE PA PET Customized Pelletizer Recycling Extruder Pellet Making Line Double Stage Waste Plastic Pelletizing Machine
PP PE PA PET Customized Pelletizer Recycling Extruder Pellet Making Line Double Stage Waste Plastic Pelletizing Machine
PP PE PA PET Customized Pelletizer Recycling Extruder Pellet Making Line Double Stage Waste Plastic Pelletizing Machine

PP PE PA PET Customized Pelletizer Recycling Extruder Pellet Making Line Double Stage Waste Plastic Pelletizing Machine

FOB Reference Price: Get Latest Price
≥1 Sets
US $25000
≥2 Sets
US $23500
Free Inquiry
Customized Request
  • Product Details
  • {{item.text}}

Quick Details

Voltage:
220V/380V/415V
Dimension(L*W*H):
10000*1200*1500MM
Weight:
4000
After-sales Service Provided:
Engineers available to service machinery overseas
Name:
plastic granules making machine
Material Processed:
Plastic Pp Pe Film
Capacity:
300/500/1000kg/h
TEST RUN:
INSPECT
Contactor:
SIMENS Brand
Keywords:
plastic granules making machine
Final product:
granule
Motor:
Wannan Motor

Quick Details

Output (kg/h):
1 - 1000 kg/h
Place of Origin:
Zhejiang, China
Brand Name:
hopesun
Voltage:
220V/380V/415V
Dimension(L*W*H):
10000*1200*1500MM
Weight:
4000
After-sales Service Provided:
Engineers available to service machinery overseas
Name:
plastic granules making machine
Material Processed:
Plastic Pp Pe Film
Capacity:
300/500/1000kg/h
TEST RUN:
INSPECT
Contactor:
SIMENS Brand
Keywords:
plastic granules making machine
Final product:
granule
Motor:
Wannan Motor

PP PE PA EVA PS Pelletizer Extruder  Line Double Stage Waste Plastic Pelletizing Machine

Application:

Applicable materials : PP,PE, ABS ,PS ,PC ,PA,PET ,PBT etc.

Material shape: bottle ,container , hard scrap etc

Advantages:

1.  Equipped with the side feeding device to ensure high output.

2.  Vent design on the barrel to evaporate the volatiles form the recycling material.

3.  Hydraulic screen change unit for easy operation and safety.

4.  The vertical centrifuge separates and dry the pellets faster.

5.  High-efficient side-feeder ensures high capacity feeding, low energy consumption

6.  Plastic pelletizer style: water-ring cutting with extrusion die, noodle cutting type

Model

Long dia.ratio

Output(kg/h)

Power(kw)

HPD-SJP-80-70

28:1

100-120

18.5

HPD-SJP-90-80

28:1

120-140

22-30

HPD-SJP-100-90

28:1

140-170

37-45

HPD-SJP-120-110

28:1

200-240

37-45

HPD-SJP-130-120

28:1

270-320

55-75

HPD-SJP-140-130

28:1

350-430

75-90

HPD-SJP-150-140

28:1

450-550

75-110

HPD-SJP-160-150

28:1

500-600

110-132


some machines video :

1. https://youtu.be/J3NaPy5E3Gc

2. https://youtu.be/4-ia8W4-UGg

3. https://youtu.be/ViyP9ZdSvmU

4. https://youtu.be/aXvgME_Y7Ls

5. https://youtu.be/nKb9iMj1LZg

Contact with us for more video and idear for different kinds of plastic pelletizing machine .

Mobile&whatsapp&wechat : 008615888181919

Item

Specification

Screw and barrel

l  made of high grade 38CrMoAIL

l  hardening& tempering hardness : HB270-300

l  Nitrided hardness: HV850-1000

l  Nitrided depth:0.45-0.7 mm

l  Screw straightness  : 0.015 mm

Gear box

l  Gear made of 20CrMnTi

l  Hard teeth surface

l  Hardness : HRC54-62

l  Bearing  : ZHJ and DYZV

l  Sealing:TAIWAN TTO

Motor

l Beautiful profile

l High efficiency and energy saving

(IE2 of IEC60034-30 and level 3 of GB18613-2012)

l Class F VPI insulation

l Low noise

l Little vibration

l Reliable performance

l High lock rotor torque

l Junction box equipped with glands

Screen changer

l Option : Hydraulic , motor , manual etc

l  Filter material : 38CrMoAl nitrition treatment

l Convenient and high efficient

Electrical parts

l Option : chnt , siemens , schedule brand etc ;

l Stable and high performance

Pelletizer

l Horizontal or vertical pelletizer according to the use

l Option : strand pelletizer , water ring , under water cutting ;

l Rotary blade design and blade teeth made of tungsten steel

l Stable and cutting in uniform
