Quick Details
-
Filling Accuracy:
-
99%
-
Voltage:
-
220V/380V/50HZ
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Zonelit Packaging
-
Dimension(L*W*H):
-
1150*700*1750mm
-
Weight:
-
280 KG
-
Product name:
-
tomato paste sachet filling and sealing machine
-
Usage:
-
filling sealing sachet
-
Bottle type:
-
sachet,bags
-
Filling speed:
-
15~40 sachet per minute
-
Bag length:
-
30-150mm
-
Bag width:
-
25-145mm
-
Control:
-
PLC+ Touch Screen
-
Material:
-
SS304/316
-
Keywords:
-
sachet filling and sealing machine
-
Key words:
-
sachet packaging machine
Quick Details
-
Machinery Capacity:
-
500BPH, 1000BPH, 100BPH, 200BPH
-
Packaging Material:
-
Plastic, Wood
-
Filling Material:
-
Other, Water, Oil, Juice, alcohol, wine
-
Filling Accuracy:
-
99%
-
Voltage:
-
220V/380V/50HZ
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
Zonelit Packaging
-
Dimension(L*W*H):
-
1150*700*1750mm
-
Weight:
-
280 KG
-
Product name:
-
tomato paste sachet filling and sealing machine
-
Usage:
-
filling sealing sachet
-
Bottle type:
-
sachet,bags
-
Filling speed:
-
15~40 sachet per minute
-
Bag length:
-
30-150mm
-
Bag width:
-
25-145mm
-
Control:
-
PLC+ Touch Screen
-
Material:
-
SS304/316
-
Keywords:
-
sachet filling and sealing machine
-
Key words:
-
sachet packaging machine
shampoo sauce honey sachet packaging machine tomato paste sachet filling and sealing machine
Product Description
Features:
This machine integrates mechanical and electrical functions, two CPU computer control system, large screen LCD, microcomputer control optical tracking correcting system, equipped with high-precision stepper motor, exactly the same position design of each bag, control system of complete synchronization, fixed length, position and speed, automatic fault diagnosis function. Can choose a ribbon typewriter or stamp marking device.
This machine bag making, filling, counting, sealing, cutting a series of actions are done automatically. Stepless speed regulation, speed regulation process without stopping. Adjust weight without stop.
|
Packing speed
|
15-40 bag/min
|
|
Bag length
|
30-150mm
|
|
Bag width
|
25-145mm
|
|
Filling range
|
5-50ml/20-100ml
|
|
Power Consumption
|
1.8kw
|
|
Air pressure
|
0.6－0.7MP
|
|
Weight
|
280kg
|
|
Dimensions
|
1150*700*1750mm
|
Applicable Materials
This machine is mainly used for ketchup/tomato sauce, chili sauce, hotpot condiment, salad cream, cooking oil, honey, yogurt,fruit juice, wine, vinegar, shampoo, hair conditioner, facial cream, medical and chemical liquid/paste quantitative packaging.
Product Details
Packaging film width could be adjusted
suitable for various bags packaging.
Hopper could with mixing function
and has two
CPU computer control system, large screen LCD, microcomputer control
Why Choose Us
The parts connected with liquid adopt SS304 material
Customized the layout as your required and free lifetime technical support
Double your output wihtout doubling your cost
Jobsite installation,traning,maintain and free lifetime technical support
Turney project from A to Z supported
