Optional equipped with breaking or stirring mechanism
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
teconway
-
Voltage:
-
Local Power
-
Dimension(L*W*H):
-
Customized Size
-
Weight (KG):
-
1000 kg
-
Product name:
-
Screw Conveyor
-
Keyword:
-
Conveyor
-
Usage:
-
Granular Material
-
Color:
-
Silver
-
Motor:
-
3.0~5.5KW
-
Screw blade Diameter:
-
260mm
-
Screw blade Material:
-
Stainless steel/Manganese steel
-
Capacity:
-
2.5~5m³/H
Quick Details
-
Power:
-
Customized
-
Warranty:
-
1 Year
-
Width or Diameter:
-
300mm
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
teconway
-
Voltage:
-
Local Power
-
Dimension(L*W*H):
-
Customized Size
-
Weight (KG):
-
1000 kg
-
Product name:
-
Screw Conveyor
-
Keyword:
-
Conveyor
-
Usage:
-
Granular Material
-
Color:
-
Silver
-
Motor:
-
3.0~5.5KW
-
Screw blade Diameter:
-
260mm
-
Screw blade Material:
-
Stainless steel/Manganese steel
-
Capacity:
-
2.5~5m³/H
TECONWAY Conveyors
Over 20 years of experience
Market-leading quality at market-beating prices
Precision, Reliable, Easy to Maintain, Customized
Market-leading quality at market-beating prices
Precision, Reliable, Easy to Maintain, Customized
Products Description
A
screw conveyor
is a mechanism that uses a rotating helical blade, usually within a tube or u-type trough structure to move liquid or granular materials.
Screw conveyors are used to feed, distribute, collect or mix and can be equipped to either heat or cool while performing this transfer. Their clean compact design saves valuable space since no return run is required. Screw Conveyors fit in cramped quarters, are simple to support and easy to install. And they cost less than most other types of conveyors.
In modern industry, screw conveyors are often used horizontally or at a slight incline as an efficient way to move semi-solid bulk materials, including food waste, municipal solid waste, Industrial sludge, wood chips, aggregates, cereal grains, animal feed, boiler ash, and many others.
A screw conveyor is also called spiral conveyor, auger conveyor.
Screw conveyors are used to feed, distribute, collect or mix and can be equipped to either heat or cool while performing this transfer. Their clean compact design saves valuable space since no return run is required. Screw Conveyors fit in cramped quarters, are simple to support and easy to install. And they cost less than most other types of conveyors.
In modern industry, screw conveyors are often used horizontally or at a slight incline as an efficient way to move semi-solid bulk materials, including food waste, municipal solid waste, Industrial sludge, wood chips, aggregates, cereal grains, animal feed, boiler ash, and many others.
A screw conveyor is also called spiral conveyor, auger conveyor.
|
Technical Parameters of Shaftless Screw Conveyors
|
|
|
|
|
|
|
||||||
|
Model Type
|
Screw Blade Outer Diameter
|
Conveying Capacity
|
Power
|
Revolving Speed
|
Max. Length
|
Inclined
Angle
|
||||||
|
|
|
|
|
|
|
|
||||||
|
|
mm
|
m³/h
|
Kw
|
r/min
|
m
|
°
|
||||||
|
WLS160
|
160
|
1.0~1.5
|
2.2~3.0
|
15～30
|
≤12
|
0～30°
|
||||||
|
WLS200
|
200
|
1.5~2.5
|
3.0~4.0
|
15～30
|
≤12
|
0～30°
|
||||||
|
WLS260
|
260
|
2.5~5.0
|
4.0~5.5
|
15～30
|
≤15
|
0～30°
|
||||||
|
WLS320
|
320
|
5.0~8.0
|
5.5~7.5
|
15～30
|
≤15
|
0～30°
|
||||||
|
WLS360
|
360
|
7.0~10
|
7.5~11
|
15～30
|
≤20
|
0～30°
|
||||||
|
WLS420
|
420
|
10~20
|
7.5~11
|
15～30
|
≤25
|
0～30°
|
||||||
|
WLS500
|
500
|
20~30
|
11~15
|
15～30
|
≤30
|
0～30°
|
||||||
|
1. The motor with different power should be determined according to the working condition, conveyed materials, inclined angle and conveying length and other factors;
|
|
|
|
|
|
|
||||||
|
|
|
|
|
|
|
|
||||||
|
2. Teconway will design and manufacture conveyors to suit your specific requirements.
|
|
|
|
|
|
|
||||||
Manganese steel or stainless-steel Screw Blade
Pitch and thickness designed according to the usage
Customized Hopper
NSK, SKF bearings, Well-known brand gear motor
Customer-specified brand is also OK.
Customer-specified brand is also OK.
Customized Hopper
Customize the volume as needed
Optional equipped with breaking or stirring mechanism
Optional equipped with breaking or stirring mechanism
ADVANTAGE
1.
Full Engineering Design Support
2. Advanced Equipment and Benchmark Quality
APPLICATION
Main Product
Why Choose Us
Certifications
Production Line
Packing&Shipping
FAQ
Q1 : Are you trading company or manufacturer?
A1 : We are professional manufacturer with 20+ years experiences.
Q2 : Where is your factory located?
A2 : Dezhou City of Shandong Province, which is very close to Beijing,Tianjin,Qingdao.
Q3 : Do you provide OEM service?
A3 : Yes. Any required logos are available.
Q4 : How could we trust you and your company? This is first time transaction?
A4 : Our company has long term professional experience. We cooperate over 1000 customers in China and overseas. We export nearly 40 countries all over the world. Welcome to our company and visit our plant production condition any time.
Q5: Can your machine be customized?
A5: Yes, we have an experienced design & technical team. We can design and manufacture kinds of conveyors as your requirements.
Q6: How to get an accurate quotation?
A6: Please provide us at least the following basic conveying information: material type and weight or volume per unit time,
conveying distance and height. Of course, the more details we know, the more accurate quotation will be.
Q7: Can you offer oversea service?
A7: We provide full engineering design support to service customer overseas. Also, we will provide you manual, photos and/or videos to help you to operate and maintain the machine.
Q8: what’s the package?
A8: The normal package is plywood case (Size: L*W*H).
