Quick Details
-
Light Source:
-
LED
-
Product Weight（kg）:
-
0.8
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DF
-
Product Name:
-
Rechargeable LED Emergency Battery Powered Bulkhead Lights
-
Lighting source Power:
-
3-12W
-
Emergency time:
-
1-4h
-
Operation temperature:
-
-20--50℃ , 65+20% R H
-
Emergency switch time:
-
≤ 1S
-
The service life:
-
30000Hours
-
Warranty:
-
2 years
-
Charging Time:
-
>12 hours without break
-
Certs:
-
CE/ROSH/FCC/SAA
Quick Details
-
Battery Type:
-
Ni-Cd Ni-MH Lithium
-
Material:
-
Transparent and PC cover
-
Usage:
-
emergency lighting
-
Light Source:
-
LED
-
Product Weight（kg）:
-
0.8
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
DF
-
Product Name:
-
Rechargeable LED Emergency Battery Powered Bulkhead Lights
-
Lighting source Power:
-
3-12W
-
Emergency time:
-
1-4h
-
Operation temperature:
-
-20--50℃ , 65+20% R H
-
Emergency switch time:
-
≤ 1S
-
The service life:
-
30000Hours
-
Warranty:
-
2 years
-
Charging Time:
-
>12 hours without break
-
Certs:
-
CE/ROSH/FCC/SAA
The Rechargeable LED Emergency Battery Powered Bulkhead Lights will provide the same output and performance as a standard emergency light but with the added advantage of low power consumption and running costs.
The light is fitted with a self-test feature and has an IP65 rating making them ideal for installing in internal or external environments.
| The technical data for Rechargeable LED Emergency Battery Powered Bulkhead Lights BD-SF03 | |
| Product Code | BD-SF03 |
| Weight | 1.00kg |
| Lamp Type | 45 CREE LEDs |
| Power Consumption | 3-12W |
| Battery Type | 3.6V |
| Backup Duration | 3 Hours (custom-made) |
| Light Output | custom-made |
| Dimensions |
350*117*76mm
|
- Non-maintained /maintained operation
- 2 Year Warranty on Maintained units
- Hinged/removable gear tray
- Supplied complete with LEDs and battery
- Low power consumption
- Compact design
- 3 hours back-up battery duration (custom-made)
- Suitable for wall or ceiling mounting
Maintained Operation
When in maintained operation the lamp of an emergency luminaire stays on constantly at all times and stays lit for the minimum emergency duration after a mains failure.
Non-Maintained Operation
When in non-maintained operation the lamp of an emergency luminaire will only light in the event of a mains failure and will stay lit for the minimum emergency duration required.
Please Note : Maintained units are capable of being wired to enable non-maintained operation.
DF LED Emergency Bulkhead Light BD-SF03--emergency working picture
