The bracket can be adjusted to 219°, which strengthens its thickness, the double bracket installation is more stable and safe,the fixtures and mounting brackets are much thicker(5mm).
- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
SNOOWEL
-
Model Number:
-
SW-TS09-W1500
-
Color Temperature(CCT):
-
2700K-6500K, 2700-6500K
-
Beam Angle(°):
-
20°, 40°, 60°, 90°, 50°(asymmetrical)
-
CRI (Ra>):
-
70
-
Input Voltage(V):
-
AC100-277V
-
Working Lifetime(Hour):
-
70000
-
Working Temperature(℃):
-
-35 - 60
-
Lifespan (hours):
-
70000
-
Product name:
-
Led Stadium Light
-
Power:
-
1500watt
-
Body color:
-
Black
-
View angle49°x21°(asymmetrica:
-
20°, 40°, 60°, 90°,50°(asymmetrical)
-
PF:
-
> 0.97
-
LED Light Source:
-
5050 SMD
-
Keyword:
-
LED Stadium Light Waterproof IP66 Outdoor
-
Storage Temperature:
-
-35℃ to 60℃
Quick Details
-
Lamp Luminous Flux(lm):
-
225000
-
Warranty(Year):
-
5-Year
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
SNOOWEL
-
Model Number:
-
SW-TS09-W1500
-
Color Temperature(CCT):
-
2700K-6500K, 2700-6500K
-
Beam Angle(°):
-
20°, 40°, 60°, 90°, 50°(asymmetrical)
-
CRI (Ra>):
-
70
-
Input Voltage(V):
-
AC100-277V
-
Working Lifetime(Hour):
-
70000
-
Working Temperature(℃):
-
-35 - 60
-
Lifespan (hours):
-
70000
-
Product name:
-
Led Stadium Light
-
Power:
-
1500watt
-
Body color:
-
Black
-
View angle49°x21°(asymmetrica:
-
20°, 40°, 60°, 90°,50°(asymmetrical)
-
PF:
-
> 0.97
-
LED Light Source:
-
5050 SMD
-
Keyword:
-
LED Stadium Light Waterproof IP66 Outdoor
-
Storage Temperature:
-
-35℃ to 60℃
Why Choose Us
SNOOWEL-Experienced supplier in LED lighting industry for 13 years.
*5 years warranty！
* All wattage are optional！
* Warm White/Natural White/Cool White optional！
* Many installation methods are available！
* Adapt to ultra-harsh environments！
* More than 70000 hours of service life！
* OEM/ODM service are available, welcome custom sample order.
*Having TUV,ENEC,CB,SAA,EMC,ETL,LVD,RCM,IEC,IP66,K10,IK9,CE,RoHS etc certificates
Products Description
Features:
【Adjustable angle】 Users can adjust the projection angle of each stadium light individually to increase the projection area, easy and convenient to operate 【Super bright and energy efficient】 The LED floodlight uses a non-strobe LED driver solution. The large LED chip outputs 150LM/W of luminous flux through the PC optical lens. 【SAFETY PERFORMANCE】: Ensure 50000 hours life, IP67 Waterproof , LED Floodlights outdoor can be used in heavy rain, Snow and high temperature environment
【Adjustable angle】 Users can adjust the projection angle of each stadium light individually to increase the projection area, easy and convenient to operate 【Super bright and energy efficient】 The LED floodlight uses a non-strobe LED driver solution. The large LED chip outputs 150LM/W of luminous flux through the PC optical lens. 【SAFETY PERFORMANCE】: Ensure 50000 hours life, IP67 Waterproof , LED Floodlights outdoor can be used in heavy rain, Snow and high temperature environment
【USAGE SCENARIO】
:
Snoowel LED Stadium lights are suitable where long-term lighting is required. for Docks, Construction sites, Stadiums, swimming pools, Outdoor parking spaces, Lawns, Farms, Warehouses
|
Product specification
|
|
|
|
Model No.
|
SW-TS09-W1500
|
|
|
Rated Power
|
240W / 500W / 750W / 1000W / 1250W / 1500W / 2000W option
|
|
|
Input Voltage
|
AC100-277V, 50/60Hz; AC347V/480V is for option
|
|
|
PF:
|
>0.97
|
|
|
IP Grade:
|
IP66
|
|
|
THD:
|
10%（at 230v, 50Hz)
|
|
|
LED Parameters
|
|
|
|
LED chip
|
SMD5050
|
|
|
Light Flux
|
140-150Lm/W
|
|
|
Color Temperature
|
2700-6500k
|
|
|
CRI
|
>70Ra or 80Ra
|
|
|
Beam Angle
|
10° 20° 40° 60° 90° 50°(asym metrical)
|
|
|
Mechanical Specification
|
|
|
|
Heat sinks:
|
Aluminum
|
|
|
Body color
|
Black
|
|
|
Operating Temperature
|
-35℃ - 60℃
|
|
|
Net W./Gross W
|
29.25KGS / 32.00KGS(one piece)
|
|
|
Packing size
|
108x66x31CM, One piece in one carton
|
|
|
Warranty
|
5 years warranty
|
|
The back design is more waterproof, our wires are installed inside.
Don’t worry about water entering in rainy days to avoid electric shock.
LED Light Test & Quality Inspection
Product Packaging
