Quick Details
-
Model Number:
-
XQ-S-11
-
IP level:
-
NO
-
Contact Capacity:
-
AC 220V 20(10)A
-
Time Frame:
-
24h/24h
-
Contact Resistance:
-
≤50mΩ
-
Insulation Resistance:
-
≥100MΩ
-
Rated Voltage:
-
110,240V,AC
-
Ambient Temperature:
-
-20℃ - +55℃
-
Storage Time:
-
300h Replaceable Battery
-
Set Number:
-
15 Points.Time 96Times
-
Consumed Power:
-
5VA
Quick Details
-
Max. Voltage:
-
240V
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
XUANQI
-
Model Number:
-
XQ-S-11
-
IP level:
-
NO
-
Contact Capacity:
-
AC 220V 20(10)A
-
Time Frame:
-
24h/24h
-
Contact Resistance:
-
≤50mΩ
-
Insulation Resistance:
-
≥100MΩ
-
Rated Voltage:
-
110,240V,AC
-
Ambient Temperature:
-
-20℃ - +55℃
-
Storage Time:
-
300h Replaceable Battery
-
Set Number:
-
15 Points.Time 96Times
-
Consumed Power:
-
5VA
|
Model
|
|
|
XQ-S-11
|
|
|||
|
Contact Capacity
|
|
|
AC 200V 20(10)A
|
|
|||
|
Time Frame
|
|
|
24h/24h
|
|
|||
|
Contact Resistance
|
|
|
≤50mΩ
|
|
|||
|
Insulation Resistance
|
|
|
≥100mΩ
|
|
|||
|
Rated Voltage
|
|
|
110/240V AC
|
|
|||
|
Life
|
|
|
Electrical/10, Machainery/10
|
|
|||
|
Ambient Temperature
|
|
|
-20℃+55℃
|
|
|||
|
Consumed Power
|
|
|
5VA
|
|
|||
|
Storage Time
|
|
|
300h
|
|
|||
|
Minimum Setting Unit
|
|
|
15 Minutes
|
|
|||
|
Set Number
|
|
|
15 Points/Time 96Times
|
|
|||
|
Contact
Capacity
|
Resistance
|
|
15A
|
|
|||
|
|
Incandescent Lamp Load
|
|
12A
|
|
|||
|
|
Lndutivloade（cosφ=0.7）
|
|
10A
|
|
|||
|
|
Motor Load （cos=0.7）
|
|
AC 110.75W AC 220V 1500E
|
|
|||
|
Ambient Operating Temperature
|
|
|
-10℃+50℃
|
|
|||
|
Ambient Operating Humidity
|
|
|
Less Than 85%
|
|
|||
|
Weight
|
|
|
250g
|
|
|||
|
Function
|
|
|
Timing
|
|
|||
|
Installation
|
|
|
Din Rail
|
|
|||
|
Battery
|
|
|
Rechargeable NI-MH Battery
|
|
|||
