The fuselage adopts a low-front and high-reardesign to reduce air resistance during flight andimprove spraying efficiency.
- Product Details
- {{item.text}}
Quick Details
-
Marketing Type:
-
New Product 2023
-
Core Components:
-
FOC
-
Weight:
-
70 KG
-
Material:
-
Carbon Fibre
-
Spray width:
-
8-10m
-
Spray efficiency:
-
12-15 Hectares/hour
-
Certification:
-
CE,FCC,ISO9001,OHSAS18001,ISO14001
-
Power:
-
Smart battery and quick charger
-
Spread size:
-
1465mm * 1520mm * 650mm
-
Folded size:
-
940mm * 645mm * 650mm(
-
Shipment:
-
By sea, air,courier service
-
MOQ:
-
1 Unit
Quick Details
-
Place of Origin:
-
Shandong, China
-
Diameter:
-
150 cm
-
Feature:
-
Automatic flight, intelligent spraying, AB point
-
Marketing Type:
-
New Product 2023
-
Core Components:
-
FOC
-
Weight:
-
70 KG
-
Material:
-
Carbon Fibre
-
Spray width:
-
8-10m
-
Spray efficiency:
-
12-15 Hectares/hour
-
Certification:
-
CE,FCC,ISO9001,OHSAS18001,ISO14001
-
Power:
-
Smart battery and quick charger
-
Spread size:
-
1465mm * 1520mm * 650mm
-
Folded size:
-
940mm * 645mm * 650mm(
-
Shipment:
-
By sea, air,courier service
-
MOQ:
-
1 Unit
Products Description
Make farming work safer and more efficient
Autonomous Flight
24 Hours Ease of Work
Supports multiple color/capacity/text customization
Product Detail
The arm adopts an oblique foldingdesign, which reduces the volume by20% compared with the same capacitydrone.The new model is more convenient to transport and store.
The folding part of the arm is upgraded to aone-button buckle, which greatly enhances thestability and makes it easier to operate.
The battery slider material ofthe newmodel has been upgraded to nyloncarbon fiber, which is smoother andmore stable than before, making it easyto replace.
The new model is equipped with a smart distribution board and a tiled heat sink to make its heat dissipation more efficient. lt supports fault detection andstorage, accurately locates the cause of the fault, andintegrates functions such as anti-ignition, powermonitoring, data recording,and CAN communication.
WORK IN THE RIAN
Waterproof class :lP67.
Core components waterproof,
Internal equipment waterproof, dust-proof, line protection.
Fast Charging
Adopting Greep 3.0 intelligent plug-in lithium battery, it is more convenient to replace the battery. It supports up to 3
C
charging, and the charger can support up to 60 A charging. It can be fully charged in15 minutes, and 4 batteries can work continuously.
charging, and the charger can support up to 60 A charging. It can be fully charged in15 minutes, and 4 batteries can work continuously.
carbon fiber
A large number of 6061 aluminum alloy chain frame structures are used, which are more sturdy and durable
Modular design
The distribution board adopts an integrated gluing process, which eliminates the need to disassemble the distribution board for installing power and flight control, improving assembly and subsequent maintenance efficiency
Downward Pressure Windfield
Stable downward pressure wind field, pesticides can be penetrated directly to the bottom of crops.
Ceramic Nozzle
High pressure nozzles:-Using Germany ceramic nozzle, good corrosion resistance and long service life. -100~200
um
droplet diameter,better wind resistance.- Suitable for spraying wheat, corns,
Centrifugal Nozzle
Omnidirectional 360°sowing, uni-formly distributed without leakage.Suitable for spreading solid fertilizers,seeds, feed etc.
EASY TO OPERATE
Manual model-Operate manually with remote control-Integrated remote control-5.5-inch large display Ground station, image
transmis - sion
transmis - sion
Map selection and automatic route planning Support map saving without planning next time
Manual point selection/flight point selection Support map saving without planning next time
Support break point memory After replenishing electricity or raw materials, one click return to the break point to start working
SUPPORT SPRAYING WORKDURING DAY AND NIGHT
Brushless motor + efficient radiator + night indicator light (front and rear indicator light different design, easy to identify the direction of night, improve the safety of the operation)+
120° wide Angle lighting + HD camera.
Ground Awareness
The UAV equipped with terrain tracking radar can detect the terrain environment in real time and automatically adjust the flight altitude.
Make sure you can handle rough terrain.
Avoidance Radar
The obstacle avoidance radar system can sense obstacles and the surrounding environment in all environments without interference from dust light. Automatic obstacle avoidance and adjustment function to ensure safety during operation.
