Quick Details
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Xingda
-
Voltage:
-
380V 50HZ 3Phase(Customized)
-
Dimension(L*W*H):
-
Customized
-
Power (kW):
-
55
-
Weight:
-
4 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Pipe diameter:
-
110mm
-
Center height:
-
1000mm
-
Cooling water:
-
≤20℃, ≥0.3Mpa
-
Compressed air:
-
0.3m3/min, ≥0.5MPa
-
Humidity degree:
-
≤85%
-
Output:
-
200kg/h
-
Pipe Material:
-
PE,HDPE
-
Inverter:
-
ABB
-
Color of the machine:
-
Customized
Quick Details
-
Screw Design:
-
Single-screw
-
Screw L/D Ratio:
-
33:1
-
Screw Speed (rpm):
-
120 rpm
-
Place of Origin:
-
Jiangsu, China
-
Brand Name:
-
Xingda
-
Voltage:
-
380V 50HZ 3Phase(Customized)
-
Dimension(L*W*H):
-
Customized
-
Power (kW):
-
55
-
Weight:
-
4 KG
-
After-sales Service Provided:
-
Engineers available to service machinery overseas
-
Pipe diameter:
-
110mm
-
Center height:
-
1000mm
-
Cooling water:
-
≤20℃, ≥0.3Mpa
-
Compressed air:
-
0.3m3/min, ≥0.5MPa
-
Humidity degree:
-
≤85%
-
Output:
-
200kg/h
-
Pipe Material:
-
PE,HDPE
-
Inverter:
-
ABB
-
Color of the machine:
-
Customized
Product Description
Specification
|
Model
|
PE-16/63
|
PE-20/110
|
PE-50/160
|
PE-75/250
|
PE-110/315
|
PE-200/450
|
PE-315/630
|
PE-400/800
|
|
Pipe diameter
|
16-63mm
|
20-110mm
|
50-160mm
|
75-250mm
|
110-315mm
|
200-450mm
|
315-630mm
|
400-800mm
|
|
Max output
|
150kg/h
|
200kg/h
|
300kg/h
|
350kg/h
|
400kg/h
|
500kg/h
|
850kg/h
|
850kg/h
|
|
Extrusion speed
|
1-15m/min
|
1.2-12m/min
|
0.6-8m/min
|
0.5-4m/min
|
0.4-3.7m/min
|
0.3-3m/min
|
0.2-2m/min
|
0.1-1 m/min
|
|
Extruder model
|
SJ-65/30
|
SJ-65/33
|
SJ-75/33
|
SJ-75/33
|
SJ-75/33
|
SJ-90/33
|
SJ-120/33
|
SJ-120/33
|
|
Installed power
|
85kw
|
110kw
|
125kw
|
180kw
|
260kw
|
325kw
|
480kw
|
600kw
|
|
Center height
|
1000mm
|
1000mm
|
1000mm
|
1000mm
|
1100mm
|
1100mm
|
1200mm
|
1300mm
|
|
Line length
|
35m
|
38m
|
38m
|
40m
|
42m
|
52 m
|
60m
|
68m
|
