Quick Details
-
Mounting Type:
-
concealed mounting
-
Description:
-
Microwave motion sesnor, Motion & Position Sensor, Microwave Radar Sensor
-
Model Number:
-
YW101
-
Type:
-
Motion & Position Sensor, Microwave Radar Sensor
-
Place of Origin:
-
Xiamen
-
Brand Name:
-
OEM/ODM
-
Theory:
-
Doppler
-
Output:
-
Motion & Position Sensor, Microwave Radar Sensor
-
Description::
-
microwave motion sensor
-
Detection Range::
-
360
-
Rated load::
-
1200W (220-240VAC); 600W(100-130VAC)
-
Reach::
-
2-25m (radii.), adjustable
-
Time setting::
-
5s-30min;adjustable
-
HF system::
-
5.8GHz CW radar, ISM band
-
Warranty::
-
5 years
-
Application::
-
Smart Lighting
-
Certificate::
-
CE
-
IP:
-
IP20
Quick Details
-
Use:
-
lights motion sensor
-
Series:
-
microwave motion sensor
-
Features:
-
High frequency
-
Mounting Type:
-
concealed mounting
-
Description:
-
Microwave motion sesnor, Motion & Position Sensor, Microwave Radar Sensor
-
Model Number:
-
YW101
-
Type:
-
Motion & Position Sensor, Microwave Radar Sensor
-
Place of Origin:
-
Xiamen
-
Brand Name:
-
OEM/ODM
-
Theory:
-
Doppler
-
Output:
-
Motion & Position Sensor, Microwave Radar Sensor
-
Description::
-
microwave motion sensor
-
Detection Range::
-
360
-
Rated load::
-
1200W (220-240VAC); 600W(100-130VAC)
-
Reach::
-
2-25m (radii.), adjustable
-
Time setting::
-
5s-30min;adjustable
-
HF system::
-
5.8GHz CW radar, ISM band
-
Warranty::
-
5 years
-
Application::
-
Smart Lighting
-
Certificate::
-
CE
-
IP:
-
IP20
Detail Information:
| Operating voltage | 120 - 240V AC, 50/60Hz. | |||
| Rated load: | 600W@120VAC (capacitive) / 1200W @ 200/240VAC (capacitive) | |||
| Stand-by power | <0.5W | |||
| Detection area | 25%/ 50%/75%/100% | |||
| Hold time | 5s/1min/5min/30min | |||
| Daylight threshold | 5Lux/20Lux/100Lux/Disable ( | |||
| Microwave frequency | 5.8GHz±75MHz | |||
| Microwave power | <0.3mW | |||
| Interfaces | 4-pole pluggable clamp terminal (L,N,N,L’) for 0.75-1.5mm2 cable | |||
| Mounting height | Max.5m(ceiling mounted);Max.3m(wall mounted) | |||
| Detection range | Max.ø12m(ceiling mounted);Max.10m(wall mounted) | |||
| Detection angle | 360° | |||
| Operating temperature | -25°C - +60°C | |||
| IP rating | IP20 | |||
| Warranty | 5 years | |||
Features:
1. Microwave motion detection version.
2. Six DIP switch setting, distance, hold time, daylight sensor adjustable.
3. Ultra-small mounting size, multiple mounting options, support for top and bottom mounting options.
4. Super cost-effective, support a variety of lamps,tri-proof lamps, ceiling lamps.
5. The infrared sensor is used to filter out the light sensor, and the light sensitivity value is more accurate, and is not affected by cloudy and sunny days.
6. Low impedance 5.8G antenna for superior immunity to interference.
Dimension (mm):
Wiring and Structure:
Radiation Pattern:
Function DIP Settings:
Hold-time
Hold-time means the time period to keep the lamp on 100% after motion detected.
Daylight sensor
Daylight sensor means the daylight threshold to enable or disable the sensor function.
"Disable": The sensor works always, even during daylight.
"100lux": The sensor works only in twilight.
"20lux, 5lux": The sensor works only in the dark.
Detection range
Detection range can be reduced by selecting the combination
on the DIP switches to fit precisely each application.
Demo:
