Dongguan Jianlong Hydraulic Machinery Co., Ltd. is located in Dongguan, a famous manufacturing city. Be based in
Liaobu Town, Dongguan City, the company has set up international business division, Guangxi, Shanghai, Hubei office
Our products are exported to the United States, Mexico, Australia, Japan, South Korea, Vietnam,
Singapore and many other countries. Jianlong Hydraulic Machinery Co., Ltd. has more than 10 years of hydraulic press research and development, Design, manufacturing experience, with a number of patented products, always adhering to the "customer first, spirit Enterprising "service concept, for our customers to provide fast and rofessional service!
The company is proficient in all kinds of hydraulic machinery design, manufacturing, sales and other services, the main production Products are: servo multi - direction (3D) forging press, servo four - column double - action tension hydraulic press, wait Serve jigsaw oil press, servo four-column oil press, servo cold forging machine, servo hot press, wait Die casting edge cutter, servo frame type oil press, servo sheet metal shaping oil press, servo Bow (C) shape machine, hydraulic punch and other hydraulic equipment.
The company has passed ISO9001:2015 international quality, integrity management, after-sales service,
CE and other system certification, with a complete and scientific quality system. The company in good faith, strength
And product quality to win the industry recognition, welcome friends from all walks of life to visit Jianlong hydraulic
technology, Guidance and business negotiation.
- Product Details
- {{item.text}}
Quick Details
-
Return Force (kN):
-
2000 kN
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Jianlong
-
Year:
-
2023
-
Voltage:
-
220v/380v
-
Weight (T):
-
4.6 T
-
Model Number:
-
JLA6-200T
-
Motor Power (kw):
-
11 kw
-
Marketing Type:
-
Hot Product 2022
-
Energy Source:
-
Hydraulic
-
High accuracy:
-
0.02mm
-
Mould supply:
-
can be supplied
-
After-sales service provided:
-
Site installation, commissioning and remote technical training
-
Function:
-
Automatic, manual
-
Automation:
-
Configurable automated production line
-
Price:
-
Offer competitive prices
-
Security:
-
High security level
-
Energy saving:
-
25%-50%, low maintenance cost
-
Service life:
-
3-5 years longer than ordinary models
Quick Details
-
Machine Type:
-
Four-column Three-beam Hydraulic Press
-
Slide Stroke (mm):
-
300
-
Ejector Force (kN):
-
55
-
Return Force (kN):
-
2000 kN
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
Jianlong
-
Year:
-
2023
-
Voltage:
-
220v/380v
-
Weight (T):
-
4.6 T
-
Model Number:
-
JLA6-200T
-
Motor Power (kw):
-
11 kw
-
Marketing Type:
-
Hot Product 2022
-
Energy Source:
-
Hydraulic
-
High accuracy:
-
0.02mm
-
Mould supply:
-
can be supplied
-
After-sales service provided:
-
Site installation, commissioning and remote technical training
-
Function:
-
Automatic, manual
-
Automation:
-
Configurable automated production line
-
Price:
-
Offer competitive prices
-
Security:
-
High security level
-
Energy saving:
-
25%-50%, low maintenance cost
-
Service life:
-
3-5 years longer than ordinary models
Our factory
Product introduction
|
item
|
|
Product specifications
|
|
|
||||
|
|
|
JLH2-200TS
|
JLH2-300TS
|
JLH2-500TS
|
||||
|
Master cyinder
|
Capacity
|
200ton
|
300ton
|
500ton
|
||||
|
|
Stroke
|
350mm
|
350mm
|
400mm
|
||||
|
|
Down speed
|
330mm/s
|
320mm/s
|
290mm/s
|
||||
|
|
Press speed
|
40mm/s
|
40mm/s
|
35mm/s
|
||||
|
|
Return speed
|
310mm/s
|
300mm/s
|
280mm/s
|
||||
|
|
Capacity
|
30ton
|
30ton
|
40ton
|
||||
|
|
journey
|
150mm
|
150mm
|
200mm
|
||||
|
|
Capacity
|
3ton
|
3ton
|
5ton
|
||||
|
|
Stroke
|
50mm
|
50mm
|
50mm
|
||||
|
Working table size
|
L-R(Cylinder)
|
550mm
|
600mm
|
650mm
|
||||
|
|
F-B(edge)
|
600mm
|
650mm
|
650mm
|
||||
|
Open height
|
|
600mm
|
700mm
|
900mm
|
||||
|
Motor power
|
|
19kw
|
22kw
|
37kw
|
||||
|
Note: the above parameters are for reference only, order according to the contract.
|
|
|
|
|
||||
Scope of application
Scope of application: 1. Suitable for all kinds of plastic hot pressing and embossing, all kinds of composite sheets and new
materials forming punching process; 2. Suitable for furniture factory, artificial board secondary processing technology; 3. All
kinds of decorative materials: such as PVCX, veneer, sticker decorative cloth leveling, shaping process, etc.
materials forming punching process; 2. Suitable for furniture factory, artificial board secondary processing technology; 3. All
kinds of decorative materials: such as PVCX, veneer, sticker decorative cloth leveling, shaping process, etc.
Company profile
Our company
Product packaging
Why Choose Us
Our workshop
.
The company has 3000 square meters of hydraulic press production base, can manufacture more than 100 sets of hydraulic press at the same time, and has offices in Guangdong, Shanghai, Guangxi and Hubei.
Our Exhibition
.
Our Certificate
.
Jianlong hydraulic Press has passed ISO9001:2015 international quality, integrity management, after-sales service, CE and other system certification and a number of patent certification products, with a complete and scientific mechanical quality management system.
Create more value for customers
Focus on hydraulic machinery for 18 years, a number of listed companies to provide services.
