Quick Details
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HonorMach
-
Model Number:
-
HPW
-
Product name:
-
Hydraulic Winch
-
Material:
-
Steel
-
Motor:
-
Jinjia Brand
-
Usage:
-
Truck Crane
-
Colour:
-
Customer Requirement
-
Packing:
-
Wooden Case
-
Warranty:
-
1 Year
-
Certification:
-
ISO CE
-
Model:
-
HPW
-
Feature:
-
Running Smoothly
Quick Details
-
Power Source:
-
Hydraulic
-
Application:
-
BOAT
-
Capacity:
-
standard
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
HonorMach
-
Model Number:
-
HPW
-
Product name:
-
Hydraulic Winch
-
Material:
-
Steel
-
Motor:
-
Jinjia Brand
-
Usage:
-
Truck Crane
-
Colour:
-
Customer Requirement
-
Packing:
-
Wooden Case
-
Warranty:
-
1 Year
-
Certification:
-
ISO CE
-
Model:
-
HPW
-
Feature:
-
Running Smoothly
Widely Used Double Drum Hydraulic Hoisting Winch 30 Ton For Sale
Product Description
Hydraulic planetary winch is a high torque winch with the rated load 0.5 Ton(1100lbs) to 50 Ton(110000lbs), hydraulic motor have high mechanical efficiency and large torque, can drive different distributor as per different working conditions. This kind of winches have following features:compact structure,small size,light,nice appearance,safety,high efficiency,large torque,good stability,low noise,reliable operation and so on.
HONORMACH HPW Series Hydraulic Winch adopt planetary gear transmission, compact structure, smooth operation, multi-tooth meshing, high transmission efficiency, large output torque, widely used in lifting transportation, engineering machinery, metallurgy, mining, construction machinery and other fields. Grease has been added to this product, and users should replenish grease according to frequency of use (added from 3 small copper caps).
Specification
|
Model
|
HWP-10H
|
HWP-20H
|
HWP-30H
|
HWP-50H
|
|
Pull(kn)
|
20
|
20
|
30
|
50
|
|
Working pressure
|
13Mpa
|
16Mpa
|
18Mpa
|
20Mpa
|
|
Oil flow supply
|
56L/min
|
80L/min
|
80L/min
|
120L/min
|
|
Rope diameter
|
10mm
|
12mm
|
12mm
|
14mm
|
|
Wire rope
|
50m
|
135m
|
110m
|
83m
|
*Notice:We Provide Customized Services For Various Capacity Of Hydraulic Winches From 0.5 Ton (1100 lbs) To 50 Tons(110000 lbs)!*
Product Details
Product Application
Application：Widely used in construction, water conservancy engineering, forestry, mining, wharf, etc. material lifting, also can be used as a modern electronic control automatic operation line supporting equipment.
Packing & Delivery
Standard packing (Wooden case) or Customized packaging according to customer needs.
