Automatic sharpening clipper blades machine blade sharpening machine

Automatic sharpening clipper blades machine blade sharpening machine

FOB Reference Price: Get Latest Price

≥1 Sets

US $4200

≥5 Sets

US $4000

Free Inquiry

Customized Request

Product Details

{{item.text}}

Quick Details

Brand Name:: MLG

Voltage:: 220V/380V110V/440V

Dimension(L*W*H):: 760x740x730

Weight (KG):: 165

Power (kW):: 0.55

Product name:: Blade Grinding Machine

Application:: Grinding Knife

Certification:: CE ISO

After Warranty Service:: Service

Quick Details

Wheel Size(mm):: 125*50*32mm

Year:: 2022.7

Place of Origin:: Shandong, China

Brand Name:: MLG

Voltage:: 220V/380V110V/440V

Dimension(L*W*H):: 760x740x730

Weight (KG):: 165

Power (kW):: 0.55

Product name:: Blade Grinding Machine

Application:: Grinding Knife

Certification:: CE ISO

After Warranty Service:: Service

Grinding Machine Grade Knife Grinder For Plywood Machinery

This knife grinder machine is mainly used in strt blade cutting tool in different angles,suitable for all kinds of cutter tools of plywood,furniture,printing,textile industry etc.It is also used to the oblique opening of high speed tool steel.
The machine tools consists of five parts,incl machine body,sliding plate,motor,grinding head,electrical parts.

Each component has compact structure,rational and beautiful layout,It can make sure the same height and weight and express its unique advantages,so it is ideal for Plywood factory and straight blade knives manufacturers.

Specification

Main Features
1. This machine mainly grind all type of long knives, like peeling machine knife, Granulator knife,cutting paper knife ,Shearing Blades, sliceing knives etc.
2. This machine can work long surface knife. Max. Working length is 1500mm.
3. This machine’s body is a design of gantry body, with the high-quality steel weld,The body has high strength and good rigidity.
4. The worktable use the electro magnetic chuck. And very convenience to clamp knife. The worktable is easy to adjust the angle by worm gear.
5. This machine use the inverter. It can be easy to adjust the horizontal and vertical speed of the grinding head.
6. Job accuracy of machine is 0.01mm.

Specification of Knife grinder machine
Model	knife grinding machine
Grinding wheel speed(m/s)	15
Slide speed(m/s)	4-25m
Maximum grinding length(mm)	3000
Grinding accuracy	≤0.05mm/m
The total weight(KG)	3200

Recommend Products

Other PlywoodMachine

Heavy duty frame guarantee stable for hard wood and soft wood,enlarged the rollers.The surface with chromatin treatment ，higher
wearing resistent and durable.

The body of the machine is welded with high quality steel.It ensures the durability and high precision of the machine's capicity.

Product packaging

Nude packing or according to clients' request for Knife double side surface grinding machine.

Shipping

1) Provide the free consultation of the equipment.

2) Provide the standard device and the flow chart.
3) According to the clients’ special requirement, offering the reasonable plan and free design to help to select the equipment.

Why Choose Us

Advantages:

1. W e have a factory : we are a company integrating industry and trade, we have our own factory, can customize personalized
services for customers.

2. After-sales service : We provide one-year warranty period and solve after-sales problems for customers in a timely manner.
