Quick Details
-
System Power:
-
3.7KW
-
pressure capacity:
-
more than 120 tons of container trucks
-
Operating Temperature::
-
-45℃-65℃
-
the degree of elevation:
-
450mm-800mm
-
Starting Time:
-
≤ 3S
-
Weight:
-
2200kg-5500kg approx
-
control system:
-
hydraulic
Quick Details
-
Place of Origin:
-
Sichuan, China
-
Brand Name:
-
Ricj
-
power supply voltage:
-
380V (control voltage 24V)
-
System Power:
-
3.7KW
-
pressure capacity:
-
more than 120 tons of container trucks
-
Operating Temperature::
-
-45℃-65℃
-
the degree of elevation:
-
450mm-800mm
-
Starting Time:
-
≤ 3S
-
Weight:
-
2200kg-5500kg approx
-
control system:
-
hydraulic
Products Description
Product Application
The Hydraulic Road Blocker are widely used in highway toll stations, checkpoints,airports,agencies,embassies, customs, banks, industrial and mining enterprises, ports, warehouses, parking lots, and all places where vehicle traffic is restricted.
1.The placeman sends instructions through the control system, and the hydraulic transmission enables the roadblock device to quickly ascend and descend.
2.Vehicle passes
3.The roadblock is automatically lifted and lowered by the inductive detection automatic command of the roadblock device or the manual button operation; to control the lane, the door is released or closed. To effectively prevent vehicles from forcibly punching cards.
Specifications
1.The placeman sends instructions through the control system, and the hydraulic transmission enables the roadblock device to quickly ascend and descend.
2.Vehicle passes
3.The roadblock is automatically lifted and lowered by the inductive detection automatic command of the roadblock device or the manual button operation; to control the lane, the door is released or closed. To effectively prevent vehicles from forcibly punching cards.
Specifications
|
Control system
|
Hydraulic (liquid crystal display, English, Russian, Turkish, Spanish,different language menu, the language is customized)
|
|
|
Power supply voltage
|
380V (control voltage 24V)
|
|
|
System Power
|
3.7KW
|
|
|
Pressure capacity
|
120 tons of container trucks
|
|
|
Anti-collision
|
K12 (equivalent to 120KM / hour impact, the car is blocked, the equipment works as usual)
|
|
|
Protection level
|
IP68 (dustproof, waterproof)
|
|
|
Open time
|
2~6S (adjustable)
|
|
|
Closing time
|
2~6S (adjustable)
|
|
|
Communication
|
RS485 ≤ 1200M
|
|
|
Degree of elevation
|
450mm-800mm
|
|
|
Working temperature
|
-45 ° C --- 75 ° C
|
|
|
Hydraulic pressure is adjustable, normal pressure should be adjusted below 50KGF, the maximum cannot exceed 70KGF.
Storage environment: -10 °C - 75 °C, rainproof, moisture proof and dustproof. |
|
|
|
SPECIFICATIONS FOR
HYDRAULIC ROADBLOCK MACHINE
|
|
|
|
|||
|
Model
|
Dimensions
|
Flip height
|
Remark
|
|||
|
RB-101-3
|
L3000*W1050*H600mm
|
450-600mm
|
Size can be customized
|
|||
|
RB-101-4
|
L4000*W1050*H600mm
|
450-600mm
|
Size can be customized
|
|||
|
RB-101-5
|
L5000*W1050*H600mm
|
450-600mm
|
Size can be customized
|
|||
|
Thickness Customizable size: 20-30mm Increased customizable size: 400-800mm
|
|
|
|
|||
Main Features
1. Durable, Overload, Operate Smoothly, Low Noise, Fast speed up&down
2. Micro-control technology makes bollards work stable and reliable, Easily integrate to other systems
3. Compatible with road barrier, Turnstiles and other access system control to achieve automatic control
4.Advanced mature Hydraulic pressure technologies
5. Remote control system realize wireless control up&down within 30 meters range
6.Customized for different users requests
7.Controller display: LCD and LED
8. Swiping card system: built-in card reader to control bollards up&down
9. Road barrier integrate with Bollards: built-in access control realize road barrier, A/C and bollards in one-card
10.Connected with Computer Management OR Charging Systems
