Quick Details
-
Positioning Accuracy (mm):
-
0.03 mm
-
Travel (X Axis)(mm):
-
400 mm
-
Travel (Y Axis)(mm):
-
600 mm
-
Repeatability (X/Y/Z) (mm):
-
0.03 mm
-
Spindle Motor Power(kW):
-
300-800w
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
E-CUT
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
90*70*52.5cm
-
Power (kW):
-
800
-
Weight (KG):
-
25
-
Product name:
-
CNC 4060
-
After-sales Service Provided:
-
Online Technical Support
-
Function:
-
Wood Acylic Plywood MDF Engraving
-
Spindle power:
-
300-800w
Quick Details
-
Working Table Size(mm):
-
40*60
-
Machine Type:
-
CNC Router
-
Range of Spindle Speed(r.p.m):
-
0 - 12000 rpm
-
Positioning Accuracy (mm):
-
0.03 mm
-
Travel (X Axis)(mm):
-
400 mm
-
Travel (Y Axis)(mm):
-
600 mm
-
Repeatability (X/Y/Z) (mm):
-
0.03 mm
-
Spindle Motor Power(kW):
-
300-800w
-
Place of Origin:
-
Anhui, China
-
Brand Name:
-
E-CUT
-
Voltage:
-
220V
-
Dimension(L*W*H):
-
90*70*52.5cm
-
Power (kW):
-
800
-
Weight (KG):
-
25
-
Product name:
-
CNC 4060
-
After-sales Service Provided:
-
Online Technical Support
-
Function:
-
Wood Acylic Plywood MDF Engraving
-
Spindle power:
-
300-800w
Specification
|
Paramenters
|
|
|
|
|||
|
Model
|
CNC3020
|
CNC3040
|
CNC4060
|
|||
|
|
|
|
|
|||
|
Reset positioning accuracy
|
0.05MM
|
0.05MM
|
0.03MM
|
|||
|
|
|
|
|
|||
|
Precision
|
0.05MM
|
0.05MM
|
0.03MM
|
|||
|
|
|
|
|
|||
|
Voltage
|
220V/110V
|
220V/110V
|
220V/110V
|
|||
|
|
|
|
|
|||
|
Power
|
300W
|
300W
|
800W
|
|||
|
|
|
|
|
|||
|
Spindle motor speed
|
3000-12000rpm
|
3000-12000rpm
|
24000rpm
|
|||
|
|
|
|
|
|||
|
XYZ effective stroke
|
200*300*55MM
|
300*400*55MM
|
400*600*75MM
|
|||
|
|
|
|
|
|||
|
Transfer method
|
T12*2 Screw
|
|
605screw rod
|
|||
|
|
|
|
|
|||
|
Control System
|
MACH3
|
|
MACH3
|
|||
|
|
|
|
|
|||
|
Stepper motor
|
57series stepper motor
|
|
57series stepper motor
|
|||
|
|
|
|
|
|||
|
Frame material
|
Aluminum structure,12MM aluminumplate
|
|
Aluminum structure,12MM aluminumplate
|
|||
|
|
|
|
|
|||
|
Machine dimensions
|
56*45.5*43cm
|
66*53.5*43cm
|
91*69*52cm
|
|||
|
|
|
|
|
|||
|
package size
|
54*43*43.5cm
|
65*52*44.5cm
|
90*70*52.5cm
|
|||
|
|
|
|
|
|||
|
Machinable materials
|
PVC/Wood,Plastic,Jade(customized)etc,;
|
|
PVC/Wood,Plastic,Jade(customized)etc,;
|
|||
|
|
|
|
|
|||
|
Weight
|
26Kg
|
31Kg
|
62Kg
|
|||
|
|
|
|
|
|||
Application and Working Samples
1) Advertising industry. Engrave and cut various signboards, marble, copper, character mold, font. And various metal sign, brand.
2) Woodworking industry. Solid wood furniture, custom furniture, furniture decoration, musical instrument manufacturing, wooden handicrafts, art models, artistic font characters, logos, plate plane carving, artistic murals, screen relief carving and cutting, decoration processing, gift packaging, wave boards, Cutting the three-dimensional surface and shape of various wooden industrial products such as electrical appliances, sporting goods, etc.
3) Decorate industry. Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper, aluminum plate engraving and milling process.
4) Craft & gift industry. Engrave various word or graph on the souvenir and handicraft, ironwork engraving, dials.
5) Plate processing. Insulation part, plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti bate
board,epoxy resin, ABS, PP, PE and other carbon mixed compounds.
6) Mold industry. It can engrave various molds, wooden molds, fonts, aviation wooden molds, propellers, building models, sand table models, motorboat models, automobile foam molds, etc
1) Advertising industry. Engrave and cut various signboards, marble, copper, character mold, font. And various metal sign, brand.
2) Woodworking industry. Solid wood furniture, custom furniture, furniture decoration, musical instrument manufacturing, wooden handicrafts, art models, artistic font characters, logos, plate plane carving, artistic murals, screen relief carving and cutting, decoration processing, gift packaging, wave boards, Cutting the three-dimensional surface and shape of various wooden industrial products such as electrical appliances, sporting goods, etc.
3) Decorate industry. Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper, aluminum plate engraving and milling process.
4) Craft & gift industry. Engrave various word or graph on the souvenir and handicraft, ironwork engraving, dials.
5) Plate processing. Insulation part, plastic chemical components, PCB, inner body of car, bowling tracks, stairs, anti bate
board,epoxy resin, ABS, PP, PE and other carbon mixed compounds.
6) Mold industry. It can engrave various molds, wooden molds, fonts, aviation wooden molds, propellers, building models, sand table models, motorboat models, automobile foam molds, etc
