Quick Details
-
Color:
-
full color
-
Panel Size:
-
(W)320mm*160mm(H), (W)320mm*160mm(H)
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
outdoor led display
-
Pixel Pitch:
-
1.86MM/2MM/2.5MM, 1.86MM/2MM/2.5MM
-
Brightness:
-
800nits, 800nits
-
Color Depth:
-
1R1G1B, 1R1G1B
-
Lifespan (hours):
-
100000Hours, 100000Hours
-
View Angle（H/V）:
-
Horizontal >170 Vertical>120, Horizontal >170 Vertical>120
-
Product name:
-
Led Video Display Panel
-
Usage:
-
Outdoor Adverting Display
-
Keyword:
-
Waterproof LED Display Screen Panels
-
Certificate:
-
CE ROHS FCC
-
Size:
-
Customized Product
-
Display Function:
-
Video/Text/Picture/Time/3D Text/Office/SWF
-
Installation:
-
Fixed Installation
-
Material:
-
Metal Case + Toughened Glass Panel
Quick Details
-
Application:
-
Outdoor
-
Type:
-
LED
-
Brand Name:
-
HaoXian
-
Color:
-
full color
-
Panel Size:
-
(W)320mm*160mm(H), (W)320mm*160mm(H)
-
Place of Origin:
-
Guangdong, China
-
Model Number:
-
outdoor led display
-
Pixel Pitch:
-
1.86MM/2MM/2.5MM, 1.86MM/2MM/2.5MM
-
Brightness:
-
800nits, 800nits
-
Color Depth:
-
1R1G1B, 1R1G1B
-
Lifespan (hours):
-
100000Hours, 100000Hours
-
View Angle（H/V）:
-
Horizontal >170 Vertical>120, Horizontal >170 Vertical>120
-
Product name:
-
Led Video Display Panel
-
Usage:
-
Outdoor Adverting Display
-
Keyword:
-
Waterproof LED Display Screen Panels
-
Certificate:
-
CE ROHS FCC
-
Size:
-
Customized Product
-
Display Function:
-
Video/Text/Picture/Time/3D Text/Office/SWF
-
Installation:
-
Fixed Installation
-
Material:
-
Metal Case + Toughened Glass Panel
Product Description
Our product advantages .
1：Can be customized size
2：A variety of control methods can be selected
3：Uninterrupted testing for 72 hours
4：Free warranty for 3 years
5：10 years of production experience, 1000+ project cases
6：Used at stage,bank, promotion, exhibition, station, KTV, stadium, airport and other
outdoor places.
Specification
|
Product Model
|
P2.5
|
p3
|
p4
|
p5
|
p6
|
outdoor P8
|
p10
|
||||||
|
Pixel Density(dots/sqm)
|
160000
|
111111
|
62500
|
40000
|
27777
|
15625
|
10000
|
||||||
|
cabinet Size
|
960 x 960mm
|
|
|
|
|
|
|
||||||
|
Weight
|
35Kg/PCS
|
|
|
|
|
20Kg/pcs
|
|
||||||
|
Brightness
|
5000cd/square meter
|
|
|
|
|
6000cd/sqm
|
|
||||||
|
Scan Mode
|
1/16 Scan
|
1/16 Scan
|
1/10 Scan
|
1/8 Scan
|
1/8 Scan
|
1/4 Scan
|
1/4 Scan
|
||||||
|
Viewing Angle
|
Horizontal:120°,Vertical:120°
|
|
|
|
|
|
|
||||||
|
Best Viewing Distance
|
2.5-300m
|
3-300m
|
4-300m
|
5-300m
|
6-300m
|
8-300m
|
10-300m
|
||||||
|
Waterproof Level
|
Front IP65,Back IP54
|
|
|
|
|
|
|
||||||
|
Refresh Rate
|
1920Hz
|
|
|
|
|
|
|
||||||
|
Average Power Consumption
|
400W/sqm
|
400W/sqm
|
320W/sqm
|
240W/sqm
|
240W/sqm
|
240W/sqm
|
240W/sqm
|
||||||
|
Working Temperature
|
﹣20℃ ~ ﹢ 50℃
|
|
|
|
|
|
|
||||||
|
Control System
|
Synchronous control / asynchronous control
|
|
|
|
|
|
|
||||||
|
Life Span
|
100,000 hours
|
|
|
|
|
|
|
||||||
Details Images
Outdoor LED display screen .
1. Cabinet Size: 960×960mm
2. SMD LED; High brightness: 6000nits, and brightness adjustable,High intensity.
3. Standard processing technology to ensure each row and each column lamps at the same horizontal line, and ensure light consistency and clear, stability pictures.
4. SD to ensure large viewing angle, up to 120° horizontally and 120° vertically. Image no distortion, no color cast in any angle within this range.
5. Cabinet design lightweight, easy to maintain, IP65 high-performance waterproof and dust resistance.
The outdoor LED Display Price is manufactured by using best quality material, purchased from most reputed vendors. The final products feature supreme quality and offers best outputs. High refresh rate and gray scale ensures the picture quality remains seamless.
The display features a wide viewing angle
of 120°horizontal and 120° in vertical whic
reaches more viewers. The picture quality
remains seamless in all direction and at a
distance, presenting all viewers the same
highly quality outputs. This makes it suitable
for large gathering
Installation type
Applications
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
