Quick Details
-
Rated Lifting Moment:
-
1000KN.M
-
Span:
-
30~80m
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
YONGMAO
-
Make:
-
SYM/SCM/Zoomlion
-
Weight (KG):
-
20000 kg
-
After-sales Service Provided:
-
Overseas service center available
-
Product name:
-
QTZ80 used topless tower crane
-
Color:
-
Yellow
-
Working radius (m):
-
30-70
-
Type:
-
Flat Top
-
Tip load:
-
1.6 Ton
-
Main Material:
-
Q235B/Q345B
-
Power Supply:
-
380V 50Hz/440V 60Hz
-
Slewing speed:
-
0.62 R/min
-
Name:
-
Tower Crane Spare Parts
Quick Details
-
Rated Loading Capacity:
-
8 Ton, 10 TON, 4.5t
-
Max. Lifting Height:
-
Other, 200m
-
Application:
-
Residential Buildings
-
Rated Lifting Moment:
-
1000KN.M
-
Span:
-
30~80m
-
Place of Origin:
-
Liaoning, China
-
Brand Name:
-
YONGMAO
-
Make:
-
SYM/SCM/Zoomlion
-
Weight (KG):
-
20000 kg
-
After-sales Service Provided:
-
Overseas service center available
-
Product name:
-
QTZ80 used topless tower crane
-
Color:
-
Yellow
-
Working radius (m):
-
30-70
-
Type:
-
Flat Top
-
Tip load:
-
1.6 Ton
-
Main Material:
-
Q235B/Q345B
-
Power Supply:
-
380V 50Hz/440V 60Hz
-
Slewing speed:
-
0.62 R/min
-
Name:
-
Tower Crane Spare Parts
Product Description
All Inverter control,mechanisms run smoothly, little impact for tower crane while speed changing; Schneider and Simmens for electrical parts;
Compact conformation, light weight and easy to be repaired; large-diameter drum with double fold line groove has a good performance of laying rope, enables long life of steel wire rope.
A full range of advanced high accuracy equipments were used, including digital drilling and cutting machine, welding robot, automatic painting line...; very high dimension accuracy, highly exchangible; raw material from best steel manufacturer; Ultrasonic crack detection for all the steel parts;strict and thorough test before shipping.
|
|
| Model | 6016 |
| Max Load | 8/10t |
| Tip Load | 1.6t |
| Jib Length | 60m |
| Hoist Height | 45m |
| Lift Speed | 0-80m/min |
| Trolley Speed | 0-55m/min |
| Slewing Speed | 0-0.6r/min |
Reference model for your choose
| Model | Jib Length(m) | Tip Load | Max Load(ton) |
| K30/30(QTZ250tm) | 70m | 3.0t | 12t |
| k35/32(QTZ270tm) | 70m | 3.2t | 14t |
| K40/21(QTZ280tm) | 70m | 2.1t | 16t |
