1. The machine's body width is only 900mm, allowing it to maneuver freely in narrow spaces such as through backyard gates for operation. 2. Its boom features a vertical lift design, with the pin height of the bucket reaching up to 2350mm (compared to industry counterparts at just 2100mm), enabling loading onto high-sided trucks. 3. The engine is selected from EPA and Euro V dual-certified diesel options - either a British Perkins 403J-18.5KW or a Japanese Kubota D902-18.5KW. The hydraulic system adopts an Italian HANSA closed-loop system, which is a mainstream configuration among international skid steer loader brands. Operation is carried out via a pilot control handle that allows single-handed control of movement while also precisely operating the boom and bucket during travel. 4. The boom comes standard with a float function, ensuring that when using sweeping attachments, it can follow the contours of the ground. 5. The operator's position is equipped with foam padding for added comfort.
- Product Details
- {{item.text}}
Quick Details
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
1992mmX1050mm(820mm)X1210mm
-
Machine Weight:
-
1538 kg
-
Bucket capacity:
-
0.08CBM
-
Marketing Type:
-
New Product 2024
-
Product name:
-
STR 1000
-
Cutting-edge Design:
-
Closed Hydraulic System
-
Engine:
-
Kubota/Perkins
-
Rotating speed (rpm):
-
3600
-
Noise (Db):
-
≤95
-
Pressure (Mpa):
-
17
-
bucket Capacity:
-
0.08 m³
-
Max Lifting Force:
-
300 Kg
-
Customization:
-
Color/Logo/Fuselage Sticker
-
Provide support:
-
TUV and other third party door-to-door inspection service
Quick Details
-
Engine Brand:
-
Perkins
-
Power:
-
18.5 KW (25HP)
-
Brand Name:
-
STR
-
Place of Origin:
-
Shandong, China
-
Dimension(Long * Breadth * High):
-
1992mmX1050mm(820mm)X1210mm
-
Machine Weight:
-
1538 kg
-
Bucket capacity:
-
0.08CBM
-
Marketing Type:
-
New Product 2024
-
Product name:
-
STR 1000
-
Cutting-edge Design:
-
Closed Hydraulic System
-
Engine:
-
Kubota/Perkins
-
Rotating speed (rpm):
-
3600
-
Noise (Db):
-
≤95
-
Pressure (Mpa):
-
17
-
bucket Capacity:
-
0.08 m³
-
Max Lifting Force:
-
300 Kg
-
Customization:
-
Color/Logo/Fuselage Sticker
-
Provide support:
-
TUV and other third party door-to-door inspection service
Earth-moving Machinery Crawler Loader high intensity work mini front end skid steer loader with skid loader attachments
PRODUCT SPECTFICATION
DRT-V1000 Skid Steer Loader Highlights（Advantages）
1. The machine's body width is only 900mm, allowing it to maneuver freely in narrow spaces such as through backyard gates for operation. 2. Its boom features a vertical lift design, with the pin height of the bucket reaching up to 2350mm (compared to industry counterparts at just 2100mm), enabling loading onto high-sided trucks. 3. The engine is selected from EPA and Euro V dual-certified diesel options - either a British Perkins 403J-18.5KW or a Japanese Kubota D902-18.5KW. The hydraulic system adopts an Italian HANSA closed-loop system, which is a mainstream configuration among international skid steer loader brands. Operation is carried out via a pilot control handle that allows single-handed control of movement while also precisely operating the boom and bucket during travel. 4. The boom comes standard with a float function, ensuring that when using sweeping attachments, it can follow the contours of the ground. 5. The operator's position is equipped with foam padding for added comfort.
1. The machine's body width is only 900mm, allowing it to maneuver freely in narrow spaces such as through backyard gates for operation. 2. Its boom features a vertical lift design, with the pin height of the bucket reaching up to 2350mm (compared to industry counterparts at just 2100mm), enabling loading onto high-sided trucks. 3. The engine is selected from EPA and Euro V dual-certified diesel options - either a British Perkins 403J-18.5KW or a Japanese Kubota D902-18.5KW. The hydraulic system adopts an Italian HANSA closed-loop system, which is a mainstream configuration among international skid steer loader brands. Operation is carried out via a pilot control handle that allows single-handed control of movement while also precisely operating the boom and bucket during travel. 4. The boom comes standard with a float function, ensuring that when using sweeping attachments, it can follow the contours of the ground. 5. The operator's position is equipped with foam padding for added comfort.
PRODUCT PARAMENTERS
|
No
|
Item
|
Metric
|
U.S.
|
|
1
|
Max working height (H3）
|
3028 mm
|
119.2 inch
|
|
2
|
Max pin height (H2)
|
2352 mm
|
92.6 inch
|
|
3
|
Max Dumping height (H1)
|
1730 mm
|
68.1 inch
|
|
4
|
Max Dumping distance(E)
|
900 mm
|
35.4 inch
|
|
5
|
Max Dumping Angle (a3)
|
95°
|
95°
|
|
6
|
Rollback of bucket on ground (a2)
|
25°
|
25°
|
|
7
|
Departure angle (a1)
|
28°
|
28°
|
|
8
|
Total height (H)
|
1405 mm
|
55.3 inch
|
|
9
|
Ground clearance (F)
|
185 mm
|
7.3 inch
|
|
10
|
Wheel base (L1)
|
1435 mm
|
56.5 inch
|
|
11
|
Overall length without bucket (L3)
|
2152 mm
|
84.7 inch
|
|
12
|
Total width (B2)
|
900 mm
|
35.4 inch
|
|
13
|
Bucket width (B1)
|
920 mm
|
36.2 inch
|
|
14
|
Total length with bucket (L)
|
2895 mm
|
114.1 inch
|
|
15
|
Turn radius forward turning (R)
|
1740 mm
|
68.5 inch
|
|
16
|
Rated Power (KW)
|
18.4KW(25HP)
|
|
|
17
|
Rotating speed (rpm)
|
2800
|
|
|
18
|
Noise (Db)
|
≤95
|
|
|
19
|
Pressure (Mpa)
|
2.4
|
|
|
20
|
Raise
|
4
|
|
|
21
|
Dump
|
1.3
|
|
|
22
|
Lower
|
3.2
|
|
|
16
|
Operating Load
|
454 Kg
|
1000 Lb
|
|
20
|
Bucket Capacity
|
0.18 m³
|
3 ft³
|
|
21
|
Max Lifting Force
|
300 Kg
|
661.39 Lb
|
|
22
|
Travel Speed
|
0-5.8 Km/h
|
3.73 mlie/h
|
|
23
|
Operating Weight
|
1538 Kg
|
3390 Lb
|
OUR ADVANTAGES
The engine is selected from EPA and Euro V dual-certified diesel options - either a British Perkins 403J-18.5KW or a Japanese Kubota D902-18.5KW.
The Attachment adopts international standard quick-change, easy to disassemble and replace.
The machine's body width is only 900mm, allowing it to maneuver freely in narrow spaces such as through backyard gates for operation.
Its boom features a vertical lift design, with the pin height of the bucket reaching up to 2350mm (compared to industry counterparts at just 2100mm), enabling loading onto high-sided trucks.
The hydraulic system adopts an Italian HANSA closed-loop system, which is a mainstream configuration among international skid steer loader brands. Operation is carried out via a pilot control handle that allows single-handed control of movement while also precisely operating the boom and bucket during travel.
The operator's position is equipped with foam padding for added comfort.
DETAILS IMAGES
A CORNER OF THE FACTORY AND SHIPPING
Attachment Parameters
Tiller
Mixer
Auger+Auger drill
Sweeper with bucket
Angel blade
Snow blower
Backhoe
Grapple
Trench filler
Log Splitter/Branch crusher
Stump grinder
Stump grinder
Trencher
Fork
Brush cutter
Lawn mower
FAQ
Q: Are you original manufacturer?
A: Yes. We are manufacturer of construction machines and you can take a video tour of our factory anytime during working hours.
Q: How long is the machine warranty time?
A: One year.
Q: How should we do if the machine broken ?
A: You can take a video to us and our technicians will analyze the cause of the problem based on the video.
Q: How should we do if parts are broken ?
A: We advise customers to purchase some conventional accessories based on their country and
environment. If other parts broke ,we will send to you by sea or by air.
environment. If other parts broke ,we will send to you by sea or by air.
Q: What is the delivery time ?
A: Generally we need 5-7 days to produce the machine after prepayment ,if you are urgent , 3 days will be ok ,then send to port.
Q: What is the terms of payment?
A: :Normally, we accept 20% advance, 80% should be paid after finished the machine, L/C at sight.
