Quick Details
-
Place of Origin:
-
Henan, China
-
Product name:
-
Compact Bridgman Crystal Growth Furnace
-
Max temperature:
-
1200C/1700C
-
Voltage:
-
110V/220V
-
heating tube:
-
High purity quartz
-
tube dia:
-
50mm/60mm/80mm
-
Two Heating Zone:
-
100 mm
-
Pulling speed range:
-
1-500 um/sec adjustable
Quick Details
-
Warranty:
-
2 YEARS
-
Brand Name:
-
SCK
-
Model Number:
-
OTF-1200X-S-VT-BMGH
-
Place of Origin:
-
Henan, China
-
Product name:
-
Compact Bridgman Crystal Growth Furnace
-
Max temperature:
-
1200C/1700C
-
Voltage:
-
110V/220V
-
heating tube:
-
High purity quartz
-
tube dia:
-
50mm/60mm/80mm
-
Two Heating Zone:
-
100 mm
-
Pulling speed range:
-
1-500 um/sec adjustable
Factory custom OTF-1200X-S-VT-BMGH 1200ºC Bridgman crystal growth furnace
SCK-OTF-1200X-S-VT-BMGH is a compact and economic 1200ºC Maximum Bridgman crystal growth furnace with 2" quartz tube and precision hanged wire travel mechanism, which is designed for growing small size crystal under control atmosphere or sealed quartz crucible at low cost.
(factory Support customization, including accessories and consumables, please contact our staff for details.)
SPECIFICATIONS:
|
Vertical Two Zone Tube Furnace
|
Compact two zones split vertical tube furnace. Working Voltage: 110V AC or 220V selectable Max. Power Consumption: 1.5 KW Two Heating Zone: 100 mm L for each Zone , 200 mm L in total Max. heating temperature: 1200°C Continuous working temperature: 1100°C Two programmable digital temperature controllers which control two heating zone independently. Max. Temperature gradient: 1ºC/Cm |
|
|
Three sets of Ni-SShanging wire are included Max. working temperature is 800C. Optional hanging wire for higher working temperature is available upon request: Ni-Cr-Al wire ( not included ) Max. working temperature < 1100°C Platinium wire ( not included ) Max.working temperature >1200°C ,<1600°C Thin hanging wire goes through the top flange. Positive inert gas can keep processing tube under controlled atmosphere. For air sensitive material, sample shall be sealed in a small quartz tube with pre-vacuumed as Pic below right |
|
Motor and controller
|
6"L x 4"W Touch Screen Unit is built in controlling DC motor rotating and wire traveling speed Wire descending speed is programmable within 3 segments. Descending speed range : 1-500 um/sec adjustable with accuracy of +/- 0.05% Lower speed range is available upon request at extra cost Total stoke length: 450mm High-quality DC motor is installed for rotating hanging wire for at extra cost and pulling up Power: 50W, 110V - 240V C |
|
Product Dimensions |
520mm(L) x 430mm(W) x 1100 mm(H).78KG |
|
Compliance |
CE Certified |
|
Warranty |
2 Years limited warranty with lifetime support |
