No. of Cells: 120 cells
Dimension: 1754×1096×30 mm
Weight: 21.0 kg
Modules per box: 36pcs
Modules per 40' container: 936pcs
Dimension: 1754×1096×30 mm
Weight: 21.0 kg
Modules per box: 36pcs
Modules per 40' container: 936pcs
- Product Details
- {{item.text}}
Quick Details
-
Warranty:
-
25years
-
Brand Name:
-
Alicosolar/OEM
-
Model Number:
-
182/210-560M
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2294*1134*35 mm/Larger/OEM
-
Product name:
-
560w solar panel 650w
-
Keyword:
-
Alicosolar/ OEM
-
Application:
-
For solar panel sun power
-
Junction Box:
-
IP68 Rated
-
Connector:
-
PV Compatible Connector
-
Front Cover:
-
3.2mm Thickness PET
-
Cell Type:
-
Mono 182*182 mm
-
Cable:
-
4mm2
-
OEM:
-
Avilable
-
Certificate:
-
CE/TUV
Quick Details
-
Cell size:
-
182mmx182mm
-
Type:
-
Half Cell, Bifacial, Double-glass, All Black
-
Panel Efficiency:
-
20.X%-22.X %
-
Warranty:
-
25years
-
Brand Name:
-
Alicosolar/OEM
-
Model Number:
-
182/210-560M
-
Place of Origin:
-
Jiangsu, China
-
Panel Dimensions:
-
2294*1134*35 mm/Larger/OEM
-
Product name:
-
560w solar panel 650w
-
Keyword:
-
Alicosolar/ OEM
-
Application:
-
For solar panel sun power
-
Junction Box:
-
IP68 Rated
-
Connector:
-
PV Compatible Connector
-
Front Cover:
-
3.2mm Thickness PET
-
Cell Type:
-
Mono 182*182 mm
-
Cable:
-
4mm2
-
OEM:
-
Avilable
-
Certificate:
-
CE/TUV
Product Introduction
Grade A Material
|
Electrical Characteristics/ Vertex Series
|
|
|
|
|
|
|||||
|
Maximum Power（Pmax/W）
|
415
|
420
|
425
|
430
|
435
|
|||||
|
Voltage at Maximum Power(Vmp/V)
|
41.7
|
42.0
|
42.2
|
42.3
|
42.5
|
|||||
|
Current at Maximum Power(Imp/A)
|
9.94
|
10.01
|
10.08
|
10.17
|
10.24
|
|||||
|
Open Circuit Voltage（Voc/V)
|
50.0
|
50.1
|
50.2
|
50.3
|
50.4
|
|||||
|
Short Circuit Current(lsc/aA)
|
10.55
|
10.58
|
10.61
|
10.64
|
10.67
|
|||||
|
Module Efficiency(%)
|
20.8
|
21.0
|
21.3
|
21.5
|
21.8
|
|||||
|
Electrical Characteristics/ Alicosolar Series
|
|
|
|
|
|
|||||
|
Maximum Power（Pmax/W）
|
530
|
535
|
540
|
545
|
550
|
|||||
|
Voltage at Maximum Power(Vmp/V)
|
41.7
|
41.8
|
41.9
|
42
|
42.1
|
|||||
|
Current at Maximum Power(Imp/A)
|
12.71
|
12.8
|
12.89
|
12.98
|
13.07
|
|||||
|
Open Circuit Voltage（Voc/V)
|
49.5
|
49.6
|
49.7
|
49.8
|
49.9
|
|||||
|
Short Circuit Current(lsc/aA)
|
13.44
|
13.53
|
13.62
|
13.71
|
13.8
|
|||||
|
Module Efficiency(%)
|
20.5
|
20.7
|
20.9
|
21.1
|
21.3
|
|||||
|
Electrical Characteristics/ 650W+ Series
|
|
|
|
|
|
|||||
|
Maximum Power（Pmax/W）
|
650
|
655
|
660
|
665
|
670
|
|||||
|
Voltage at Maximum Power(Vmp/V)
|
37.61
|
37.81
|
38.01
|
38.21
|
38.41
|
|||||
|
Current at Maximum Power(Imp/A)
|
17.28
|
17.32
|
17.36
|
17.40
|
17.44
|
|||||
|
Open Circuit Voltage（Voc/V)
|
45.58
|
45.28
|
45.98
|
46.18
|
46.38
|
|||||
|
Short Circuit Current(lsc/aA)
|
18.16
|
18.21
|
18.26
|
18.31
|
18.36
|
|||||
|
Module Efficiency(%)
|
20.92
|
21.09
|
21.25
|
21.43
|
21.57
|
|||||
No. of Cells: 120 cells
Dimension: 1754×1096×30 mm
Weight: 21.0 kg
Modules per box: 36pcs
Modules per 40' container: 936pcs
Dimension: 1754×1096×30 mm
Weight: 21.0 kg
Modules per box: 36pcs
Modules per 40' container: 936pcs
No. of Cells: 120 cells
Dimension: 1754×1096×30 mm
Weight: 21.0 kg
Modules per box: 36pcs
Modules per 40' container: 936pcs
Dimension: 1754×1096×30 mm
Weight: 21.0 kg
Modules per box: 36pcs
Modules per 40' container: 936pcs
Vertex
No. of Cells: 132 cells
Dimension: 2384×1303×35 mm mm
Weight: 33.6 kg
Modules per box: 31pcs
Modules per 40' container: 558pcs
Dimension: 2384×1303×35 mm mm
Weight: 33.6 kg
Modules per box: 31pcs
Modules per 40' container: 558pcs
Professional Packing
Tier 1 Solar Module
Manufcturer Show
Why Choose Us - QC
Solar Cell String EL Testing
Each solar PV cell string must be tested by EL machine to ensure every single solar cell is perfect.
EL Testing Before Lamination
Each Solar Module must be tested by EL machine before lamination to ensure every solar cell string is perfect.
Appearance Inspection After Lamination
Each Solar Module must be inspected by QC after lamination to ensure there is no defect during lamination.
Final EL Testing
Final EL Testing 100% ensure zero intenal electric defect for each solar module.
Output Power Testing
Output power testing ensure 100% positive power tolerance and excellent power performance.
Final Appearance Inspection
Each Solar Module must be inspected by QC before packaging to ensure there is no defect during production process.
Projects Shown
Utility Scale
With years of professional experience, Alicosolar can provide you the perfect module product for your perfect projects so as to maximize your benefits of investments.
Commercial
Either self-consumption or selling to the grid, commercial projects provide system owners with a new way of investment, in which module plays a key role. And Alicosolar was, is, and will always be a reliable partner which you won`t regret to choose.
Residential
Thousands of houses around the globe are equipped with Alico solar panel systems, so they can now enjoy the clean power with a lower electricity bill and moreover, make profits from them.
