Quick Details
-
Brand Name:
-
LW
-
Model Number:
-
Float switch
-
Material:
-
Plastic
-
Mode:
-
GAS
-
Product name:
-
Water Level Sensor
-
Media Type:
-
Gas
-
Flow Rate:
-
100000 Times
-
Operating Temperature:
-
0~80 (Rubber Cable)
-
Rated voltage:
-
250V(380V)/120V
-
Rated current:
-
15(8)A 10(4)A
-
Working temperature:
-
0
-
Protection Grade:
-
IP68
-
Mechanical endurance:
-
≥300.000 times
-
Electrical endurance:
-
≥50.000 times
Quick Details
-
Grade:
-
Industrial
-
Warranty:
-
1Year
-
Place of Origin:
-
Zhejiang, China
-
Brand Name:
-
LW
-
Model Number:
-
Float switch
-
Material:
-
Plastic
-
Mode:
-
GAS
-
Product name:
-
Water Level Sensor
-
Media Type:
-
Gas
-
Flow Rate:
-
100000 Times
-
Operating Temperature:
-
0~80 (Rubber Cable)
-
Rated voltage:
-
250V(380V)/120V
-
Rated current:
-
15(8)A 10(4)A
-
Working temperature:
-
0
-
Protection Grade:
-
IP68
-
Mechanical endurance:
-
≥300.000 times
-
Electrical endurance:
-
≥50.000 times
Product Description
Application
Float switch is using microswitch to be contact elements.When the liquid level rises to the float place, angle of floats place
will be changed by the liquid level. When it reaches an certain angle, there will be ON or OFFcontact signal output at the
switches.
This water pump float switch is widely used to control the liquid level. Our float switch quality is stable, safe,Flaot Switch's
operation voltage is 220vac, and current can be up to 15A. Applies to branch water,sewage,aid-base solution and oil.
will be changed by the liquid level. When it reaches an certain angle, there will be ON or OFFcontact signal output at the
switches.
This water pump float switch is widely used to control the liquid level. Our float switch quality is stable, safe,Flaot Switch's
operation voltage is 220vac, and current can be up to 15A. Applies to branch water,sewage,aid-base solution and oil.
Specification
|
Rated Voltage
|
250V (380V) / 120V
|
|
Rated current
|
16A(8A); 10A(8A); 10A(4A)
|
|
Working temperature
|
0℃ - 80℃
|
|
Mechanical endurance
|
≥300000 times
|
|
Electrical endurance
|
≥50000 times
|
|
Protection grade
|
IP68
|
