Quick Details
-
Driven type:
-
Diesel engine
-
Theoretic output:
-
30 m3/h
-
Max. aggregate size:
-
40mm
-
Conveying pipe ID.:
-
125mm
-
Conveying distance:
-
150/300m
-
Pumping system oil pressure:
-
30 Mpa
-
Mixing system oil pressure:
-
14Mpa
-
Hopper capacity:
-
400L
-
Hydraulic oil tank:
-
280L
Quick Details
-
Power Type:
-
Diesel/Electric
-
Place of Origin:
-
Henan, China
-
Product name:
-
KBJ-30D Concrete Mixer Pump
-
Driven type:
-
Diesel engine
-
Theoretic output:
-
30 m3/h
-
Max. aggregate size:
-
40mm
-
Conveying pipe ID.:
-
125mm
-
Conveying distance:
-
150/300m
-
Pumping system oil pressure:
-
30 Mpa
-
Mixing system oil pressure:
-
14Mpa
-
Hopper capacity:
-
400L
-
Hydraulic oil tank:
-
280L
KBJ-30D Concrete Pump with Mixer
Portable Concrete Pump Diesel Engine Portable Concrete Mixer Pump with Remote Control
Concrete Mixer Pump Introduction:
1. KBJ Concrete Mixer Pump combines concrete mixer and concrete pump as one new concrete pumping machine with concrete mixer.
2. Concrete mixer is driven by two mixing motor and grinding wheel rotation, with uniform mixing, thorough discharging and stable performance.
3. Concrete pump has double cylinder hydraulic pump system with reliable performance.
4. Concrete Mixer Pump spare parts are from high quality products of famous brand.
5. The pump could be electric motor or diesel engine.
Concrete Mixer Pump Features:
1. compact structure, flexible movement, easy operation and simple maintenance.
2. remote control with high automatic degree and easy operation, saving labor cost.
3. independent mixing system with even mixing performance and high working efficiency.
4. double cylinder hydraulic pump system with high pumping speed and high working efficiency.
5. advanced S-tube distribution valve, well sealing techinc, good sealing performance.
6. centralized lubrication system, low consumption of equipment parts, less maintenance cost.
7. equipped with wired remote controller, easy to operate.
8. PLC system to ensure best control performance.
Concrete Mixer Pump Application:
1. pump concrete, fine aggregates such as fine stone and mortar etc.
2. pump heat-insulated lightweight foamed cement, mortar floor heating, and self leveling for ground architecture.
3. pump plain concrete and fiber concrete in engineering construction.
4. pump refractory and thermal insulation material.
5. pump afforestation soil in ecological environment construction.
6. pressure perfussion for foundation piles, backfill in overbroken tunnels, railway slope supporting, and disaster management.
Concrete Mixer Pump Technical Parameters:
|
Model |
/ |
KBJ diesel engine concrete mixer pump |
|
Theoretic output |
M3/h |
30 |
|
Theoretic outlet pressure |
Mpa |
10 |
|
Theoretic delivery height |
m |
150 |
|
Theoretic delivery distance |
m |
300 |
|
Delivery pipe inner diameter |
mm |
Φ125 |
|
Rated voltage |
V |
~380 |
|
Main motor power |
Kw |
85 (YC04J22T-115) |
|
Hydraulic system pumping pressure |
MPa |
34 |
|
Hydraulic system mixing pressure |
MPa |
23 |
|
Max. Mixing speed |
r/min |
2400 |
|
Oil tank volume |
L |
280 |
|
Max. aggregate diameter |
mm |
≤40 |
|
Concrete slump |
mm |
80~200 |
|
Outer dimension (L*W*H) |
mm |
5800*2150*2600 |
|
Weight |
Kg |
5000 |
Detailed Configuration:
|
Item |
Configuration |
Place of Origin |
|
Diesel Engine |
Yuchai/DEUTZ |
China/Germany |
|
Main Oil Pump |
KAWASAKI |
Korea/Japan |
|
PLC |
Mitsubishi |
Japan |
|
Oil Cylinder |
Hunan XIELI |
China |
|
Concrete Cylinder |
Wuxi Shuangyu |
China |
|
Dynamo |
Shanghai PinXing |
China |
|
Hydraulic hose |
Manuli |
Italy |
|
Group Valve |
BolSeen |
Taiwan |
Concrete Mixer Pump Details:
|
