- Product Details
- {{item.text}}
Quick Details
-
Brand Name:
-
Bingo
-
Model Number:
-
PS-WE10
-
Max. Current:
-
12A
-
Max. Working Pressure:
-
10Bar
-
IP level:
-
ip68
-
rated current:
-
12A
-
operating temperature:
-
0-55
-
protection grade:
-
ip65
-
rated voltage:
-
110/230V
Quick Details
-
Whether the smart:
-
Yes
-
Max. Voltage:
-
110 / 230V
-
Place of Origin:
-
Shanghai, China
-
Brand Name:
-
Bingo
-
Model Number:
-
PS-WE10
-
Max. Current:
-
12A
-
Max. Working Pressure:
-
10Bar
-
IP level:
-
ip68
-
rated current:
-
12A
-
operating temperature:
-
0-55
-
protection grade:
-
ip65
-
rated voltage:
-
110/230V
Product Description
Water Pump Pressure Switch
1). Electric switch used in water systems.
2). It starts the electric pump automatically after a pressure decrease(taps opening) and stops it when the fluid flow interrupts at the maximum pressure level of the electric pump(taps closed).
3). Starting pressure is adjustable during installation, adjustment range: 1.0bar-3.5bar.
4). Joint screw: G1"male.
5). Completely replaced traditional pump control system composed of pressure switch, pressure tank and check valve, etc.
6). Stop the water pump in the case of water shortage.
7). Automatic reset after a stop caused by dry running, standard time-interval 60min/1 test.
8). Customized setting.
Detailed Images
Panel.
CE, TUV Certificate, IP65.
Installation interface.
Threaded interface,easy to install,firm and
Brand new engineering plastics.
ROHS certificateDifferent color available.
Wire connection port.
With rubber sleeve,sealed interface,waterproof
Installation instruc
Vertical installation, arrows indicate the flow of water.
Specification
|
Model
|
PS-WE10
|
|
Medium
|
water
|
|
Starting pressure
|
1.0bar, 1.2bar, 1.5bar or 2.2bar
|
|
Max.pressure
|
10bar
|
|
Power
|
1.1KW(220V-240V),0.75KW(110V-120V)
|
|
Electric rating
|
10A; 110V-120V or 220V-240V, 50/60Hz
|
|
temperature
|
Max.60℃
|
|
Connection
|
G1"
|
|
Protection grade
|
IP65
|
|
Size
|
228mm*169mm*167mm
|
Model selection
PS-WE10
PS-WE13
PS-WE14
PS-WE15
PS-WE16
PS-WE20
PS-WE21
PS-WE22
PS-WE23
PS-WE24
PS-WE30
PS-WE40
