Quick Details
-
Customized support:
-
Logo
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GLC
-
Model Number:
-
GLC-DGL-WIFI-04
-
Operating Temperature:
-
-20~70
-
Product Name:
-
Wifi Smart Switch
-
Material:
-
PC
-
Frequency:
-
WiFi 2.4GHz/433 MHZ
-
current:
-
40A
-
Voltage:
-
AC90V-AC264V
-
Usage:
-
Light/motor
-
Function:
-
Mobile Remote Control + Voice Control+RFControl
-
Key Feature2:
-
Alexa Google Home IFTTT
-
Support APP:
-
Smartlife Tuya
-
Application:
-
Water Pump
Quick Details
-
Max. Current:
-
40A
-
Max. Voltage:
-
264V
-
Network:
-
wifi+rf
-
Customized support:
-
Logo
-
Place of Origin:
-
Guangdong, China
-
Brand Name:
-
GLC
-
Model Number:
-
GLC-DGL-WIFI-04
-
Operating Temperature:
-
-20~70
-
Product Name:
-
Wifi Smart Switch
-
Material:
-
PC
-
Frequency:
-
WiFi 2.4GHz/433 MHZ
-
current:
-
40A
-
Voltage:
-
AC90V-AC264V
-
Usage:
-
Light/motor
-
Function:
-
Mobile Remote Control + Voice Control+RFControl
-
Key Feature2:
-
Alexa Google Home IFTTT
-
Support APP:
-
Smartlife Tuya
-
Application:
-
Water Pump
Product Paramenters
|
Key word
|
RF+wifi smart switch
|
Working voltage
|
AC90V-264V
|
|
|||
|
Product Size
|
54*84*28mm
|
RF working frequency
|
433.932 MHz
|
|
|||
|
Emission current
|
≤0.01 uA
|
APP
|
Tuya
|
|
|||
|
Remote control size
|
12*29*61mm
|
Control mode
|
RF+WIFI
|
|
|||
|
Current
|
40A
|
RF Remote Control Batteries
|
CR2016 two in series
|
|
|||
|
Working mode
|
Self-locking interlock Manual on/off Mobile APP control
|
|
|
|
|||
Details Images
Scope of application:
Learn Matching Instructions
Introduction to the working mode
Self-locking mode:
with a key control, press once open, then press once off, called self-locking.
Interlocking mode: when the remote control has two keys, one button is on and the other button is off, it is called interlocking.
Manual switch: no remote control, press the learning button on the receiver, press one on, then one off.
Interlocking mode: when the remote control has two keys, one button is on and the other button is off, it is called interlocking.
Manual switch: no remote control, press the learning button on the receiver, press one on, then one off.
Learning methods
Self-lock:
the controller is powered on, hold down the learning button and wait for 3 seconds, the indicator light will flash once, release your hand, press the button of the remote control, the indicator light will flash 3 times, indicating the success of code
Interlock: the controller is powered ON, hold down the learning button and wait for 5 seconds, the indicator flashes twice,
release your hand, press the ON/ ON button of the remote control, the indicator flashes for 3 times and then it is in the light state, and then press OFF/ key of the remote control, the indicator flashes twice, indicating success in code checking
Code clearing: the controller is powered on, hold down the learning button and wait for 8 seconds, and the indicator light flashes 4 times, indicating the code clearing is successful
Manual on/off : the learning button on the controller can control the output on and off, press that open, then press that off
Interlock: the controller is powered ON, hold down the learning button and wait for 5 seconds, the indicator flashes twice,
release your hand, press the ON/ ON button of the remote control, the indicator flashes for 3 times and then it is in the light state, and then press OFF/ key of the remote control, the indicator flashes twice, indicating success in code checking
Code clearing: the controller is powered on, hold down the learning button and wait for 8 seconds, and the indicator light flashes 4 times, indicating the code clearing is successful
Manual on/off : the learning button on the controller can control the output on and off, press that open, then press that off
