Quick Details
-
Power:
-
15kw, 15kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CNMC
-
Maximum Digging Height:
-
2350 mm
-
Maximum Digging Depth:
-
1300 mm
-
Machine Weight:
-
1600 kg
-
Max Digging Radius:
-
1100 mm
-
Rated Speed:
-
2.2km/h
-
Marketing Type:
-
New Product 2021
-
Product name:
-
1.5t small excavator
-
Brand:
-
CNMC
-
Keyword:
-
small excavators
-
Feature:
-
low price mini excavator
-
Type:
-
Mini Small Excavator
-
COLOR:
-
Customized
-
Displacement:
-
6.8ml/r
-
Application:
-
Construction Digging
-
Certification:
-
CE
Quick Details
-
Operating Weight:
-
900KG
-
Bucket capacity:
-
0.025cbm/100kg
-
Engine Brand:
-
CHANGCHAI
-
Power:
-
15kw, 15kw
-
Place of Origin:
-
Shandong, China
-
Brand Name:
-
CNMC
-
Maximum Digging Height:
-
2350 mm
-
Maximum Digging Depth:
-
1300 mm
-
Machine Weight:
-
1600 kg
-
Max Digging Radius:
-
1100 mm
-
Rated Speed:
-
2.2km/h
-
Marketing Type:
-
New Product 2021
-
Product name:
-
1.5t small excavator
-
Brand:
-
CNMC
-
Keyword:
-
small excavators
-
Feature:
-
low price mini excavator
-
Type:
-
Mini Small Excavator
-
COLOR:
-
Customized
-
Displacement:
-
6.8ml/r
-
Application:
-
Construction Digging
-
Certification:
-
CE
Specifications-1
Products Description
The product has
beautiful appearance, high configuration, superior performance, low fuel consumption and wide operating range
. Quick-change joints can be used to reduce maintenance and operation costs, liberate labor, increase mechanization, low investment and high return.
|
Model
|
CNM-13
|
|
Manufacturer
|
CHINA MACHINERY ENGNEERING MACHINERY CO.,LTD
|
|
Brand
|
RHINOCEROS
|
|
Opereting Weight
|
1100kg
|
|
Digging Bucket Capacity
|
0.025cbm/100kg
|
|
Bucket width
|
340mm
|
|
Engine
|
KOOP/ KUBOTA
|
|
Rated power
|
8.6kw/1800r/min
|
|
Displacement
|
0.499L
|
|
Bore stroke
|
70x55
|
|
Main pump
|
CBK-F6.8
|
|
Displacement
|
6.8ml/r
|
|
Swing motor
|
SJ-TECH (MP-1-160)
|
|
Traveling motor
|
KERSEN 310
|
|
Travel speed
|
2.2km/h
|
|
MAIN DEMENSIONS
|
|
|
Overall dimension LxWxH
|
2430x780x1420 mm
|
|
Wheelbase
|
770 mm
|
|
Total length of track
|
960mm
|
|
Piltform ground cearane
|
376 mm
|
|
Platform back tuning radius
|
664 mm
|
|
Chassis width
|
896 mm
|
|
Track width
|
180 mm
|
|
Chassisground ciarance
|
132 mm
|
|
Track height
|
320 mm
|
|
OPERATING RANGE
|
|
|
Max.digging depth
|
1300mm
|
|
Max. Vertical diging depth
|
1376 mm
|
|
Max.digging height
|
2350 mm
|
|
Max. Dumping height
|
1600 mm
|
|
Max. Digging redius on ground
|
1400 mm
|
|
Min. Rotation radius
|
1100 mm
|
|
Max. Upgrade height of bulldozer blade
|
120mm
|
|
Max. Digging depth of bulldozer blade
|
200 mm
|
Details Images
An extending undercarriage and fold out dozer blade allow the machine to be configured for excellent working stability and optimum performance. Easy retraction, controlled from the operator's seat, enables the machine to pass through narrow openings.
Packing and delivery
Our Advantanges
Trade strengths
China Machinery (Jining) Industrial Co., Ltd. is located in Asia's largest industrial base---Shandong Jining City. We are a professional manufacturer of construction machinery ,spare parts,and other heavy machinery equipments and accessories .
CHNMC owns it,s speiclal design, development, manufacturing as a professional manufacturer.We focus on a series of machines and accessories, a wide range of diversity, reasonable price and on-time delivery.
